Produkteinführung
The GE IC697MDL940 Relay Output Module is a high-performance, 16-point relay output module designed for the GE Fanuc Series 90-70 PLC system. This module is engineered to deliver reliable switching and control von both AC and DC loads, making it a versatile solution for industrial automation and process control systems.
The IC697MDL940 is capable von switching loads up to 16 amps per point and supports voltage ranges von 120/240 VAC or 5/24/125 VDC, making it suitable for a wide range von control tasks such as solenoid valves, contactors, and motor starters. Each output point is individually isolated to ensure robust operation and to prevent electrical interference between circuits.
The relay outputs are configured to handle 480 VA for AC loads and 60 watts for DC loads, providing high power-handling capability while maintaining stable performance. This design allows it to control inductive or resistive loads effectively in harsh industrial environments.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Hersteller | GE Fanuc |
| Product Modell | IC697MDL940 |
| Product Type | Relay Output Module |
| Series | Series 90-70 |
| Number von Outputs | 16 points |
| Output Type | Relay (Form A, normally open) |
| Load Voltage Range (AC) | 120/240 VAC |
| Load Voltage Range (DC) | 5/24/125 VDC |
| Load Current Capacity | 16 Amps per point |
| Power Handling (AC) | 480 VA per output |
| Power Handling (DC) | 60 Watts per output |
| Output Isolation | 1500 V RMS between groups and ground |
| Group Configuration | 4 isolated groups von 4 points each |
| Switching Delay (Operate/Release) | 10 ms typical |
| Status Indicators | Individual LED per output |
| Backplane Power Consumption | 0.7 Amps @ 5 VDC |
| Dielectric Strength | 1500 Vrms for 1 minute |
| Mounting Type | Rack-mounted (Series 90-70 rack) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H x W x D) | 200 × 40 × 150 mm |
| Gewicht | 0.912 kg |
Product Applications
The IC697MDL940 Relay Output Module is widely used in industrial automation systems where reliable and high-current switching is required. Its versatility makes it suitable for controlling both AC and DC loads across multiple sectors.
Key applications include:
-
Manufacturing automation systems controlling conveyors, actuators, and process equipment.
-
Power generation systems for controlling auxiliary equipment and protection devices.
-
Oil and gas control systems, managing solenoids, relays, and pumps.
-
Water treatment and distribution, operating valves and pumps.
-
Material handling systems, managing motors, drives, and contactors.
-
Building automation, controlling lighting and HVAC systems.
Product Advantages
The GE IC697MDL940 stands out for its durability, flexibility, and high electrical capacity. Designed for industrial-grade environments, it provides dependable operation even under continuous duty.
Key advantages include:
-
High Current Capacity – Each point can switch up to 16 amps, ideal for heavy-duty applications.
-
Wide Voltage Compatibility – Handles both AC (120/240 VAC) and DC (5/24/125 VDC) loads.
-
Independent Isolation – Each group is isolated, preventing noise coupling and improving system safety.
-
Long Relay Life – Industrial-grade relays provide excellent endurance under high load switching.
-
Status LEDs for Each Output – Easy visual troubleshooting and system monitoring.
-
Flexible Configuration – Supports a wide range von devices such as solenoids, contactors, and indicators.
-
Rugged Design – Withstands mechanical vibration and electrical noise typically found in industrial environments.
-
Backplane Integration – Seamlessly integrates into the GE Series 90-70 PLC platform.
FAQ
-
What types von loads can the IC697MDL940 control?
The IC697MDL940 is capable von controlling both AC and DC loads, such as solenoids, lamps, contactors, and small motors. It efficiently manages inductive and resistive loads within industrial automation systems. -
Can the module handle high inrush currents during startup?
Yes, the relay contacts are designed to withstand high inrush currents, allowing it to control inductive devices like motors and solenoids without contact damage. -
Does the module provide isolation between output groups?
The IC697MDL940 features four isolated groups von four points each. This design prevents electrical interference and ensures that each group operates independently. -
How are output statuses visually indicated on the module?
Each output point has an individual LED indicator that clearly shows the ON or OFF status, simplifying system diagnostics and field maintenance. -
What is the typical operating delay for the relay outputs?
The relays have an average operate or release time von around 10 milliseconds, ensuring fast and dependable response in industrial control operations. -
Can AC and DC loads be used on the same module simultaneously?
Yes, AC and DC loads can be used on the same module, provided they are assigned to separate isolated groups to prevent cross-interference or grounding issues. -
What protection is recommended for inductive load switching?
For inductive loads such as coils and motors, external suppression components like diodes or RC snubbers should be installed to minimize contact arcing and extend relay life. -
How is field wiring performed on the IC697MDL940 module?
The module includes removable terminal blocks for easy field wiring. Proper wire gauge and torque specifications should be followed to ensure secure and reliable electrical connections. -
What is the power consumption from the PLC backplane?
The module draws approximately 0.7 A from the 5 VDC backplane supply, which must be considered during system power budgeting. -
Is the IC697MDL940 compatible with redundant PLC configurations?
Yes, it can be deployed in redundant or fail-safe GE Fanuc Series 90-70 PLC systems to enhance reliability and ensure continuous control in mission-critical applications.
Recommended Related Modells (Same Series or Similar Function)
| Modell Number | Beschreibung | Voltage/Current Rating | Output Type | Points |
|---|---|---|---|---|
| IC697MDL710 | Relay Output Module | 24/48 VDC, 2 A | Relay | 16 |
| IC697MDL740 | Discrete Output Module | 24/48 VDC, 2 A | Transistor | 16 |
| IC697MDL750 | Discrete Output Module | 24/48 VDC, 0.5 A | Transistor | 32 |
| IC697MDL752 | Discrete Output Module | 12 VDC, 0.5 A | Transistor | 32 |
| IC697MDL753 | Discrete Output Module | 5/48 VDC, 0.5 A | Transistor (Negative Logic) | 32 |
| IC697MDL930 | Relay Output Module | 120 VAC, 2 A | Relay | 8 |
Popular Modells from the Same Marke (GE Fanuc)
| Modell Number | Beschreibung | Function | Series |
|---|---|---|---|
| IC697CPU772 | Central Processing Einheit | CPU Module | Series 90-70 |
| IC697ALG230 | Analog Input Module | 8-Channel Analog Input | Series 90-70 |
| IC697ALG440 | Analog Output Module | 8-Channel Analog Output | Series 90-70 |
| IC697MDL250 | Discrete Input Module | 120 VAC Input | Series 90-70 |
| IC697BEM731 | Genius Bus Controller | Communication Module | Series 90-70 |
| IC697CMM742 | Ethernet Interface Module | Network Communication | Series 90-70 |
