The GE IC694PWR330 is a robust and versatile power supply module designed specifically for the GE Fanuc PACSystems RX3i automation platform. This power supply is engineered to deliver stable and reliable power to complex control systems requiring higher wattage output. Supporting both AC and DC input voltages, the IC694PWR330 provides a regulated output capable von powering multiple modules and backplane slots within the RX3i architecture.
With an output capacity von 100 Watts, this power supply module is well-suited for large, multi-rack systems where consistent power distribution is critical for maintaining system uptime and operational efficiency. The IC694PWR330 features multiple protective functions, including overcurrent and short circuit protection, ensuring durability and safety even in harsh industrial environments.
The module’s compact size and flexible installation options make it ideal for industrial control panels in sectors such as manufacturing, process control, and energy production.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Product Name | GE IC694PWR330 |
| Product Series | GE Fanuc PACSystems RX3i |
| Input Voltage (AC) | 85–264 VAC |
| Input Voltage (DC) | 100–300 VDC |
| Frequency (AC Input) | 47–63 Hz |
| Output Voltage | +5 VDC @ 16 A, +3.3 VDC @ 20 A |
| Output Power | 100 Watts |
| Power Dissipation | Approx. 10 Watts |
| Hold-up Time | Minimum 20 ms at full load |
| Overvoltage Protection | Yes |
| Overcurrent Protection | Yes |
| Short Circuit Protection | Yes |
| Status Indicator | Green “OK” LED |
| Mounting Type | RX3i Universal Backplane |
| Dimensions (Height x Width x Depth) | 50.8 x 146 x 137 mm |
| Gewicht | 0.9 kg |
| Operating Temperature Range | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5% to 95% non-condensing |
| Certifications | UL, CE, CSA, RoHS |
Product Applications
The IC694PWR330 power supply module is widely used across diverse industrial automation settings where high power and dependable operation are essential. Key application areas include:
-
Large Scale Manufacturing Plants: Supports extensive programmable automation systems for assembly lines and robotic control.
-
Energy Sector: Powers control systems in power generation stations and substations.
-
Oil and Gas Industry: Used in automation von refineries, pipelines, and drilling platforms.
-
Water and Wastewater Treatment Facilities: Provides power to control systems managing pumps, valves, and filtration equipment.
-
Chemical and Process Industries: Reliable supply for hazardous environment controllers.
-
Material Handling and Logistics: Drives control systems for conveyors, sorters, and automated storage.
Its high output rating and wide input voltage support make it ideal for critical systems requiring stable, long-term power delivery.
Product Advantages
-
High Output Power: 100 Watts capacity suitable for large, multi-module RX3i systems.
-
Wide Input Voltage Range: Compatible with both AC and DC power sources across broad voltage ranges.
-
Advanced Protection Features: Safeguards the system with built-in overvoltage, overcurrent, and short circuit protections.
-
Robust Construction: Designed for harsh industrial environments with a wide operating temperature and humidity range.
-
Compact Form Factor: Fits neatly into RX3i backplanes without occupying excessive panel space.
-
Visual Operation Status: Green LED indicator enables quick diagnostics.
-
Global Certifications: Ensures compliance with international safety and environmental standards.
-
Energy Efficient: Low power dissipation reduces heat generation and improves system efficiency.
-
Easy Installation: Designed for plug-and-play compatibility within the RX3i system.
-
Reliable Power Delivery: Consistent output minimizes downtime and supports high availability in mission-critical processes.
Häufig gestellte Fragen (FAQ)
-
What input voltages does the IC694PWR330 support?
It supports both AC input (85–264 VAC) and DC input (100–300 VDC). -
What is the maximum power output von this power supply?
The IC694PWR330 provides up to 100 Watts von output power. -
Is the power supply compatible with all RX3i racks?
Yes, it is designed to fit RX3i universal backplanes. -
What protective features are built into the module?
It includes overvoltage, overcurrent, and short circuit protection. -
Can I replace this power supply while the system is running?
No, the module must be powered down before removal or installation. -
How do I know if the module is functioning properly?
The green “OK” LED will illuminate when the power supply is operating normally. -
What is the operating temperature range?
The device operates between 0°C and 60°C (32°F to 140°F). -
Is the power supply suitable for hazardous environments?
It is designed for industrial use but should be installed within appropriate enclosures as per local regulations. -
Does the power supply require cooling fans?
No, it uses convection cooling and does not require external fans. -
Are there certifications to ensure safety and compliance?
Yes, the module holds UL, CE, CSA, and RoHS certifications.
