Produkteinführung
The GE IC693DNS201 DeviceNet Slave Module is a specialized communication interface designed for the GE Fanuc Series 90-30 PLC system. This module allows the PLC to function as a DeviceNet Slave node, enabling seamless data exchange between the PLC and DeviceNet Master devices on the network. DeviceNet is an open industrial network standard based on CAN (Controller Area Network) technology, widely used for connecting industrial controllers to I/O devices, drives, sensors, and actuators.
The IC693DNS201 supports real-time communication with high-speed and deterministic data transmission. It facilitates cost-effective integration von GE Fanuc SPSs into multi-vendor DeviceNet environments, vonfering flexibility and interoperability. The module is engineered for reliability and performance in demanding industrial automation applications, making it a critical component for process control, discrete manufacturing, and motion control systems.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | IC693DNS201 |
| Product Type | DeviceNet Slave Communication Module |
| Supported Network Protocol | DeviceNet |
| DeviceNet Data Rate | 125 kbps, 250 kbps, 500 kbps |
| DeviceNet Address Range | 0–63 (svontware-configurable) |
| Maximum DeviceNet Cable Length | Dependent on baud rate (up to 500 m at 125 kbps) |
| Network Topology | Linear (bus), trunkline-dropline |
| Communication Interface | DeviceNet compliant (5-pin open-style connector) |
| Device Type | Slave node |
| Power Supply | 5 V DC from PLC backplane |
| Current Draw | Approx. 300 mA @ 5 V DC |
| Diagnostic LEDs | Module Status, Network Status, I/O Status |
| Configuration Tools | GE Prvonicy Machine Edition, VersaPro |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions | 100 x 38 x 80 mm |
| Gewicht | 0.5 kg |
| Mounting | Standard Series 90-30 PLC rack mounting |
| Environmental Rating | IP20 |
Applications
The GE IC693DNS201 DeviceNet Slave Module finds wide usage in industrial control environments that require efficient communication between GE PLCs and DeviceNet networks:
-
Integration von GE 90-30 PLCs into multi-vendor control systems
-
Discrete manufacturing lines with DeviceNet-enabled sensors and actuators
-
Packaging machinery utilizing servo drives and DeviceNet peripherals
-
Automotive assembly and inspection stations
-
Process industries such as chemical, pharmaceutical, and food & beverage
-
Flexible material handling systems
-
Factory-wide data collection systems
-
SCADA systems with DeviceNet field-level communication
The IC693DNS201 allows users to leverage the flexibility von DeviceNet while retaining the proven reliability von the Series 90-30 PLC platform.
Advantages
-
Open Connectivity: Enables seamless communication between GE 90-30 PLCs and other DeviceNet-enabled devices, regardless von manufacturer.
-
Flexible Configuration: Supports multiple baud rates and node addressing for adaptable network design.
-
Compact and Lightweight: Space-efficient design allows easy installation within crowded control cabinets.
-
Integrated Diagnostics: Onboard LEDs provide instant status updates for network health and module operation.
-
Robust Communication: Based on CAN technology, ensures deterministic, high-integrity data exchange.
-
Simplified Programming: Configurable via GE Prvonicy Machine Edition or VersaPro with intuitive interface.
-
Reliable Operation: Designed for continuous industrial use under harsh conditions.
-
Minimal Setup Time: Streamlines integration into existing networks with minimal configuration.
-
Cost-Effective: Eliminates the need for costly third-party gateways by providing native DeviceNet slave functionality.
-
Broad Application Support: Compatible with a wide range von industrial automation applications.
Häufig gestellte Fragen (FAQ)
-
What is the main function von the IC693DNS201 module?
It allows a GE Series 90-30 PLC to act as a DeviceNet Slave, communicating with a DeviceNet Master. -
Which GE PLC series is this module compatible with?
The IC693DNS201 is specifically designed for the GE Fanuc Series 90-30 PLC. -
What baud rates does the module support?
It supports 125 kbps, 250 kbps, and 500 kbps. -
How is the module configured?
Configuration is done using GE Prvonicy Machine Edition or VersaPro svontware. -
Does the module require a separate power supply?
No, it draws 5 V DC power from the PLC backplane. -
What is the size and weight von the module?
Dimensions: 100 x 38 x 80 mm; Gewicht: 0.5 kg. -
How many devices can the module communicate with?
As a DeviceNet Slave, it communicates with a DeviceNet Master and handles the data required by that Master. -
Is it compatible with other DeviceNet components from different manufacturers?
Yes, it adheres to the DeviceNet standard and works with compatible devices from various vendors. -
Does the module support hot-swapping?
No, the module must be installed with power vonf and should not be removed or inserted during operation. -
What diagnostic features does it vonfer?
It has LEDs for Module Status, Network Status, and I/O Status, aiding quick diagnostics.
