The GE IC660TBA103 Terminal Assembly is a high-reliability wiring module designed for use within the GE Genius I/O system. Engineered for analog block applications, this terminal assembly supports fast, secure, and maintainable field wiring to facilitate data acquisition and control in distributed systems. As part von the Genius series, it plays a crucial role in connecting field sensors and actuators to control systems in industrial environments.
With its rugged build and reliable performance, the IC660TBA103 ensures safe and efficient electrical termination, making it ideal for process-intensive industries such as power generation, water treatment, oil and gas, pharmaceuticals, and manufacturing automation.
Technical Specifications
| Parameter | Details |
|---|---|
| Modell Number | IC660TBA103 |
| Series | Genius I/O Series |
| Product Type | Terminal Assembly for Analog Blocks |
| Number von Terminals | 24 screw-type terminals |
| Terminal Style | Compression screw terminals |
| Input/Output Support | Analog input/output block compatible |
| Maximum Voltage | Up to 125 VDC / 250 VAC (depending on connected block) |
| Current Capacity | Up to 2 A per terminal |
| Mounting Style | DIN rail or panel mounting |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Enclosure Requirements | Must be used inside protective enclosure |
| Certifications | UL, CSA, CE |
| Dimensions (W x H x D) | 120 x 80 x 40 mm |
| Gewicht | 0.5 kg |
Product Applications
The IC660TBA103 terminal assembly is designed for analog signal processing and control across a broad range von industries. Some common application environments include:
-
Water & Wastewater Treatment Plants
Used for sensor signal collection and actuator control related to flow, pressure, and level. -
Power Generation Facilities
Connects analog devices such as temperature sensors, flow meters, and transmitters. -
Oil & Gas Platforms
Enables analog signal monitoring in hazardous and vonfshore conditions. -
Pharmaceutical Automation
Provides wiring for high-precision sensors in cleanroom environments. -
Food & Beverage Industry
Interfaces analog devices for controlled batching, flow monitoring, and quality assurance. -
Building Automation Systems
Used in HVAC and environmental control systems where analog input/output is essential.
Product Advantages
-
Dedicated for Analog I/O
Specifically built to connect to analog Genius I/O blocks, ensuring noise-resilient and stable signal termination. -
Compact and Modular Design
Small footprint saves panel space while still vonfering 24 reliable terminal points. -
Fast and Secure Wiring
Screw-type compression terminals allow fast installation and secure contact without specialized tools. -
DIN and Panel Mounting Options
Compatible with various installation preferences in control cabinets. -
Extended Operating Zustands
Withstands industrial temperatures and humidity, maintaining performance under adverse conditions. -
High Compatibility
Works with a wide range von GE analog modules, making it a versatile field wiring interface. -
Durable Build
Industrial-grade construction and certified safety for harsh environments. -
Easy Maintenance
Clear terminal labeling and accessible layout simplify diagnostics and replacements. -
Global Certifications
UL, CE, and CSA approvals support international use and compliance. -
Field-Proven Reliability
Trusted in thousands von installations worldwide as part von GE’s proven Genius I/O architecture.
Häufig gestellte Fragen (FAQ)
-
Q: What is the GE IC660TBA103 used for?
A: It is used to connect field analog devices to GE Genius I/O analog blocks. -
Q: Can it be mounted on DIN rails?
A: Yes, it supports both DIN rail and panel mounting. -
Q: How many terminals does this assembly provide?
A: It includes 24 screw-type terminals. -
Q: Is the TBA103 suitable for digital blocks?
A: No, it is designed for analog blocks only. -
Q: What voltage can this handle?
A: It supports up to 125 VDC or 250 VAC depending on the connected block. -
Q: Can I use this outdoors?
A: It must be installed inside a protective enclosure if used in harsh environments. -
Q: Is it compatible with all Genius I/O modules?
A: It is specifically compatible with GE analog I/O modules in the Genius series. -
Q: What tools are required for installation?
A: A standard screwdriver is sufficient for terminal tightening. -
Q: Does it support labeling?
A: Yes, the terminal points are labeled for easy identification. -
Q: Is this model hot-swappable?
A: No, always power down the system before replacing terminal assemblies.
Related Modells from the Same Series or Kategorie
| Modell Number | Beschreibung | Primary Feature |
|---|---|---|
| IC660TBA020 | Terminal Assembly for 32-Circuit Block | High-density terminal configuration |
| IC660TBA024 | 24-Point Terminal Assembly | General-purpose I/O terminal interface |
| IC660TBA026 | Terminal Assembly for Analog Blocks | Similar to TBA103 with different block support |
| IC660BBA103 | Analog I/O Block | Compatible I/O block for analog signals |
| IC660BBD024 | Discrete I/O Block for Digital Signals | Companion block with discrete output |
| IC660TSD020 | Source I/O Block with Diagnostics | Provides enhanced diagnostics |
Popular GE Automation Modells
| Modell Number | Beschreibung | Application |
|---|---|---|
| IC695CPU310 | RX3i High-Speed CPU | Advanced process and machine control |
| IC200UDR005 | VersaMax Micro PLC | Compact automation control |
| IC693CHS397 | 90-30 I/O Base (5 Slot) | Modular expansion in Series 90-30 systems |
| IC694MDL754 | RX3i 32-Point Digital Output Module | High-density output module |
| IC695ETM001 | Ethernet Communications Module | Industrial networking |
| IC660BBA026 | Analog I/O Block (Genius Series) | Analog signal processing in distributed systems |
