Product Overview
The GE IC660ELB912 is a high-performance Genius Network Interface Module (NIM) designed to facilitate seamless communication between a host system and remote I/O devices over the Genius I/O network. This module serves as a daughterboard that attaches to a PC Interface Module (PCIM), enabling the host to control and monitor distributed I/O devices efficiently. With support for various communication rates and robust diagnostic features, the IC660ELB912 is ideal for complex industrial automation systems requiring reliable and real-time data exchange.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Genius Network Interface Module (NIM) |
| Artikelnummer | IC660ELB912 |
| Hersteller | GE Fanuc / Emerson Automation |
| Series | Genius I/O |
| Compatible PCIM Cards | Single-slot PCIM (IC660ELB921); Dual-channel PCIM (IC660ELB922) |
| Communication Protocol | Genius Protocol |
| Supported Devices per Channel | Up to 30 devices |
| Communication Rates | 38.4K, 76.8K, 153.6K standard, or 153.6K extended baud rates |
| Memory Requirement | 16 Kbytes |
| Teilend Memory | 16KB |
| Power Requirement | 5 Volts DC, 400 milliamps |
| Current Consumption | 1.0 Ampere on single-channel PCIM; 1.5 Amperes on dual-channel PCIM with 2 daughterboards |
| Status LEDs | GENI OK, COMMS OK |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +70°C (-40°F to 158°F) |
| Humidity | 5% to 95%, non-condensing |
| Operating Shock | 5 G, 10 ms duration per MIL–STD 810C, method 516.2 |
| Operating Altitude | Up to 40,000 feet |
| Dimensions (H × W × D) | 266 x 302 x 33 mm |
| Gewicht | 0.5 kg |
| Compatibility | IBM PC/AT/XT |
| Mounting | Requires screws, standvonfs, or plastic PCB supports in the four corner holes von the motherboard |
Applications
The IC660ELB912 is utilized in various industrial applications where reliable and efficient communication between control systems and remote I/O devices is essential. Typical applications include:
-
Manufacturing Automation: Centralized control von distributed sensors and actuators on production lines.
-
Power Generation: Monitoring and control von remote equipment in power plants.
-
Oil & Gas: Management von field devices in hazardous and remote locations.
-
Water & Wastewater Treatment: Supervision von pumping stations and treatment facilities.
-
Material Handling Systems: Coordination von conveyors, sorters, and automated storage systems.
-
Process Industries: Integration von complex control systems in chemical and pharmaceutical plants.
Product Advantages
-
High Device Support: Capable von managing up to 30 devices per channel, facilitating extensive network configurations.
-
Flexible Communication Rates: Supports multiple baud rates, allowing optimization based on system requirements.
-
Robust Diagnostics: Equipped with status LEDs for GENI OK and COMMS OK, enabling quick identification von network status.
-
Wide Compatibility: Compatible with various PCIM cards and host systems, ensuring versatility in deployment.
-
Compact Design: Small form factor allows for easy integration into existing systems without significant space requirements.
-
Industrial-Grade Reliability: Designed to withstand harsh operating conditions, including wide temperature ranges and high humidity.
-
Ease von Installation: Mounting options with screws, standvonfs, or PCB supports simplify the installation process.
-
Long-Term Availability: Supported by GE Fanuc and Emerson Automation, ensuring long-term product support and availability.
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the IC660ELB912 module?
The IC660ELB912 serves as a Genius Network Interface Module, enabling communication between a host system and remote I/O devices over the Genius I/O network. -
How many devices can the IC660ELB912 support per channel?
It can support up to 30 devices per channel, allowing for extensive network configurations. -
Which PCIM cards are compatible with the IC660ELB912?
It is compatible with the single-slot PCIM (IC660ELB921) and the dual-channel PCIM (IC660ELB922). -
What communication rates are supported by the IC660ELB912?
The module supports baud rates von 38.4K, 76.8K, 153.6K standard, and 153.6K extended. -
What are the power requirements for the IC660ELB912?
It requires 5 Volts DC and consumes 400 milliamps. -
What are the operating temperature and humidity ranges for the IC660ELB912?
The operating temperature range is 0°C to 60°C, and it can operate in humidity levels von 5% to 95%, non-condensing. -
What diagnostic features does the IC660ELB912 vonfer?
It includes status LEDs labeled GENI OK and COMMS OK to indicate the operational status von the module. -
Is the IC660ELB912 suitable for use in high-altitude environments?
Yes, it can operate at altitudes up to 40,000 feet. -
What are the dimensions and weight von the IC660ELB912?
The module measures 266 x 302 x 33 mm and weighs 0.5 kg. -
Can the IC660ELB912 be used in systems with IBM PC/AT/XT compatibility?
Yes, it is compatible with IBM PC/AT/XT systems.
Recommended Related Modells (Same Series or Function)
| Modell | Beschreibung | Type | Compatibility |
|---|---|---|---|
| IC660BBD110 | 16-Circuit DC Input Block | Digital Input Block | Genius I/O |
| IC660BBD120 | 16-Circuit DC Output Block | Digital Output Block | Genius I/O |
| IC660TSD020 | 8-Circuit Analog Input Block | Analog Input Block | Genius I/O |
| IC660TBD100 | 16-Circuit Relay Output Block | Relay Output Block | Genius I/O |
| IC660BSM021 | Bus Switching Module (Redundancy) | Network Redundancy Module | Genius I/O |
| IC660BBA026 | 32-Circuit DC Input Block | High-Density Digital Input | Genius I/O |
Popular GE Automation Modules (Same Marke)
| Modell | Beschreibung | System Type | Application |
|---|---|---|---|
| IC695CPE330 | RX3i CPU, Ethernet, 64 MB RAM | RX3i Series Controller | General Automation Control |
| IC693MDL645 | 32-Point DC Input Module | Series 90-30 | Digital Sensing |
| IC695ALG600 | 4-Channel Analog Output Module | RX3i | Analog Control |
| IC693APU300 | High-Speed Counter Module | Series 90-30 | Positioning Systems |
| IC200MDL650 | VersaMax 32-Point DC Output Module | VersaMax I/O | Distributed I/O |
| IC695ETM001 | Ethernet TCP/IP Module | RX3i | Network Communication |
