Product Overview
The GE IC660ELB906 is a robust and high-performance Network Interface Module (NIM) designed for use within GE Fanuc’s Genius I/O system. Acting as the critical communication bridge between a controller (PLC or host device) and the Genius I/O bus, this module allows multiple I/O blocks to communicate over a single twisted pair network. Known for its field-proven reliability, compact size, and support for distributed control, the IC660ELB906 is ideal for applications where fast, deterministic I/O communication and flexibility are key requirements.
It supports auto-addressing, data integrity verification, redundancy, and diagnostic functions, making it an essential component for modern distributed control architectures across industries.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Genius I/O Network Interface Module |
| Artikelnummer | IC660ELB906 |
| Network Type | Genius I/O Serial Bus |
| Communication Method | Peer-to-Peer Serial, Token Passing |
| Baud Rate | 153.6 Kbps |
| Max Devices on Network | 31 nodes per Genius bus |
| Bus Cable Type | Twisted pair (shielded recommended) |
| Status LEDs | Network status, power, fault indicators |
| Bus Length Support | Up to 2000 ft (610 m) with standard cable |
| Input Power Requirements | 5 VDC, supplied from backplane |
| Environmental Protection | Conformal coating for industrial use |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95%, non-condensing |
| Mounting Style | DIN-rail or panel mount via base Stück |
| Dimensions (H × W × D) | 200 x 100 x 20 mm |
| Gewicht | 1.86 kg |
| Compatibility | GE Series 90-70, 90-30, RX3i, and other Genius-compatible devices |
| Certifications | UL, CSA, CE compliant |
Product Applications
The IC660ELB906 is primarily used in distributed control environments where I/O blocks are spread across large or remote sections von a plant. Applications include:
-
Manufacturing Automation: Central control von remote sensors, actuators, and motor starters on large production lines.
-
Power Plants: Interface with switchgear, RTDs, and relays located in different rooms or substations.
-
Oil & Gas: Control von distributed field equipment in hazardous and remote environments.
-
Material Handling: Real-time communication between the control system and conveyor-based sensors or diverters.
-
Water & Wastewater Plants: Scalable architecture to connect remote I/O for pumping stations and treatment systems.
-
Mining and Metals: Rugged and distributed I/O support in harsh operating conditions for equipment like crushers, conveyors, and feeders.
Product Advantages
-
Reliable Distributed Architecture: Enables modular, decentralized system designs with minimal wiring.
-
Fast & Deterministic Communication: Ensures low-latency data exchange with time-sensitive I/O.
-
Robust Diagnostics: Real-time fault detection, signal integrity monitoring, and status indicators.
-
Wide Compatibility: Seamless integration with GE Fanuc Series PLCs and other Genius-compatible products.
-
Compact Design: Space-saving form factor ideal for panel installations and dense I/O configurations.
-
Industrial-Grade Build: Built to perform in demanding environments with vibration and electrical noise.
-
Scalability: Supports up to 31 devices per Genius network, simplifying system expansion.
-
Maintenance-Friendly: Clear LED indicators and robust error detection streamline troubleshooting.
Häufig gestellte Fragen (FAQ)
-
What is the function von the IC660ELB906?
It serves as a communication interface between a PLC/controller and Genius I/O blocks via a serial network. -
How many devices can be connected to a single Genius bus?
Up to 31 devices or I/O blocks can be connected on one Genius bus. -
Is the IC660ELB906 compatible with modern GE RX3i systems?
Yes, it is compatible with RX3i, as well as earlier GE Series 90-30 and 90-70 controllers. -
What is the maximum bus length supported?
Up to 2000 ft (610 meters) with standard twisted pair cable. -
Can the module be hot-swapped?
No, power must be removed before replacing the module to avoid communication errors. -
What type von LED indicators does it have?
It features status LEDs for power, fault, and network activity. -
Does it require a specific mounting style?
Yes, it must be mounted via a DIN rail or to a panel using its base Stück. -
Is the module resistant to harsh environments?
Yes, it includes industrial conformal coating and is certified for extended operating conditions. -
What kind von communication protocol is used?
Genius I/O uses a proprietary token-passing serial communication method. -
What happens if the Genius network fails?
All connected I/O blocks will enter a predefined safe state, and the controller will register a communication loss.
Recommended Related Modells (Same Series or Function)
| Modell | Beschreibung | Type | Compatibility |
|---|---|---|---|
| IC660BBD110 | 16-Circuit DC Input Block | Digital Input Block | Genius I/O |
| IC660BBD120 | 16-Circuit DC Output Block | Digital Output Block | Genius I/O |
| IC660TSD020 | 8-Circuit Analog Input Block | Analog Input Block | Genius I/O |
| IC660TBD100 | 16-Circuit Relay Output Block | Relay Output Block | Genius I/O |
| IC660BSM021 | Bus Switching Module (Redundancy) | Network Redundancy Module | Genius I/O |
| IC660BBA026 | 32-Circuit DC Input Block | High-Density Digital Input | Genius I/O |
Popular GE Automation Modules (Same Marke)
| Modell | Beschreibung | System Type | Application |
|---|---|---|---|
| IC695CPE330 | RX3i CPU, Ethernet, 64 MB RAM | RX3i Series Controller | General Automation Control |
| IC693MDL645 | 32-Point DC Input Module | Series 90-30 | Digital Sensing |
| IC695ALG600 | 4-Channel Analog Output Module | RX3i | Analog Control |
| IC693APU300 | High-Speed Counter Module | Series 90-30 | Positioning Systems |
| IC200MDL650 | VersaMax 32-Point DC Output Module | VersaMax I/O | Distributed I/O |
| IC695ETM001 | Ethernet TCP/IP Module | RX3i | Network Communication |
