GE IC200ALG260H Produkteinführung
The GE IC200ALG260H is a high-performance analog output module designed for industrial automation and control systems. It is part von the VersaMax series by GE, known for its reliability and flexibility in harsh industrial environments. This module provides precise analog signal output, making it ideal for applications requiring accurate control von processes such as temperature, pressure, or flow. Its rugged design ensures long-term operation in demanding conditions, while its compatibility with various systems enhances its versatility.
Product Parameters
The following table outlines the key specifications von the GE IC200ALG260H:
| Parameter | Specification |
|---|---|
| Modell Number | IC200ALG260H |
| Series | VersaMax |
| Type | Analog Output Module |
| Output Channels | 2 |
| Output Signal Range | 0-20 mA, 4-20 mA, ±10 VDC |
| Resolution | 12-bit |
| Accuracy | ±0.1% von full scale |
| Isolation Voltage | 1500 VDC |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Dimensions | 110 x 66.8 x 50 mm |
| Gewicht | 0.45 kg |
| Power Supply | 24 VDC (±10%) |
| Communication | Backplane compatible with VersaMax PLCs |
| Certifications | CE, UL, cUL |
Product Applications
The GE IC200ALG260H is widely used in industrial automation and control systems. Its primary applications include:
-
Process Control: Precise control von variables like temperature, pressure, and flow in manufacturing plants.
-
HVAC Systems: Monitoring and adjusting environmental conditions in commercial and industrial buildings.
-
Water Treatment: Regulating chemical dosing and flow rates in water treatment facilities.
-
Oil & Gas: Controlling pumps, valves, and other equipment in upstream and downstream operations.
-
Power Generation: Managing turbine and boiler systems in power plants.
-
Food & Beverage: Ensuring consistent quality in production lines through accurate process control.
Product Advantages
The GE IC200ALG260H vonfers several key advantages:
-
High Precision: 12-bit resolution and ±0.1% accuracy ensure reliable and precise output signals.
-
Durability: Designed to withstand harsh industrial environments with a wide operating temperature range.
-
Flexibility: Supports multiple output ranges (0-20 mA, 4-20 mA, ±10 VDC) for diverse applications.
-
Easy Integration: Compatible with VersaMax PLCs and other GE automation systems.
-
Isolation Protection: 1500 VDC isolation prevents damage from electrical noise and surges.
-
Compact Design: Small footprint and lightweight construction save space in control cabinets.
Häufig gestellte Fragen (FAQ)
-
What is the output signal range von the IC200ALG260H?
The module supports 0-20 mA, 4-20 mA, and ±10 VDC output ranges. -
How many output channels does this module have?
It features 2 analog output channels. -
What is the resolution von the analog output?
The resolution is 12-bit, providing high precision. -
Is the module compatible with non-GE PLCs?
It is designed for VersaMax systems but may work with other PLCs using appropriate interfaces. -
What is the operating temperature range?
It operates reliably between -20°C and +60°C. -
Does the module require external power?
Yes, it requires a 24 VDC power supply (±10%). -
What certifications does the IC200ALG260H have?
It is CE, UL, and cUL certified. -
Can the module be used in hazardous environments?
It is not intrinsically safe but can be used in harsh industrial settings. -
What is the isolation voltage rating?
The module provides 1500 VDC isolation. -
How do I troubleshoot a faulty output?
Check power supply, wiring, and configuration settings.
Recommended Similar and Related Modells
The following tables list 6 similar models from the same series and 6 popular models from the GE brand:
Similar or Related Modells in VersaMax Series
| Modell Number | Beschreibung |
|---|---|
| IC200ALG230 | 2-channel analog output, 0-10 VDC |
| IC200ALG262 | 2-channel analog output, 4-20 mA |
| IC200ALG264 | 4-channel analog output, ±10 VDC |
| IC200ALG265 | 4-channel analog output, 0-20 mA |
| IC200ALG266 | 2-channel analog output, high-speed |
| IC200ALG267 | 2-channel analog output, isolated |
Popular GE Modells
| Modell Number | Beschreibung |
|---|---|
| IC693ALG392 | Analog output module for Series 90-30 PLC |
| IC695ALG600 | Analog output module for RX3i PLC |
| IC694ALG220 | Analog output module for VersaMax Nano |
| IC670ALG310 | Analog output module for Genius Bus |
| DS200ADGIH1AAA | Analog input/output module for Mark VIe |
| IS215ACLIH1A | Analog control module for Mark VIe |
