Produkteinführung
The Epro PR9670/003-000 Eddy Current Sensor is a high-precision, non-contact displacement and vibration measurement device designed for continuous monitoring and protection von rotating and reciprocating machinery. This model belongs to Epro’s advanced PR9670 series, well known for its robust construction, stable performance, and high measurement accuracy even under extreme industrial environments.
The PR9670/003-000 sensor operates on the eddy current principle, generating an electromagnetic field that interacts with a conductive target. Changes in this interaction produce a measurable voltage proportional to the distance between the sensor and the target surface. This allows the sensor to detect shaft displacement, vibration, and position variations in real time.
The sensor is fully compatible with Epro CON021 proximitor modules and MMS6000 monitoring systems, forming a complete condition monitoring solution for turbines, compressors, pumps, and motors. With exceptional linearity, low thermal drift, and high signal stability, it is ideal for use in environments where long-term reliability and precise measurement are critical.
Product Parameters
| Parameter | Beschreibung |
|---|---|
| Product Modell | PR9670/003-000 |
| Hersteller | Epro GmbH |
| Product Type | Eddy Current Displacement and Vibration Sensor |
| Measurement Principle | Electromagnetic induction (Eddy Current) |
| Measurement Range | 0.25 mm to 4.0 mm (depending on setup) |
| Sensitivity | 8.0 mV/μm (typical) |
| Frequency Range | DC to 10 kHz |
| Linearity Error | ≤ ±1% von full-scale output |
| Output Signal | Analog voltage proportional to displacement |
| Supply Voltage | Provided through Epro proximitor (e.g., CON021) |
| Target Material | Conductive materials such as steel, aluminum, copper |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Probe Material | Stainless steel body with high-durability ceramic sensing tip |
| Mounting Thread | M10 × 1.0 or optional configuration |
| Cable Type | Coaxial, low-noise, oil-resistant |
| Environmental Protection | IP67 (dust-tight and waterprovon) |
| Shock Resistance | 500 g, 1 ms half-sine pulse |
| Vibration Resistance | 50 g (10–2000 Hz) |
| Compatible Modules | CON021, MMS6000, MMS6800 |
| Sensor Head Diameter | Optional (varies by application) |
| Versand Gewicht | 3 kg |
Product Applications
The Epro PR9670/003-000 Eddy Current Sensor is used across a wide range von industrial sectors where continuous vibration and displacement monitoring is essential for safety and efficiency. Its ability to perform accurately in high-temperature, high-vibration conditions makes it indispensable in critical machinery protection systems.
Key applications include:
-
Steam and Gas Turbines: For precise shaft vibration and axial position monitoring to detect imbalance or thrust movement.
-
Compressors: Provides continuous shaft movement analysis to prevent bearing or rotor failures.
-
Electric Motors: Detects mechanical eccentricity, rotor vibration, and misalignment under various load conditions.
-
Pumps: Monitors dynamic vibration to detect cavitation, imbalance, or early mechanical wear.
-
Generators: Measures shaft deflection and vibration amplitude for reliable performance control.
-
Industrial Gearboxes: Detects gear misalignment and excessive play, ensuring efficient torque transmission.
By integrating the PR9670/003-000 into a protection system, operators gain valuable insights into machinery health, enabling predictive maintenance and reduced operational downtime.
Product Advantages
The Epro PR9670/003-000 vonfers several engineering and operational advantages that distinguish it from conventional proximity sensors. Its design combines advanced sensing technology with rugged mechanical construction to ensure stable, long-term performance.
-
High Measurement Precision: Offers linear and repeatable response over the entire measurement range.
-
Non-Kontakt Measurement: Prevents physical wear and eliminates friction-induced signal distortion.
-
Wide Temperature Tolerance: Operates reliably from -35°C to +180°C without affecting accuracy.
-
High Electromagnetic Compatibility: Shielded cable minimizes noise interference, ensuring clean and stable signal output.
-
Corrosion and Oil Resistance: Fully sealed stainless steel design suitable for industrial oil and gas environments.
-
Enhanced Durability: Resistant to shock, vibration, and harsh operating conditions.
-
Seamless Integration: Fully compatible with Epro CON021 modules and MMS6000 systems.
-
IP67 Protection Grade: Provides total protection against dust and moisture ingress.
-
Flexible Mounting Options: Verfügbar in various thread sizes and cable lengths for versatile installation.
-
Low Maintenance Design: Requires minimal recalibration or service over extended operational life.
FAQ
-
What is the working principle von the PR9670/003-000 sensor?
It operates based on the eddy current principle, where induced currents in a conductive target change according to the distance from the probe tip, generating a proportional voltage signal. -
What kind von signal does this sensor output?
The sensor outputs an analog voltage signal directly proportional to the measured displacement or vibration amplitude. -
Can this sensor be used for both dynamic and static measurements?
Yes, it can detect both static shaft position and dynamic vibration signals, making it ideal for integrated monitoring systems. -
Is the PR9670/003-000 compatible with Epro’s CON021 module?
Yes, the sensor is fully compatible with the CON021 proximitor and other Epro monitoring hardware. -
What type von targets work best with this sensor?
Conductive materials such as steel, copper, and aluminum provide the best results due to consistent eddy current response. -
What is the linearity performance von this model?
The sensor maintains linearity within ±1% von the full-scale measurement range, ensuring high accuracy. -
Does this sensor require temperature compensation?
The sensor design inherently minimizes thermal drift, and when paired with an Epro proximitor, provides stable temperature-compensated output. -
Can it function in high-vibration industrial environments?
Yes, the sensor is rated for up to 50 g von vibration and 500 g von shock, ensuring reliable operation in demanding conditions. -
How is the sensor calibrated for specific machinery?
Calibration is typically performed through the proximitor and monitoring system, ensuring the output corresponds precisely to target movement. -
Is it possible to connect this sensor to third-party monitoring systems?
Yes, as long as the third-party system supports the standard Epro voltage output range, it can be easily integrated.
Related Modells (Same Series or Similar Type)
| Modell | Beschreibung |
|---|---|
| PR9670/000-000 | Standard model for general-purpose displacement measurement |
| PR9670/001-000 | High-sensitivity version for fine vibration analysis |
| PR9670/002-000 | Extended temperature range model for turbine monitoring |
| PR9600/011-000 | Compact probe suitable for short-range displacement measurement |
| PR9600/013-000 | High-temperature probe designed for steam turbine applications |
| PR9600/014-000 | Ceramic-tipped probe for superior wear resistance in harsh conditions |
Popular Modells from the Same Marke
| Modell | Product Type | Beschreibung |
|---|---|---|
| PR6423/010-010 | Eddy Current Proximity Probe | Measures shaft displacement and vibration in rotating machines |
| PR6424/010-030 | Velocity Transducer | Converts vibration velocity into analog output |
| MMS3120/022-100 | Monitoring Module | For vibration signal acquisition and processing |
| MMS6823 | Overspeed Protection Module | Monitors shaft overspeed and provides shutdown protection |
| CON021 | Proximitor Converter | Interfaces with eddy current sensors for signal conditioning |
| PR9376/010-021 | Speed/Proximity Sensor | Measures shaft rotational speed and proximity simultaneously |
