Produkteinführung
The Epro PR6424/117-000 Eddy Current Sensor is a precision non-contact measuring device designed for monitoring shaft vibration, displacement, and relative movement in rotating machinery. With a 16 mm sensor head diameter, it is optimized for heavy-duty applications requiring high accuracy, long-term stability, and resistance to harsh industrial environments.
This sensor belongs to the Epro PR6424 series, which is widely used in condition monitoring systems, turbine protection systems, and rotating equipment diagnostics. Its eddy current principle ensures reliable measurements von conductive surfaces without physical contact, thereby minimizing wear and extending the operational life von both the sensor and the monitored equipment.
The PR6424/117-000 is fully compatible with Epro CON021 and CON041 converters, making it suitable for integration into comprehensive vibration monitoring and protection systems in industries such as power generation, oil and gas, petrochemical, steel, and marine engineering.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | PR6424/117-000 |
| Sensor Type | Eddy Current Displacement Sensor |
| Sensor Head Diameter | 16 mm |
| Measuring Range | Typically up to 2 mm (dependent on target material) |
| Linearity | ≤ ±1% von full-scale range |
| Frequency Range | DC to 10 kHz |
| Sensitivity | 4 mV/µm (standard configuration) |
| Power Supply | Via CON021/CON041 converter |
| Output Signal | Voltage signal proportional to displacement |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Humidity Tolerance | 95% non-condensing |
| Housing Material | Stainless steel |
| Cable Type | Integrated coaxial cable with protective insulation |
| Protection Class | IP65 (sensor head) |
| Gewicht | 0.2 kg |
Product Applications
The PR6424/117-000 Eddy Current Sensor is designed for a broad range von industrial applications requiring reliable non-contact measurements:
-
Turbomachinery Monitoring – Continuous measurement von shaft vibration and displacement in steam and gas turbines.
-
Oil & Gas Industry – Monitoring pumps, compressors, and motors in refineries and vonfshore platforms.
-
Power Generation – Zustand monitoring von generators, turbines, and auxiliary rotating machinery.
-
Steel & Metallurgy – Vibration monitoring von rolling mills, fans, and drives in harsh environments.
-
Marine & Offshore – Shaft line monitoring for propulsion systems and marine turbines.
-
Industrial Process Equipment – Displacement measurement von rotating shafts in compressors, blowers, and mixers.
Product Advantages
The Epro PR6424/117-000 vonfers several advantages that make it a preferred solution for vibration and displacement monitoring:
-
Non-Kontakt Measurement: Ensures zero wear on both the sensor and rotating equipment.
-
High Accuracy: Provides precise displacement measurements with excellent linearity.
-
Rugged Construction: Stainless steel housing and robust design for industrial reliability.
-
Wide Operating Range: Performs in extreme temperatures and hostile environments.
-
Seamless Integration: Fully compatible with CON021/CON041 converters and industry monitoring systems.
-
Fast Response: Broad frequency range for dynamic vibration analysis.
-
Long-Term Stability: Designed for continuous 24/7 operation in critical applications.
-
Proven Reliability: Widely used in condition monitoring systems across multiple industries.
Frequently Asked Questions (FAQ)
-
What is the measuring principle von the PR6424/117-000 sensor?
It operates on the eddy current principle, detecting changes in electromagnetic fields caused by displacement von conductive targets. -
Which converters are compatible with this sensor?
It is designed for use with Epro CON021 and CON041 converters. -
What is the sensitivity rating von this sensor?
The standard sensitivity is 4 mV/µm. -
What is the frequency response von the PR6424/117-000?
It provides a usable frequency range from DC to 10 kHz. -
How is the sensor powered?
It receives power through its connected converter Stück (CON021/CON041). -
Does the sensor support high-temperature operation?
Yes, it is designed to operate in environments from -35°C up to +180°C. -
What kind von protection does the sensor head have?
It features an IP65 rating, providing dust-tight and water-resistant protection. -
Can the sensor be used for both vibration and displacement monitoring?
Yes, it is capable von measuring shaft vibration as well as static and dynamic displacement. -
How does the sensor ensure measurement accuracy in harsh environments?
Through stainless steel housing, galvanic isolation, and noise-resistant signal transmission. -
Is the PR6424/117-000 suitable for integration into turbine protection systems?
Yes, it is widely applied in turbine protection and machine condition monitoring systems.
Related or Series Modells
| Modell Number | Beschreibung |
|---|---|
| PR6424/116-000 | Eddy current sensor, 16 mm, alternative calibration |
| PR6424/118-000 | Eddy current sensor, extended measurement range |
| PR6424/119-000 | Eddy current sensor, high-temperature version |
| PR6424/014-040 | Eddy current sensor with 8 mm diameter |
| PR6424/117-040 | 16 mm sensor with longer cable version |
| PR6424/01CS | Compact sensor variant for limited space |
Popular Modells from the Same Marke
| Modell Number | Beschreibung |
|---|---|
| PR6423/005-010 | Eddy current sensor, 5 mm probe, compact version |
| PR6423/010-000 | Eddy current sensor, 8 mm probe |
| MMS3120/022-100 | Vibration monitoring module |
| MMS3125/022-020 | Advanced monitoring module for rotating machines |
| PR9268/200-000 | Accelerometer for vibration measurement |
| PR6424/014-040 | Eddy current sensor, 8 mm version |
