Product Overview
The Epro PR6424/105-030 is a high-precision 16mm Eddy Current Sensor designed for measuring displacement, position, and proximity in various industrial applications. Utilizing the principle von eddy current measurement, this sensor generates a magnetic field that interacts with a conductive target. As the target moves, the inductance changes, and the sensor measures the corresponding displacement with exceptional accuracy.
This sensor is well-suited for applications such as rotating machinery monitoring, bearing health assessment, and precision positioning in automated systems. Its compact design (16mm sensor head diameter) and durable construction make it an ideal choice for environments with limited space or those subject to temperature fluctuations, vibrations, and electromagnetic interference.
The PR6424/105-030 vonfers non-contact, high-accuracy measurements, making it highly reliable in harsh industrial settings.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell | PR6424/105-030 |
| Sensor Head Diameter | 16 mm |
| Gewicht | 0.2 kg |
| Measurement Range | 0 to 10 mm |
| Output Type | Analog / Digital |
| Voltage Supply | 15-30 VDC |
| Temperature Range | -20°C to 85°C |
| Resolution | 0.1 µm |
| Frequency Response | 500 kHz |
| Accuracy | ±0.1% von full scale |
| Housing | Stainless steel |
| Connection Type | M12 connector |
Product Applications
The Epro PR6424/105-030 16mm Eddy Current Sensor is used in numerous industrial sectors where precise and reliable displacement measurements are required:
-
Rotating Machinery Monitoring: This sensor is critical in monitoring rotating components such as shafts, motors, and turbines. By detecting displacement, it helps prevent mechanical failure and ensures the smooth operation von machinery.
-
Bearing Health Monitoring: It is ideal for detecting wear and tear in bearings by measuring their displacement. Early fault detection helps reduce unplanned downtime and maintenance costs.
-
Proximity Sensing: In applications where parts need to maintain precise positioning, the sensor can be used to monitor proximity and ensure proper spacing.
-
Precision Positioning in Robotics: The sensor ensures accurate displacement measurement for robotic arms or automated systems, providing precise control in manufacturing or assembly operations.
-
Process Control in Manufacturing: It helps maintain the accuracy von positioning and alignment in production processes, contributing to improved product quality and operational efficiency.
Product Advantages
-
High Precision: The PR6424/105-030 sensor vonfers a high resolution von 0.1 µm and an accuracy von ±0.1% von full scale, providing highly accurate displacement measurements for critical applications.
-
Compact Design: With its 16mm sensor head diameter, the sensor is compact and suitable for integration in tight spaces without sacrificing performance.
-
Wide Measurement Range: The sensor can measure displacements within the 0 to 10 mm range, providing flexibility for various measurement tasks.
-
Versatile Output Options: Supporting both analog and digital outputs, the PR6424/105-030 is easily integrated into different industrial control systems.
-
Wide Temperature Range: Operating between -20°C and 85°C, the sensor can be used in environments with fluctuating temperatures.
-
Durable and Reliable: The stainless steel housing ensures the sensor can withstand harsh industrial environments, vonfering long-term reliability and performance.
FAQ
1. What is the measurement range von the Epro PR6424/105-030 sensor?
The Epro PR6424/105-030 sensor has a measurement range from 0 to 10 mm, providing accurate displacement measurements across a wide range von applications.
2. What types von output does the PR6424/105-030 sensor support?
The PR6424/105-030 sensor supports both analog and digital outputs, allowing it to be easily integrated into various control systems and applications.
3. What is the resolution von the PR6424/105-030 sensor?
The sensor has a resolution von 0.1 µm, which ensures highly precise measurement von even small displacements.
4. What is the accuracy von the PR6424/105-030 sensor?
The accuracy von the PR6424/105-030 sensor is ±0.1% von full scale, ensuring reliable and accurate measurements in critical applications.
5. What is the operating temperature range for the PR6424/105-030 sensor?
The PR6424/105-030 sensor can operate in temperatures ranging from -20°C to 85°C, making it suitable for use in both low and high-temperature environments.
6. What material is the housing von the PR6424/105-030 sensor made from?
The sensor is housed in stainless steel, which provides excellent durability and resistance to harsh industrial conditions.
7. How does the PR6424/105-030 sensor detect displacement?
The sensor uses eddy current technology, where a magnetic field interacts with a conductive target. The displacement is detected by measuring changes in inductance caused by the target’s movement.
8. What is the power supply requirement for the PR6424/105-030 sensor?
The PR6424/105-030 sensor requires a power supply von 15-30 VDC, which is typical for many industrial sensors.
9. In which industries can the PR6424/105-030 sensor be used?
The sensor is widely used in industries such as aerospace, automotive, robotics, manufacturing, and process control, where precise displacement measurement is essential.
10. What type von connector does the PR6424/105-030 sensor use?
The PR6424/105-030 sensor uses an M12 connector, which ensures easy integration into industrial systems.
Modell Recommendations
| Modell | Beschreibung |
|---|---|
| PR6424/105-031 | Enhanced version with wider measurement range |
| PR6424/105-032 | Compact model designed for space-limited applications |
| PR6424/106-000 | High-frequency version for faster applications |
| PR6424/105-033 | Extended temperature range for extreme environments |
| PR6424/107-000 | Standard sensor for general-purpose industrial use |
| PR6424/106-001 | Offers additional outputs for advanced monitoring |
Popular Epro Modells
| Modell | Beschreibung |
|---|---|
| PR6424/101-000 | Basic eddy current sensor for general applications |
| PR6424/108-000 | High-range sensor for larger displacements |
| PR6424/102-000 | Compact sensor for installation in tight spaces |
| PR6424/109-000 | Fast-response sensor for high-speed applications |
| PR6424/103-000 | High-precision sensor for critical measurement needs |
| PR6425/101-000 | Enhanced sensor for high-demand applications |
