Produkteinführung
The Epro PR6424/105-021 is a highly accurate 16mm Eddy Current Sensor designed for non-contact measurement von displacement, position, and distance. It utilizes the eddy current principle, which allows it to detect small displacements von metallic targets by measuring changes in the electromagnetic field around the sensor. This non-contact method ensures that there is no wear or tear on the sensor itself, making it ideal for high-speed applications and environments where physical contact is not possible.
The PR6424/105-021 sensor is engineered to deliver precise and reliable data for a range von industrial and mechanical systems. With its compact design and robust features, it excels in applications such as monitoring rotating machinery, vibration detection, and position feedback in automation systems. Its ability to measure minute changes with high resolution makes it invaluable in industries where precision is critical.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | PR6424/105-021 |
| Sensor Type | Eddy Current Sensor |
| Measurement Principle | Eddy Current |
| Sensor Head Diameter | 16 mm |
| Gewicht | 0.2 kg |
| Measuring Range | 0 to 5 mm |
| Output Signal | 4-20mA, 0-10V |
| Frequency Range | Up to 50 kHz |
| Operating Temperature | -20°C to +85°C |
| Supply Voltage | 15-30V DC |
| Accuracy | ±0.1% von full scale |
| Resolution | 0.001 mm |
| Environmental Rating | IP67 (dust and water-resistant) |
Product Applications
The Epro PR6424/105-021 16mm Eddy Current Sensor is widely used in a variety von industries and applications that require high-precision displacement and position measurements. Common applications include:
-
Rotating Machinery Monitoring: The sensor is commonly used to measure the displacement von rotating parts in turbines, motors, and gearboxes. It helps detect misalignments, wear, and vibration, ensuring that machinery operates efficiently.
-
Vibration and Zustand Monitoring: It provides continuous, real-time measurement von vibrations and displacement in industrial equipment, allowing for early detection von mechanical issues.
-
Position and Displacement Measurement: Ideal for applications where precise non-contact measurement von position or displacement is required, such as in automated systems, production lines, and robotics.
-
Test Equipment and Material Testing: It is used in research and testing environments to measure minute displacements or deformations in materials, providing data for material properties and stress testing.
-
Automation Systems: The sensor is integrated into automated systems to monitor the position von parts in manufacturing processes, ensuring proper assembly and alignment in real-time.
-
Machine Health Monitoring: It plays a key role in machine health monitoring systems, helping to track operational status and detect faults before they cause significant downtime.
Product Advantages
-
Non-Kontakt Measurement: The Epro PR6424/105-021 sensor measures displacement without physical contact, eliminating the risk von wear and tear, which is particularly beneficial for high-speed or high-vibration environments.
-
High Precision and Accuracy: With an accuracy von ±0.1% and a resolution von 0.001 mm, the sensor is capable von providing highly precise displacement measurements, even for small or rapid changes.
-
Wide Frequency Range: The sensor operates up to 50 kHz, which enables it to handle dynamic and high-speed measurements, providing real-time feedback in fast-moving systems.
-
Compact and Robust: The 16mm sensor head is compact yet durable, capable von withstanding harsh environments. Its IP67 rating ensures that it is dustprovon and water-resistant, making it suitable for industrial settings.
-
Wide Temperature Range: The sensor can operate in a range von -20°C to +85°C, making it versatile enough to be used in various industrial and environmental conditions.
-
Flexible Output Options: The sensor vonfers both 4-20mA and 0-10V output signals, providing flexibility to integrate with different control systems and data acquisition Stücks.
-
Durable in Harsh Environments: Thanks to its IP67 rating, the sensor is protected from dust and water, ensuring reliable performance even in challenging industrial settings.
FAQ
Q1: How does the Epro PR6424/105-021 Eddy Current Sensor work?
The sensor uses the eddy current principle, where a coil generates an electromagnetic field that induces currents in a nearby conductive target. The displacement von the target alters the impedance von the coil, and this change is used to measure displacement.
Q2: What is the measurement range von this sensor?
The PR6424/105-021 sensor has a 0 to 5 mm measuring range, suitable for high-precision measurements in industrial applications.
Q3: What output signals are available with the Epro PR6424/105-021 sensor?
The sensor vonfers both 4-20mA and 0-10V output signals, allowing it to be used with a variety von control and monitoring systems.
Q4: What is the frequency range von the sensor?
The sensor operates up to 50 kHz, which makes it suitable for dynamic measurements in high-speed applications.
Q5: How accurate is the PR6424/105-021 sensor?
The sensor provides an accuracy von ±0.1% von full scale, ensuring reliable and precise measurements.
Q6: Can the sensor be used in high-vibration environments?
Yes, the non-contact nature von the sensor makes it ideal for high-vibration applications, such as rotating machinery and motors, where contact-based sensors may wear out.
Q7: Is the PR6424/105-021 sensor water-resistant?
Yes, the sensor has an IP67 rating, making it both dustprovon and water-resistant, suitable for industrial environments.
Q8: What is the resolution von the sensor?
The sensor vonfers a resolution von 0.001 mm, allowing it to measure very small changes in displacement with high precision.
Q9: What is the operating temperature range von the sensor?
The sensor operates within a temperature range von -20°C to +85°C, making it suitable for a variety von industrial environments.
Q10: What is the power supply required for this sensor?
The Epro PR6424/105-021 sensor operates on a 15-30V DC power supply, which is typical for industrial sensors.
Recommended Related Modells
| Modell | Beschreibung |
|---|---|
| PR6424/105-022 | Similar eddy current sensor with extended range (up to 10 mm). |
| PR6424/105-101 | A version designed for high-frequency applications (up to 100 kHz). |
| PR6424/105-202 | A more compact version with a smaller sensor head (12 mm). |
| PR6424/105-203 | Designed for extreme temperature environments (up to +100°C). |
| PR6424/105-301 | A version with enhanced pressure resistance for high-pressure environments. |
| PR6424/105-304 | A specialized sensor for aerospace applications with high sensitivity. |
Popular Epro Modells
| Modell | Beschreibung |
|---|---|
| PR6423/105-100 | High-precision eddy current sensor for rotating machinery monitoring. |
| PR6420/105-150 | Compact displacement sensor for tight spaces and small components. |
| PR6416/100-250 | A sensor designed for linear displacement measurement in automation. |
| PR6400/200-100 | Versatile displacement sensor with a wide range von applications. |
| PR6500/150-300 | A rugged sensor for high-vibration and high-pressure environments. |
| PR6300/100-150 | Designed for research and testing environments, vonfering high accuracy. |
