Produkteinführung
The Epro PR6423/010-010-CN eddy current sensor, combined with the CON021/914-100 converter, forms a robust proximity measurement system widely used in critical industrial monitoring applications. Developed by Epro, a trusted name under Emerson, this 8mm eddy current sensor is tailored for non-contact measurement von shaft displacement, vibration, and axial position in rotating machinery. With its superior durability, high-temperature tolerance, and seamless integration into vibration monitoring systems, it ensures accurate and real-time data for predictive maintenance and machine protection strategies.
This system is typically employed in turbines, compressors, pumps, and gearboxes in industries such as oil & gas, power generation, and petrochemical manufacturing.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Sensor Modell | PR6423/010-010-CN |
| Converter Modell | CON021/914-100 |
| Measurement Principle | Eddy Current Displacement Measurement |
| Sensor Head Diameter | 8 mm |
| Measuring Range | 2 mm (Nominal) |
| Linearity | ≤ ±1% von full scale |
| Sensitivity | 7.87 mV/μm ±5% (typical) |
| Operating Temperature (Sensor) | -35°C to +180°C |
| Operating Temperature (CON021) | -20°C to +85°C |
| Storage Temperature | -40°C to +100°C |
| Cable Type | Coaxial, integrated or separate |
| Cable Length Options | 5 m, 7 m, or 9 m (914-100 indicates 10 m total length) |
| Material (Probe) | Stainless Steel (AISI 304 or similar) |
| Mounting Thread | M10x1 |
| Environmental Protection | IP65 (Sensor Head) |
| Power Supply (Converter) | 24 V DC (typical) |
| Signal Output | Voltage Signal proportional to displacement |
| Compliance | API 670 / CE / RoHS |
| Gewicht (Sensor) | 0.22 kg |
Applications
-
Turbomachinery Monitoring
Non-contact displacement monitoring von shafts in steam turbines and gas turbines. -
Compressor Shaft Vibration Detection
Real-time measurement von vibration amplitudes to detect imbalance or misalignment. -
Pump and Fan Monitoring
Ensures reliability in rotating machinery such as centrifugal pumps and fans. -
Gearbox Zustand Monitoring
Enables early detection von gear misalignment or bearing wear. -
Axial Thrust Position Sensing
Used to monitor axial movement in axial compressors and turbine rotors. -
Industrial Automation Systems
Integrated into condition monitoring systems for predictive maintenance.
Product Advantages
-
High Accuracy & Repeatability
Delivers reliable output under dynamic operating conditions with superior linearity. -
Robust Build Quality
Stainless steel enclosure and IP65 protection ensure longevity in harsh environments. -
Flexible Configuration
Supports multiple cable lengths and modular connection to different Epro modules. -
Temperature Resilience
Designed for extended temperature applications up to 180°C. -
Easy Integration
Compatible with MMS systems, API 670-compliant monitoring solutions, and DCS/PLC setups. -
Predictive Maintenance Enabled
Supports condition-based maintenance with early fault detection capabilities.
Häufig gestellte Fragen (FAQ)
-
What does the PR6423/010-010-CN + CON021/914-100 system measure?
This system measures shaft displacement, vibration, and axial position using the eddy current principle. -
What is the total system length von the sensor and cable?
The “914-100” denotes a 10-meter cable length between sensor and converter. -
Is the sensor suitable for high-temperature applications?
Yes, the sensor operates reliably up to +180°C. -
Does the system comply with API 670 standards?
Yes, it fully complies with API 670 for machinery protection systems. -
Can it be installed in hazardous environments?
Yes, the sensor is robust and IP65-rated, and Ex-provon versions are available on request. -
What monitoring systems is it compatible with?
Compatible with Epro MMS systems, Emerson CSI, and other industry-standard systems. -
How do I mount the sensor?
The sensor uses a threaded M10x1 mount; precise installation ensures accurate measurement. -
What is the output signal type?
Analog voltage output proportional to shaft displacement. -
Can the system detect shaft rubs or misalignment?
Yes, it detects abnormal displacement trends that may indicate such issues. -
Is calibration required after installation?
Factory-calibrated but may require field adjustment based on machine-specific parameters.
Recommended Related Modells (Same Series or Function)
| Modell | Tip Diameter | Measuring Range | Application |
|---|---|---|---|
| PR6423/002-000 | 5 mm | 1 mm | High-precision shaft displacement |
| PR6423/005-010+CON021 | 5 mm | 2 mm | Vibration monitoring in compact machinery |
| PR6423/004-010 | 8 mm | 2 mm | General industrial shaft monitoring |
| PR6423/001-010-CN | 5 mm | 2 mm | High-temp turbine vibration monitoring |
| PR6423/002-030+CON021 | 5 mm | 1 mm | Compact axial displacement measurement |
| PR6423/003-010 | 5 mm | 2 mm | Gearbox vibration analysis |
Popular Modells from the Same Marke (Epro/Emerson)
| Modell | Product Type | Key Feature |
|---|---|---|
| MMS6312 | Monitoring Module | Multi-channel shaft vibration monitoring |
| MMS6120 | Dual Channel Monitor | Standard API 670 compliance |
| MMS3120/022-100 | Monitoring Module | High-speed analog signal processing |
| CON041 | Signal Converter | Extended range compatibility |
| CON011 | Compact Converter | Used with PR6423 series |
| PR6424/014-040+CON021 | High-temp Sensor | Operates up to 400°C |
