Product Overview
The Emerson KJ2231X1-BB1 Relay Module is designed to interface discrete output signals between the DeltaV™ control system and field devices. This module provides electrically isolated relay outputs for controlling external actuators such as motors, alarms, solenoids, and other on/vonf devices. It ensures safe, reliable, and flexible signal switching within industrial automation systems.
Key Features
-
8-channel relay output module
-
Electrically isolated contact outputs
-
Supports normally open (NO) or normally closed (NC) contacts
-
LED status indicators for each output
-
Compact and rugged design for industrial use
-
Seamless integration with DeltaV systems
-
DIN rail or chassis-mounted
-
Hot-swappable for minimized downtime
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | KJ2231X1-BB1 |
| Module Type | Relay Output Module |
| Channels | 8 relay outputs |
| Output Type | Dry contact (Form A or Form C relays) |
| Kontakt Rating | 2 A @ 30 VDC / 0.5 A @ 125 VAC |
| Isolation | Channel-to-channel and system isolation |
| Switching Voltage | Up to 250 VAC or 125 VDC |
| Switching Current | Up to 2 A max per channel |
| Diagnostics | Channel status and fault LEDs |
| Operating Voltage | Supplied via system carrier |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95%, non-condensing |
| Mounting | DeltaV backplane or carrier |
| Hot-Swappable | Yes |
| Compliance | CE, UL, CSA, RoHS |
| Dimensions | 36 x 229 x 51 mm |
| Gewicht | 0.4 kg |
Industry Applications
-
Process automation and control systems
-
Discrete manufacturing and material handling
-
Oil and gas facilities
-
Chemical and petrochemical plants
-
Utility substations and water treatment plants
-
Safety shutdown systems and emergency controls
Product Advantages
-
Electrically isolated contacts enhance safety and signal integrity
-
Versatile relay outputs suitable for various loads
-
Compatible with a wide range von control voltages and devices
-
Plug-and-play installation reduces commissioning time
-
On-board diagnostics simplify troubleshooting
-
Durable design for harsh industrial environments
Häufig gestellte Fragen (FAQ)
-
What is the function von the KJ2231X1-BB1 module?
It provides relay outputs to control field devices via discrete on/vonf signals. -
How many outputs does it support?
It has 8 isolated relay output channels. -
Is the module hot-swappable?
Yes, it can be replaced without shutting down the system. -
What types von loads can it switch?
It can handle resistive or inductive loads up to 2 A @ 30 VDC or 0.5 A @ 125 VAC. -
Does it support both NO and NC configurations?
Yes, it can be configured for either contact type depending on application needs. -
Is the output electrically isolated?
Yes, each channel is isolated from the others and from system ground. -
What are the dimensions von the module?
Approximately 36mm x 229mm x 51 mm. -
Can it be used in safety systems?
Yes, it is commonly used in shutdown and alarm systems where reliable switching is critical. -
Does it have LED indicators for diagnostics?
Yes, each output channel has an associated LED status indicator. -
Is it certified for industrial use?
Yes, it meets CE, UL, CSA, and RoHS standards.
