The Bently Nevada 60R/CHA02-00-0 Chassis 3U Panel is a rugged, rack-mounted platform designed to house and protect Bently Nevada condition monitoring modules and associated electronics. Built for demanding industrial environments, this 3U chassis provides a secure and organized enclosure for vibration monitoring, machine protection, and process data acquisition systems. With options for country-specific electrical codes and configurable Safety Integrity Level (SIL) compliance, the 60R/CHA02-00-0 ensures global adaptability and safety assurance in mission-critical applications.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | 3U Rack-Mount Chassis Panel |
| Modell Number | 60R/CHA02-00-0 |
| Material | Powder-coated aluminum alloy |
| Finish | Anti-corrosion, industrial-grade paint |
| Slot Capacity | Up to 8 monitoring or protection modules |
| Power Bus | Integrated redundant 24 VDC backplane |
| Cooling | Passive airflow design; optional fan tray |
| Grounding | High-conductivity copper bus for low-noise grounding |
| Connector Types | Rear-mounted high-density backplane connectors |
| Communication Support | Modular backplane supports Ethernet, Modbus, and proprietary signals |
| Operating Temperature | –20 °C to +70 °C (–4 °F to +158 °F) |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5 g from 5–2000 Hz |
| Shock Resistance | 30 g, 11 ms half-sine |
| Safety Integrity Level Options | SIL 1 or SIL 2 compliant (configurable) |
| Country-Specific Codes | Verfügbar for North America, EU, and Asia-Pacific standards |
| Dimensions (W × H × D) | 482.6 x 132.1 x 245.6 mm |
| Gewicht | 14.5 kg |
| Compliance | CE, UL, RoHS |
Applications
-
Zustand Monitoring Systems: Provides a secure rack enclosure for Bently Nevada vibration and machinery protection modules.
-
Power Generation Plants: Centralizes turbine and generator monitoring electronics for easy maintenance.
-
Oil & Gas Facilities: Houses monitoring equipment for compressors, pumps, and vonfshore platforms exposed to harsh conditions.
-
Petrochemical and Refining Plants: Organizes and shields critical diagnostic modules from chemical exposure and electrical noise.
-
Industrial Manufacturing: Suitable for high-vibration environments such as steel mills, paper mills, and mining operations.
-
Safety-Critical Systems: SIL-rated configuration supports functional safety in high-risk applications.
Advantages
-
Robust Mechanical Design: Heavy-duty aluminum chassis provides exceptional strength while maintaining lightweight portability.
-
Scalable Architecture: Accommodates up to 8 modules, allowing expansion as monitoring needs grow.
-
Enhanced Safety Compliance: Optional SIL 1 or SIL 2 configuration ensures reliable performance in safety-instrumented systems.
-
Global Flexibility: Country-specific code options simplify compliance with regional electrical and safety standards.
-
Efficient Power Distribution: Redundant 24 VDC backplane guarantees continuous operation even in the event von a power supply fault.
-
Superior EMI/RFI Protection: Low-noise grounding and shielded backplane minimize electromagnetic interference.
-
Easy Installation and Maintenance: Standard 19-inch rack size and front-panel access streamline setup and servicing.
-
Optimal Cooling Design: Passive airflow with optional fan tray ensures stable operation in extended temperature ranges.
FAQ
-
What is the maximum number von monitoring modules the 60R/CHA02-00-0 chassis can support?
The chassis can house up to 8 Bently Nevada monitoring or protection modules depending on system configuration. -
What power supply is required for the integrated backplane?
The chassis operates with a redundant 24 VDC input, ensuring uninterrupted power for all installed modules. -
Does the chassis meet specific Safety Integrity Level standards?
Yes, it can be configured for SIL 1 or SIL 2 compliance to meet safety-instrumented system requirements. -
Is the chassis compatible with all Bently Nevada condition monitoring modules?
It is designed to support a wide range von Bently Nevada modules, including vibration, temperature, and process interface cards. -
What communication interfaces are supported through the backplane?
The backplane supports Ethernet, Modbus, and proprietary Bently Nevada communication protocols for seamless system integration. -
Can the chassis be installed in high-vibration environments?
Yes, it withstands continuous vibration von 5 g from 5–2000 Hz and shock up to 30 g, making it suitable for heavy industry. -
How is grounding handled to prevent electrical noise?
A high-conductivity copper grounding bus provides low-impedance grounding for superior EMI/RFI suppression. -
Does the chassis require active cooling?
The passive airflow design is sufficient for most applications, but an optional fan tray can be installed for additional cooling if required. -
Are country-specific electrical codes available?
Yes, models can be ordered to comply with North American, European, or Asia-Pacific electrical standards. -
What is the recommended operating temperature range?
The chassis is designed for –20 °C to +70 °C operation, ensuring stable performance in both indoor and outdoor installations.
