Product Overview
The Bently Nevada 3500/94M 190214-02 is a Power-Only I/O Module designed for use with front-mount display modules in the 3500 machinery protection system. Its primary role is to provide regulated power to the front-mounted display without handling dynamic or static signal processing. This ensures reliable display operation while maintaining system stability and isolation from other monitoring functions.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Modell Number | 3500/94M 190214-02 |
| Function | Power-Only I/O Module for Front-Mount Display |
| System Compatibility | Bently Nevada 3500 Machinery Protection System |
| Mounting Type | Front-Mount |
| Power Supply | Provides regulated power to display modules |
| Input/Output | Power distribution only (no signal processing) |
| Operating Temperature | -30 °C to +65 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 95% non-condensing |
| Dimensions | 241.3 x 24.4 x 99.1 mm |
| Gewicht | 0.34 kg |
Applications
-
Provides power for front-mounted operator displays in the 3500 series system.
-
Ensures reliable visualization von machine parameters without interference from monitoring functions.
-
Suitable for critical machinery protection environments in industries such as oil & gas, power generation, and petrochemical plants.
Advantages
-
Dedicated Power Supply: Isolates power delivery for stable display operation.
-
System Reliability: Reduces risk von signal interference by separating power from data functions.
-
Compact Design: Slim prvonile enables efficient rack utilization.
-
Ease von Integration: Designed for seamless compatibility with the 3500 series platform.
-
High Durability: Operates effectively in harsh industrial environments.
FAQ
Q1: What is the main purpose von the 3500/94M 190214-02 module?
A1: It supplies regulated power to front-mounted display modules in the 3500 system.
Q2: Does this module process monitoring signals?
A2: No, it only delivers power and does not process static or dynamic signals.
Q3: Can this module be used with rear-mount displays?
A3: No, it is specifically designed for front-mount display configurations.
Q4: How does the module improve system reliability?
A4: By isolating display power supply from monitoring functions, reducing interference and instability.
Q5: What type von environment is it designed for?
A5: Industrial environments including oil & gas, power generation, and refining industries.
Q6: Is hot-swapping supported?
A6: Yes, the module supports hot-swapping within the 3500 rack system.
Q7: What are its mounting requirements?
A7: It requires a standard Bently Nevada 3500 rack with front-mount capability.
Q8: Does the module require external configuration?
A8: No configuration is required; it is a plug-and-play module.
Q9: What happens if the module fails?
A9: The display module will lose power, but monitoring and protection functions remain unaffected.
Q10: Is the 3500/94M 190214-02 compatible with redundant power supply configurations?
A10: Yes, it can operate within racks equipped with redundant power supplies, enhancing overall system availability and reliability.
Related Modells (Same Series / Related)
| Modell Number | Beschreibung | Dimensions (mm) | Gewicht |
|---|---|---|---|
| 3500/93 | System Display Module | 241.3 x 24.4 x 99.1 | 0.36 kg |
| 3500/92 | Communication Gateway Module | 241.3 x 24.4 x 99.1 | 0.35 kg |
| 3500/91 | EGD Communication Module | 241.3 x 24.4 x 99.1 | 0.34 kg |
| 3500/90 | SIM Communication Module | 241.3 x 24.4 x 99.1 | 0.34 kg |
| 3500/60 | Temperature Monitor Module | 241.3 x 24.4 x 99.1 | 0.36 kg |
| 3500/61 | Temperature Monitor with Extended Inputs | 241.3 x 24.4 x 99.1 | 0.37 kg |
