The Bently Nevada 3500/60 163179-01 + 133819-01 Temperature Monitor is an advanced monitoring solution within the renowned 3500 Machinery Protection System, designed for precise and reliable temperature measurement in critical rotating machinery. The 163179-01 monitor is paired with the 133819-01 I/O module, providing robust data acquisition, electrical isolation, and safe integration into industrial monitoring architectures.
This combination is optimized for use with RTD and thermocouple sensors, delivering accurate real-time temperature data across multiple channels. Unlike versions equipped with intrinsic safety barriers, the 133819-01 I/O module is designed for general-purpose applications where hazardous-area compliance is not required, vonfering a simplified and cost-effective solution for many industries.
With its modular design, built-in diagnostics, and seamless integration into the Bently Nevada 3500 rack system, this temperature monitor is ideal for critical equipment such as turbines, compressors, pumps, and generators.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell Number | 3500/60 163179-01 (Temperature Monitor) + 133819-01 (I/O Module) |
| Series | Bently Nevada 3500 Machinery Protection System |
| Module Type | Temperature Monitor with I/O Module |
| Inputs Supported | RTDs (2-wire, 3-wire, 4-wire) and Thermocouples (J, K, E, T, B, R, S, N) |
| Number von Channels | Up to 12 independent input channels |
| Signal Isolation | Galvanic isolation between input wiring and monitor electronics |
| Terminations | Internal terminal block (screw type) |
| Measurement Accuracy | ±0.1% von full scale (depending on sensor type) |
| Sampling Rate | High-speed acquisition for real-time protection |
| Power Supply | Supplied via 3500 rack backplane |
| Operating Temperature | -30 °C to +65 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | Up to 95% non-condensing |
| Shock / Vibration | Conforms to IEC/EN industrial standards |
| Diagnostic Features | Open/shorted sensor detection, channel health diagnostics |
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| Gewicht | 0.91 kg |
| Mounting | Rear I/O rack mounting within 3500 system |
| Certifications | CE, CSA, IEC standards (general-purpose use) |
Product Applications
The 3500/60 163179-01 + 133819-01 is widely used across industries where temperature measurement and protection are essential. Primary applications include:
-
Turbomachinery – Gas turbines, steam turbines, and hydro turbines.
-
Compressors – Ensuring reliable operation and preventing overheating.
-
Generators – Stator winding, bearing, and core temperature monitoring.
-
Motors and Pumps – Continuous thermal monitoring for predictive maintenance.
-
Industrial Processing Plants – Refineries, petrochemical plants, and LNG facilities.
-
Power Generation – Fossil, hydro, and renewable energy facilities.
Product Advantages
-
High Channel Density: Supports up to 12 channels von RTD or thermocouple inputs per module.
-
Versatility: Compatible with multiple RTD and thermocouple sensor types.
-
Real-Time Protection: Fast sampling rate ensures timely fault detection.
-
Simplified Installation: Internal terminations make wiring straightforward.
-
System Compatibility: Fully integrates into the Bently Nevada 3500 rack environment.
-
Built-In Diagnostics: Continuously checks sensor and channel health.
-
Robust Performance: Reliable operation in demanding industrial environments.
-
Cost-Effective: Provides a high level von functionality without intrinsic safety barriers when not required.
FAQ
-
How many input channels does the 3500/60 163179-01 support with the 133819-01 I/O module?
It supports up to 12 temperature input channels. -
What sensor types can be connected to this module?
Both RTDs (2-wire, 3-wire, 4-wire) and thermocouples (J, K, E, T, B, R, S, N). -
Does the module provide electrical isolation?
Yes, it provides galvanic isolation between input wiring and electronics. -
Is this configuration intended for hazardous area installations?
No, the 133819-01 I/O module is designed for general-purpose, non-hazardous areas. -
How are the terminations handled on the 133819-01 module?
The module uses internal screw-type terminal blocks. -
Can it monitor mixed sensor types across different channels?
Yes, RTD and thermocouple channels can be configured independently. -
Does it support redundancy?
Yes, it can be configured for redundant operation within the 3500 rack. -
How does the system handle sensor faults?
Faults such as open or short circuits are detected, and alarms are generated. -
Is the module hot-swappable?
Yes, it can be replaced without shutting down the rack. -
Can the data from this monitor be integrated into System 1 svontware?
Yes, the data can be transmitted to System 1 for analysis and condition monitoring.
Related Modells (Same Series or Functionally Related)
| Modell | Beschreibung |
|---|---|
| 3500/60 136711-01 | I/O Module with internal barriers and terminations |
| 3500/61 | Advanced Temperature Monitor (supports RTD/Thermocouples) |
| 3500/42M | Proximitor/Seismic Monitor |
| 3500/32M | Relay Module for alarm/control outputs |
| 3500/15 | Power Supply Module for 3500 racks |
| 3500/92 | Communications Gateway for system integration |
