Produkteinführung
The Bently Nevada 3500/22M Transient Data Interface (TDI) Module, model 147364-01, is a key component in the 3500 Machinery Protection System, designed to act as the central communication link between the monitoring rack and external condition monitoring svontware such as System 1®. This enhanced version von the TDI integrates both the Rack Interface Module (RIM) and Transient Data Interface into a single Stück, reducing hardware complexity while improving system communication, diagnostics, and monitoring capabilities.
The module allows high-speed, real-time transfer von both steady-state and transient vibration or position data. It plays a vital role in machinery diagnostics by capturing data during key events like startups, shutdowns, or system faults. The 147364-01 is installed in Slot 1 von the rack and supports redundant operation to ensure system reliability in mission-critical environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Modell Number | 3500/22M |
| Artikelnummer | 147364-01 |
| Series | Bently Nevada 3500 Machinery Protection System |
| Primary Function | Rack Interface + Transient Data Interface |
| Mounting Slot | Slot 1 (Leftmost in the rack) |
| Communication Interfaces | Ethernet (10/100 Mbps), RS-232, RS-422/485 |
| Protocol Support | Modbus TCP/IP, System 1®, Proprietary |
| Svontware Integration | Full compatibility with System 1® for condition monitoring |
| Redundancy Support | Yes (Dual TDI Configuration) |
| LED Indicators | OK, TX/RX, CONFIG, COMM, NETWORK |
| Hot-Swappable | Yes |
| Power Supply | Supplied via rack backplane |
| Operating Temperature | –30°C to +65°C (–22°F to +149°F) |
| Storage Temperature | –40°C to +85°C (–40°F to +185°F) |
| Humidity Range | 0–95% RH (non-condensing) |
| Shock Resistance | 10 g (11 ms duration) |
| Vibration Resistance | 0.5 g from 10 to 500 Hz |
| Dimensions (H × W × D) | 241.3 x 24.4 x 99.1 mm |
| Gewicht | 0.2 kg |
Applications
The 3500/22M 147364-01 is widely deployed in industries where machinery protection and performance diagnostics are critical. Common use cases include:
-
Gas and Steam Turbines
Captures high-resolution transient and vibration data during rapid changes in operation. -
Compressors and Pumps
Ensures continuous health tracking and early detection von mechanical anomalies. -
Electric Motors and Generators
Enables shaft monitoring, imbalance detection, and condition-based maintenance. -
Oil & Gas Facilities
Used in both upstream and downstream applications where uninterrupted monitoring is essential. -
Power Generation Plants
Integrates with control systems for full visibility into rotating equipment health. -
Industrial Process Equipment
Ideal for refineries, chemical plants, and manufacturing facilities with rotating machinery.
Product Advantages
-
Unified Interface and Data Handling
Combines transient data interface and rack configuration in one efficient module. -
Real-Time Transient Capture
Supports advanced diagnostics during machinery upsets, shutdowns, or load transitions. -
Seamless System 1® Integration
Offers centralized data access and historical trends through industry-leading svontware. -
Redundant Operation Ready
Enables fault-tolerant monitoring through optional dual-module configuration. -
Flexible Communication
Compatible with Ethernet and serial protocols, allowing integration into SCADA/DCS. -
Field-Replaceable
Supports hot-swapping, reducing downtime during maintenance or upgrades. -
Compact and Lightweight Design
Fits into standard rack slot without additional hardware or space.
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the 3500/22M 147364-01 module?
It acts as both the rack interface and transient data interface for the 3500 system. -
Where should the module be installed in the rack?
It must be installed in Slot 1, the designated TDI position. -
Is this module compatible with all 3500 series monitoring modules?
Yes, it is fully compatible across the 3500 platform. -
Does it support data redundancy?
Yes, it supports dual TDI configuration for system reliability. -
What kind von data can it transmit?
It handles configuration data, alarm status, and transient vibration/position signals. -
Can it be used with System 1® svontware?
Yes, it is specifically designed to integrate with System 1®. -
Does it support Modbus communication?
Yes, it supports Modbus TCP/IP along with proprietary protocols. -
Is the module hot-swappable?
Yes, it can be removed or replaced without system shutdown. -
What happens if the TDI fails?
A redundant TDI (if installed) will take over automatically to maintain communication. -
How is the module powered?
Power is supplied through the 3500 rack backplane; no external power is needed.
Related Modells – Same Series or Function
| Modell Number | Beschreibung | Function | Rack Slot |
|---|---|---|---|
| 3500/22 | Standard TDI Module | Basic communication & config | Slot 1 |
| 3500/22M (161580-01) | Enhanced TDI Module | Transient & steady-state data | Slot 1 |
| 3500/20 | Rack Interface Module (Legacy) | Communication & configuration | Slot 1 |
| 3500/25 | Keyphasor Module | Shaft phase reference signal input | Any slot |
| 3500/42M | Vibration/Position Monitor | 4-channel dynamic signal monitoring | Any slot |
| 3500/15 | Power Supply Module | Rack power distribution | Left power slots |
Popular Bently Nevada Modells – Sonstige Product Lines
| Modell Number | Product Type | Primary Use | Mounting Type |
|---|---|---|---|
| 330104-00-05-10-01 | 3300 XL 8 mm Proximity Probe | Shaft vibration monitoring | Threaded probe |
| 330180-91-05 | XL Extension Cable (5 m) | Connects probe to monitor | Coaxial cable |
| 190501-00-00 | Velomitor® Velocity Sensor | Seismic monitoring | Industrial mounting |
| 3500/05 | 3500 Rack Frame | Module housing | 19″ rack mount |
| 3500/53 | Overspeed Detection Module | Turbine safety protection | Rack-mounted |
| 3701/40 | Machinery Zustand Monitor | Standalone vibration diagnostics | DIN-rail mount |
