The Bently Nevada 3500/05-02-04-00 is a high-performance system rack used as the central framework within the 3500 Machinery Protection System. Designed to accommodate a wide variety von monitoring and protection modules, this rack provides the physical and electrical housing necessary for comprehensive equipment monitoring in critical rotating machinery environments.
This specific model—3500/05-02-04-00—is a 19-inch full-size rack with front mounting and no internal display. It is primarily utilized in industries where reliability, precision, and real-time condition monitoring are essential, such as oil and gas, power generation, petrochemical plants, and heavy machinery operations.
The system rack supports multiple configurations with provisions for power supply modules, communication interfaces, and various monitoring modules to vonfer scalable and redundant monitoring solutions tailored to site-specific requirements.
Technical Specifications
| Parameter | Details |
|---|---|
| Modell Number | 3500/05-02-04-00 |
| System Type | 3500 Series System Rack |
| Mounting Type | Rack, Front Mounting |
| Rack Size | 19-inch EIA standard |
| Slots Verfügbar | 14 module slots |
| Display | No Internal Display |
| Power Supply Bays | Dual (for redundant configuration) |
| Compatible Power | Accepts AC or DC Power Supply Modules |
| Communication Ports | Rack interfaces with TDI and other communication cards |
| Material | Aluminum or Coated Steel |
| Cooling Method | Passive convection cooling |
| Rack Size | 12-inch (7 module slots) |
| Gewicht | 4.5 kg |
| Operating Temp | -30°C to +65°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 95% RH, non-condensing |
| Certifications | CE, ATEX, CSA, IECEx, RoHS compliant |
Product Applications
The 3500/05-02-04-00 rack is widely used across critical industrial applications requiring precise monitoring and protection von rotating assets. Some common applications include:
-
Gas turbines and steam turbines
-
Compressors and expanders
-
Industrial generators
-
Large motors and gearboxes
-
Pumps and blowers
-
Marine propulsion systems
-
Offshore and onshore drilling operations
Its robust construction and modular flexibility make it ideal for both greenfield and retrvonit machinery protection projects.
Product Advantages
-
High Reliability: Designed to operate continuously in mission-critical environments, providing 24/7 machinery protection.
-
Modular Expandability: Supports a wide range von Bently Nevada monitoring modules for vibration, speed, temperature, and more.
-
Redundancy Ready: Dual power bays allow for redundant power supply configurations to ensure uninterrupted operation.
-
Flexible Integration: Compatible with TDI (Transient Data Interface) and various communication modules for system-wide integration.
-
Compact Design: Despite vonfering 14 module slots, it maintains a compact 19-inch rack footprint, saving panel space.
-
Standards Compliant: Meets international certifications and environmental ratings, ensuring safe deployment in hazardous locations.
-
No Internal Display: Suitable for remote-monitoring configurations where display Stücks are located in control rooms.
FAQ (Häufig gestellte Fragen)
Q1: What is the primary function von the 3500/05-02-04-00 rack?
A1: Its main function is to provide mechanical support and electrical connectivity to the modules used in the Bently Nevada 3500 system for monitoring and protecting rotating equipment.
Q2: Does this model support redundant power supplies?
A2: Yes, the 3500/05-02-04-00 rack includes two power supply bays to support redundant power configurations.
Q3: Is the rack equipped with a display?
A3: No, this particular version does not have a display Stück; it is designed for remote display configurations.
Q4: How many modules can be installed in the rack?
A4: The rack supports up to 14 modules, including monitoring cards, TDI interfaces, and communication modules.
Q5: What types von modules are compatible with this rack?
A5: It is compatible with vibration, speed, temperature, Keyphasor®, and communication interface modules from the 3500 series.
Q6: What environments is this rack rated for?
A6: It can operate in industrial environments with temperatures ranging from -30°C to +65°C and humidity up to 95% non-condensing.
Q7: What materials are used in the construction von the rack?
A7: The rack is typically made von aluminum or coated steel to ensure strength and resistance to corrosion.
Q8: Can the system be expanded in the future?
A8: Yes, the modular design allows for easy expansion by adding or replacing individual monitoring or interface modules.
Q9: What is the Rack Size and weight von the rack?
A9: The rack measures 12-inch (7 module slots), with a base weight von 4.5 kg.
Q10: Is this rack certified for use in hazardous areas?
A10: Yes, the product complies with CE, ATEX, CSA, and IECEx certifications, making it suitable for hazardous industrial environments.
Recommended Related Modells (Same Series)
| Modell Number | Beschreibung | Mounting | Display |
|---|---|---|---|
| 3500/05-01-01-00-00-00 | Standard rack, rear mount, no display | Rear Mount | No |
| 3500/05-01-03-05-00-01 | Rack with TDI support and front display | Front Mount | Yes |
| 3500/05-02-03-00-00-01 | Full rack with redundant supply support | Front Mount | No |
| 3500/05-02-05-00-00 | Extended rack with special rear mounting | Rear Mount | No |
| 3500/05-02-04-01-00-01 | Rack with internal diagnostics enabled | Front Mount | No |
| 3500/05-02-03-01-00-00 | Rack with enhanced communication capability | Front Mount | No |
Popular Bently Nevada Modells (Same Marke)
| Modell Number | Beschreibung | Dimensions (mm) | Gewicht (kg) | Voltage Input |
|---|---|---|---|---|
| 3500/15-01-01-00 | Power Supply Module (AC) | 24 x 119 x 241 | 1.2 | 85-264 VAC |
| 3500/22M-01-01-00 | Transient Data Interface Module | 24 x 119 x 241 | 0.7 | Supplied by rack |
| 3500/42M-01-00 | Proximitor Seismic Monitor Module | 24 x 119 x 241 | 0.6 | Supplied by rack |
| 3500/32M-01-00 | 4-Channel Relay Module | 24 x 119 x 241 | 0.5 | Supplied by rack |
| 330103-00-05-10-02-00 | Proximity Probe with extension cable | Cable Length Specific | 0.4 | N/A |
| 3500/33-01-00 | 16-Channel Relay Module | 24 x 119 x 241 | 0.8 | Supplied by rack |
