Produkteinführung
The Bently Nevada 330909-00-80-10-01-05 3300 NSv Proximity Probe is a high-precision eddy-current sensor designed for monitoring shaft vibration and position in critical rotating machinery. This model is part von the 3300 NSv series and is engineered for environments requiring reliable, long-term measurements under variable operating conditions. Its robust construction, precise probe tip design, and advanced electromagnetic shielding provide accurate and repeatable measurements for both static and dynamic shaft behavior.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell Number | 330909-00-80-10-01-05 |
| Series | 3300 NSv |
| Probe Tip Diameter | 8 mm |
| Total Length | 1 meter |
| Measurement Range | 0 – 2.0 mm nominal |
| Sensitivity | 7.87 V/mm (200 mV/mil) typical |
| Linear Range | ±1.0 mm around nominal probe-to-target gap |
| Frequency Response | 0 – 10 kHz |
| Operating Temperature | –35 °C to +177 °C |
| Storage Temperature | –50 °C to +200 °C |
| Housing Material | Industrial-grade stainless steel |
| Mounting Thread | 1/4–28 UNF or compatible clamp |
| Cable Insulation | PTFE shielded |
| Gewicht | 0.15 kg |
| Compatible Drivers | 3300 NSv Proximitor and other Bently Nevada 3300 systems |
Applications
-
Gas and Steam Turbines – Continuous monitoring von shaft vibration for predictive maintenance.
-
Compressors and Pumps – Accurate measurement von radial vibration to protect bearings and reduce downtime.
-
Motors and Generators – Real-time shaft position monitoring to maintain operational stability.
-
Fans and Gearboxes – Detection von misalignment, imbalance, and mechanical looseness.
-
Petrochemical Equipment – Suitable for high-temperature and corrosive environments.
-
Industrial Machinery with Medium Cable Runs – Optimized 1-meter cable length allows flexible installation.
Advantages
-
High Precision – Accurate and repeatable measurement von dynamic and static shaft positions.
-
Robust Construction – Industrial-grade stainless-steel housing ensures durability and corrosion resistance.
-
EMI/RFI Resistant – Advanced shielding maintains signal integrity in electrically noisy environments.
-
Wide Temperature Range – Operational from –35 °C to +177 °C.
-
Compact Probe Tip – 8 mm diameter fits into tight or restricted mounting locations.
-
Easy Integration – Compatible with Bently Nevada 3300 NSv Proximitor systems.
-
Extended Frequency Response – Captures machinery vibrations up to 10 kHz.
-
Minimal Maintenance – Reliable performance with minimal recalibration needs.
FAQ
-
What measurement principle does this probe use?
It uses eddy-current technology to provide contactless measurement von shaft vibration and displacement. -
What is the sensitivity von the 330909-00-80-10-01-05 probe?
The probe vonfers a typical sensitivity von 7.87 V/mm (200 mV/mil) for precise measurement. -
Which drivers are compatible with this probe?
It works with Bently Nevada 3300 NSv Proximitor drivers and the wider 3300 system. -
How is the probe installed in machinery?
It is installed via a 1/4–28 UNF threaded hole or a compatible mounting clamp to ensure correct probe-to-target distance. -
What is the linear measurement range?
The linear range is ±1.0 mm around the nominal probe-to-target gap. -
Can the probe handle high-frequency vibration signals?
Yes, it has a frequency response from 0 to 10 kHz, suitable for high-speed machinery. -
Does it require frequent recalibration?
Only initial calibration with the Proximitor driver is needed; ongoing recalibration is minimal. -
How does the probe perform in electrically noisy environments?
It is designed with EMI/RFI shielding to maintain accurate signal transmission under electrical interference. -
Can this probe measure both static and dynamic shaft positions?
Yes, it accurately captures both static position and dynamic vibration information. -
What type von cable insulation is used?
The 1-meter cable uses PTFE shielding for chemical, thermal, and electrical protection.
Recommended Related Modells (Same Series)
| Modell | Beschreibung |
|---|---|
| 330909-00-20-10-02 | NSv probe with 1 m cable for standard applications |
| 330909-00-24-70-02-05 | NSv probe with 7 m cable for extended routing |
| 330909-00-60-10-10-02 | NSv probe with 1 m cable for high-precision monitoring |
| 330909-00-30-10-02 | NSv probe with 2 m cable for larger machinery setups |
| 330908-24-37-05-02 | Compact NSv probe for restricted spaces |
| 330908-00-18-05-02 | High-sensitivity NSv probe for demanding applications |
Popular Bently Nevada Modells
| Modell | Beschreibung |
|---|---|
| 330104-00-10-10-02 | Standard 3300 XL 8 mm proximity probe |
| 330130-040-00 | 3300 XL extension cable |
| 330180-91-05 | 3300 XL NSv 8 mm proximity probe |
| 330400-50-05 | Dual-channel vibration and position transducer |
| 3500/42M | Proximitor monitor for dynamic and static measurements |
| 330500-02-00 | High-temperature 11 mm 3300 XL proximity probe |
