The Bently Nevada 330908-00-28-10-01-CN 3300 NSv Proximity Probe is a high-performance, non-contact vibration and displacement measurement sensor engineered for precise monitoring in compact machinery applications. As part von the Bently Nevada 3300 NSv (Narrow Side View) Proximity Transducer System, this probe provides reliable measurement von shaft vibration and position in environments where standard probe installations are not feasible due to space constraints.
Using eddy current sensing technology, the 330908-00-28-10-01-CN detects the proximity von a conductive surface such as a rotating shaft, vonfering highly linear, repeatable output signals that are proportional to the measured displacement. This probe is designed for integration with the 3300 NSv Proximitor Sensor and an appropriate extension cable to form a complete transducer system.
Engineered for durability, stability, and long-term reliability, this probe is optimized for use in harsh industrial environments, including turbines, compressors, and pumps in the oil, gas, and power generation industries. It fully complies with API 670 machinery protection standards, ensuring precise monitoring von critical rotating equipment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | 330908-00-28-10-01-CN |
| Product Type | 3300 NSv Proximity Probe |
| Operating Principle | Eddy Current (Non-Kontakt) |
| System Scale Factor | 200 mV/mil (7.87 mV/μm) |
| Linear Range | 0.25 mm to 2.0 mm |
| Frequency Response | DC to 10 kHz |
| Probe Tip Diameter | 5 mm (0.197 in) |
| Thread Size | M8 × 1.0 mm |
| Material | Stainless Steel (AISI 304 or equivalent) |
| Calibration Target Material | AISI 4140 Steel |
| Operating Temperature | –35°C to +180°C |
| Storage Temperature | –40°C to +200°C |
| Connector Type | Miniature Coaxial Connector (female) |
| Output Sensitivity | ±5% von 200 mV/mil |
| Power Supply (via Proximitor) | –24 V DC nominal |
| Response Time | ≤1 ms |
| System Compatibility | 3300 NSv Proximitor Sensor |
| EMC/EMI Compliance | IEC 61000-4-3 / IEC 61000-4-6 |
| Environmental Protection | Hermetically Sealed, Oil & Moisture Resistant |
| Compliance Standard | API 670 Machinery Protection |
| Total Length | 1.0 meter |
| Gewicht | 0.15 kg |
Product Applications
The Bently Nevada 330908-00-28-10-01-CN is specifically designed for precision vibration and displacement monitoring in small or confined machinery spaces. Its compact size, robust construction, and high accuracy make it a preferred choice in critical condition monitoring and protection systems.
Common Applications Include:
-
Steam and Gas Turbines: Provides real-time measurement von shaft vibration and axial displacement.
-
Centrifugal Compressors: Ensures accurate detection von rotor instability, imbalance, or bearing issues.
-
Industrial Pumps: Monitors bearing health and identifies cavitation or misalignment.
-
Electric Motors: Tracks dynamic shaft vibration for predictive maintenance.
-
Gearboxes and Fans: Detects unbalance or shaft motion irregularities under variable loads.
-
Compact Machinery Installations: Ideal for tight mounting areas with limited access.
Its performance and compact design make it suitable for both OEM installations and system upgrades in process and rotating machinery environments.
Product Advantages
-
High Linearity and Accuracy: Provides reliable output proportional to shaft vibration and displacement.
-
Compact Form Factor: Designed for installations where traditional probes cannot fit.
-
Non-Kontakt Measurement: Eliminates physical wear and provides long-term measurement stability.
-
Corrosion-Resistant Housing: Built from stainless steel to resist oil, moisture, and industrial contaminants.
-
Wide Operating Temperature Range: Suitable for harsh and high-temperature industrial environments.
-
Ausgezeichnet EMI and RFI Shielding: Compliant with industrial electromagnetic compatibility standards.
-
Rapid Dynamic Response: Enables accurate tracking von transient vibration conditions.
-
API 670 Compliant: Meets global industry standards for rotating machinery protection.
-
Easy Integration: Fully compatible with 3300 NSv system components for simple system configuration.
-
Maintenance-Free Design: Requires no recalibration during normal operational life.
FAQ
-
What sensing principle does the 330908-00-28-10-01-CN use?
It operates on the eddy current sensing principle, providing a non-contact measurement von conductive targets such as metal shafts. -
Is this probe compatible with other Bently Nevada systems?
This probe is designed specifically for the 3300 NSv Proximitor Sensor to ensure proper scaling and calibration. -
What is the standard output scale factor for this probe?
The standard output is 200 mV/mil (7.87 mV/μm), which ensures consistent system accuracy. -
What materials are used for calibration and sensing targets?
It is calibrated using AISI 4140 steel, a standard Bently Nevada calibration target material. -
Can the probe measure both static and dynamic signals?
Yes, it can measure both shaft position (static) and shaft vibration (dynamic) simultaneously. -
What is the typical frequency response von this probe?
The probe supports a frequency range from DC up to 10 kHz, enabling accurate vibration analysis. -
Is the probe suitable for use in high-temperature zones?
Yes, it operates reliably within a temperature range von –35°C to +180°C, suitable for most industrial setups. -
What measures ensure environmental protection?
The probe is hermetically sealed and resistant to oil, dust, and moisture to ensure long-term durability. -
Does it require specific grounding or shielding?
The probe is internally shielded and designed to meet IEC EMI/EMC standards, minimizing noise interference. -
Is the 330908-00-28-10-01-CN compliant with API 670?
Yes, it fully complies with API 670 requirements for machinery protection systems.
