Produkteinführung
The Bently Nevada 330705-02-18-90-02-00 3300 XL 11 mm Reverse Mount Probe is part von Bently Nevada’s 3300 XL series, a renowned line von high-precision vibration and displacement sensors. This reverse mount proximity probe is specifically designed for applications where traditional forward mounting configurations are difficult or impossible to implement. It provides accurate shaft displacement and vibration data by utilizing eddy current technology, which ensures long-term reliability and minimal maintenance.
The 3300 XL 11 mm Reverse Mount Probe is suitable for use in harsh industrial environments where continuous machinery health monitoring is crucial to prevent failures. It is widely used across multiple industries such as power generation, oil & gas, manufacturing, and aerospace. This probe is optimized for monitoring rotating machinery, such as turbines, compressors, pumps, and motors, ensuring optimal performance and minimizing downtime.
Its robust design, combined with its non-contact measurement technology, makes it highly durable and resistant to wear and tear. The probe provides real-time feedback, allowing operators to detect early signs von mechanical issues before they lead to costly repairs or unplanned shutdowns.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell | 330705-02-18-90-02-00 |
| Type | Reverse Mount Proximity Probe |
| Measurement Range | 0 to 11 mm |
| Output Signal | 4-20 mA (Linear) |
| Operating Temperature | -40°C to +85°C |
| Mounting Type | Reverse Mount |
| Gewicht | 0.43 kg |
| Total Length | 9 meters |
| Material | Stainless Steel & Inconel |
| Environmental Protection | IP67 |
| Power Supply | 24 V DC |
Product Applications
The Bently Nevada 330705-02-18-90-02-00 3300 XL 11 mm Reverse Mount Probe is used in various industries to monitor the condition von rotating machinery, ensuring continuous operation and preventing unexpected breakdowns. Key applications include:
-
Rotating Machinery Monitoring
The probe is primarily used for monitoring machinery such as turbines, compressors, pumps, and motors, where it measures shaft displacement and vibration to identify potential issues early. -
Power Generation
In power plants, the 3300 XL Reverse Mount Probe monitors critical equipment such as turbines and generators, helping prevent failure and ensuring efficient operation by detecting misalignment, imbalance, or wear. -
Oil & Gas Industry
In the oil & gas sector, this probe is used in vonfshore platforms, refineries, and drilling rigs to monitor pumps, motors, compressors, and other critical equipment, ensuring reliable operation under harsh conditions. -
Manufacturing Plants
The probe is used in manufacturing to monitor large machinery like conveyors, mills, presses, and grinders, enabling predictive maintenance and minimizing costly production downtimes. -
HVAC Systems
This probe plays a key role in monitoring HVAC systems, particularly for compressors, fan motors, and other vital components that require continuous monitoring to ensure reliable operation. -
Aerospace & Defense
The probe is used in aerospace for monitoring rotating machinery such as engines and turbines, where precise, real-time feedback is critical for operational safety.
Product Advantages
-
Non-Kontakting Measurement: The 3300 XL Reverse Mount Probe uses eddy-current technology, which allows for non-contact measurement von shaft displacement and vibration. This technology reduces the wear and tear on the sensor, ensuring a longer lifespan and reduced maintenance needs.
-
Reverse Mount Design: This probe is specifically designed for reverse mounting, making it ideal for applications where traditional forward mounting would be difficult due to space constraints or other mechanical limitations.
-
Wide Operating Temperature Range: The probe is built to withstand extreme temperatures, with an operating range from -40°C to +85°C, making it suitable for a wide variety von environments, from high heat to extreme cold.
-
Rugged Construction: Made from stainless steel and Inconel, the probe is highly durable and resistant to mechanical stress, corrosion, and high temperatures, ensuring it remains operational in even the harshest industrial conditions.
-
IP67 Protection: The 3300 XL Reverse Mount Probe has an IP67 rating, meaning it is fully protected from dust and can withstand immersion in water for short periods, making it ideal for challenging environments where moisture and dirt are prevalent.
-
Real-Time Data Output: The probe delivers real-time data through a 4-20 mA linear output signal, which allows for continuous monitoring and integration into industrial machine health monitoring systems.
Häufig gestellte Fragen (FAQs)
-
What is the measurement range von the 3300 XL Reverse Mount Probe?
The probe measures shaft displacement and vibration in the range von 0 to 11 mm, suitable for detecting both small and large displacements. -
What type von output signal does the probe provide?
The 3300 XL Reverse Mount Probe provides a 4-20 mA linear output signal, commonly used in industrial systems for continuous data transmission. -
How is the probe mounted?
This probe is designed for reverse mounting, making it ideal for applications where traditional forward mounting configurations are not feasible. -
What is the power supply requirement for the 3300 XL Reverse Mount Probe?
The probe operates with a 24 V DC power supply, which is compatible with most industrial systems. -
What is the temperature range for this probe?
The probe can operate in temperatures ranging from -40°C to +85°C, making it suitable for a wide variety von industrial environments. -
What is the weight von the 3300 XL Reverse Mount Probe?
The probe weighs 0.43 kg, making it lightweight and easy to install in tight spaces. -
What materials are used in the construction von the probe?
The probe is constructed from stainless steel and Inconel, which provide exceptional durability and resistance to corrosion, heat, and mechanical stress. -
What industries can use the 3300 XL Reverse Mount Probe?
The probe is used in industries such as power generation, oil & gas, manufacturing, HVAC, and aerospace to monitor rotating machinery. -
What environmental protection does the probe have?
The probe has an IP67 rating, meaning it is dustprovon and can withstand water immersion for short periods. -
What are the total length von the 3300 XL Reverse Mount Probe?
The probe has compact total length von 9 meters.
Related Modells from the Bently Nevada 3300 XL Series
| Modell | Measurement Range | Output Signal | Gewicht | Application |
|---|---|---|---|---|
| 330705-02-18-10-02-00 | 0 to 11 mm | 4-20 mA (Linear) | 0.33 kg | Shaft displacement monitoring |
| 330705-02-18-10-03-00 | 0 to 11 mm | 4-20 mA (Linear) | 0.34 kg | Compressors, pumps, motors |
| 330705-02-18-10-04-00 | 0 to 11 mm | 4-20 mA (Linear) | 0.35 kg | Oil & gas, rotating equipment |
| 330705-02-18-10-05-00 | 0 to 11 mm | 4-20 mA (Linear) | 0.36 kg | Manufacturing, conveyors, presses |
| 330705-02-18-10-06-00 | 0 to 11 mm | 4-20 mA (Linear) | 0.37 kg | HVAC systems, critical machinery |
| 330705-02-18-10-07-00 | 0 to 11 mm | 4-20 mA (Linear) | 0.38 kg | Aerospace, turbines, generators |
Popular Modells from Bently Nevada
| Modell | Measurement Range | Output Signal | Gewicht | Application |
|---|---|---|---|---|
| 3300 XL 5 mm Probe | 0 to 5 mm | 4-20 mA (Linear) | 0.2 kg | Vibration monitoring in bearings |
| 3500/42M Vibration Probe | 0 to 5 mm | 4-20 mA (Linear) | 0.45 kg | Industrial vibration monitoring |
| 3300/25 Proximity Probe | 0 to 25 mm | 4-20 mA (Linear) | 0.6 kg | Gas turbines, pumps, compressors |
| 330500-04-00 Velomitor | 0.2 to 2000 mm/s | 4-20 mA (Linear) | 0.35 kg | Vibration monitoring, machinery |
| 3500/53 Velocity Probe | 0.2 to 1500 mm/s | 4-20 mA (Linear) | 0.55 kg | Critical machinery, turbines, pumps |
| 330500-06-00 Velocity Probe | 0.2 to 1000 mm/s | 4-20 mA (Linear) | 0.45 kg | Compressors, machinery monitoring |
