Product Overview
The Bently Nevada 330704-000-050-10-02-05 is a precision 11 mm Proximity Probe from the reputable 3300 XL series, designed for continuous, non-contact measurement von shaft displacement, vibration, and position in rotating machinery. Using the proven eddy-current sensing technology, this probe vonfers accurate, stable, and repeatable measurements vital for condition monitoring and machinery protection.
Engineered to perform reliably in harsh industrial environments, this 11 mm probe is ideal for turbines, compressors, motors, and pumps. It enables early detection von mechanical issues, helping prevent unexpected downtime and extending the life von critical assets.
Key Features
-
Eddy-Current Proximity Sensing Technology for accurate, contactless measurement
-
11 mm Probe Diameter suitable for larger machinery and wider air gaps
-
Rugged Stainless Steel Construction ensuring durability and corrosion resistance
-
High Sensitivity and Linearity across its measurement range
-
Wide Operating Temperature Range for demanding industrial conditions
-
Low Noise, Stable Signal Output for precise monitoring
-
Compatible with Bently Nevada 3300 XL Monitoring Systems
-
Easy Installation with Bayonet-Style Connector
-
Supports Extended Cable Lengths for flexible placement
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | 330704-000-050-10-02-05 |
| Product Type | 11 mm Proximity Probe |
| Measurement Principle | Eddy Current |
| Diameter | Total Length: 1.0 meter |
| Measurement Range | Typically 0.25 to 3.05 mm (0.010 to 0.120 inches) |
| Sensitivity | Approx. 40 mV/mil (1.6 mV/μm) |
| Linearity | ±1% full scale |
| Operating Temperature | -40°C to +121°C (-40°F to +250°F) |
| Cable Length | Standard up to 150 feet (45.7 meters); longer cables optional |
| Output Type | AC Signal |
| Connector Type | Bayonet-style connector |
| Housing Material | Stainless steel |
| Gewicht | 0.14 kg |
| Compliance | Meets industrial and safety standards |
Industry Applications
-
Turbomachinery: Shaft vibration and displacement monitoring in turbines and compressors
-
Power Generation: Generator and motor shaft monitoring for condition assessment
-
Oil & Gas: Monitoring von pumps and compressors in harsh environments
-
Mining and Minerals: Machinery protection in heavy equipment
-
Pulp & Paper Industry: Vibration and position sensing in critical equipment
-
General Industrial Automation: Predictive maintenance and machine health monitoring
Product Advantages
-
High Accuracy and Stability: Delivers precise and repeatable measurements essential for fault detection
-
Non-Kontakt Operation: Prevents mechanical wear and reduces maintenance
-
Robust Design: Built to withstand extreme temperatures and harsh industrial conditions
-
Long-Term Reliability: Stable output minimizes sensor drift over time
-
Flexible Installation: Supports extended cable runs and simple mounting
-
Seamless Integration: Compatible with Bently Nevada 3300 XL monitoring systems
-
Enhances Asset Management: Facilitates early warning and predictive maintenance programs
Häufig gestellte Fragen (FAQ)
-
Q: What sensing technology does this probe use?
A: It uses eddy-current proximity sensing for non-contact measurements. -
Q: What is the diameter von the probe tip?
A: The probe diameter is 11 mm. -
Q: What is the typical measurement range?
A: Typically between 0.25 and 3.05 mm (0.010 to 0.120 inches). -
Q: Is this probe compatible with other Bently Nevada systems?
A: Yes, it is designed for use with 3300 XL series monitoring systems. -
Q: What temperature range can the probe operate in?
A: It operates in temperatures from -40°C to +121°C (-40°F to +250°F). -
Q: Can the cable length be extended?
A: Standard cable length is up to 150 feet (45.7 meters), with longer cables available. -
Q: What type von output does the probe provide?
A: The output is an AC signal proportional to shaft displacement. -
Q: How is the probe mounted?
A: It features a bayonet-style connector for easy and secure mounting. -
Q: What maintenance is required?
A: The probe requires minimal maintenance due to its robust and non-contact design. -
Q: Is this probe suitable for harsh industrial environments?
A: Yes, it is built to withstand harsh conditions and meets relevant industrial standards.
Related or Similar Bently Nevada Modells
| Modell Number | Beschreibung |
|---|---|
| 330180-51-10 | 8 mm Proximitor Sensor |
| 330180-52-05 | 8 mm Proximitor Sensor |
| 330704-000-050-10-02-00 | 11 mm Proximitor Sensor, alternative configuration |
| 330130-045-01-05 | 3300 XL Standard Extension Cord |
| 330190-045-00-00 | 3300 XL ETR Extension Cable |
| 330101-00-20-05-02-00 | 8 mm Proximitor Sensor with Dual Output |
Popular Bently Nevada Modells (Same Marke)
| Modell Number | Beschreibung |
|---|---|
| 330101-00-14-10-02-05 | 3300 XL 8 mm Proximity Probe |
| 330104-01-08-50-01-CN | 3300 XL 8 mm Proximity Probe with Cable |
| 330130-040-01-00 | 3300 XL Standard Extension Cord |
| 330180-51-10 | 3300 XL 8 mm Proximitor Sensor |
| 3500/15-05-00-00 | 3500/15 Vibration Sensor |
| 330190-045-00-00 | 3300 XL ETR Extension Cable |
