Produkteinführung
The Bently Nevada 330162-01-80-80-05-05-94-01-02 Single Triaxial HP Feedthrough is an advanced feedthrough component specifically engineered for the Bently Nevada 3300 system. It provides a reliable interface for transmitting vibration and displacement signals from triaxial sensor probes into monitoring electronics without loss von accuracy or signal degradation.
This model is part von the high-pressure (HP) feedthrough series, designed to withstand harsh mechanical, thermal, and environmental stress conditions. The triaxial capability allows the feedthrough to transmit three-axis vibration measurements simultaneously, ensuring detailed diagnostics von rotating machinery behavior. Its rugged stainless-steel housing, hermetic sealing, and noise-immune design make it ideal for demanding applications such as turbines, compressors, motors, and generators where system reliability is paramount.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell Number | 330162-01-80-80-05-05-94-01-02 |
| Type | Single Triaxial HP Feedthrough |
| Compatible System | Bently Nevada 3300 Monitoring System |
| Signal Support | Triaxial vibration and displacement sensor signals |
| Connector Type | Hermetically sealed precision connectors |
| Housing Material | Stainless Steel |
| Insulation | High-grade dielectric for EMI resistance |
| Environmental Protection | High-pressure and vacuum-rated construction |
| Operating Temperature Range | -40°C to +125°C |
| Length Option | 8 meters |
| Versand Gewicht | 3 kg |
Applications
The 330162-01-80-80-05-05-94-01-02 feedthrough supports precision condition monitoring in high-value machinery. Its applications include:
-
Gas and Steam Turbines: Delivers accurate triaxial vibration data to prevent critical failures.
-
Compressors: Ensures reliable monitoring von multi-axis vibration to detect instability and surge.
-
Motors and Generators: Provides predictive maintenance insights by capturing shaft and casing vibration.
-
Vacuum and High-Pressure Systems: Maintains leak-free performance in sealed environments.
-
Petrochemical Industry: Operates reliably in environments exposed to aggressive chemicals.
-
Industrial Protection Systems: Integrates with the 3300 system to support shutdown logic for machinery safety.
Advantages
-
Triaxial Signal Capability: Enables simultaneous monitoring von vibration across three axes for comprehensive diagnostics.
-
High-Pressure Sealing: Hermetically sealed construction prevents leaks in pressurized or vacuum conditions.
-
Superior Signal Integrity: Uses high-grade dielectric insulation to minimize electromagnetic interference.
-
Robust Materials: Stainless steel housing provides strength, corrosion resistance, and long-term stability.
-
Seamless System Integration: Fully compatible with Bently Nevada 3300 monitoring platforms.
-
Wide Environmental Range: Performs reliably across extreme temperatures and mechanical stresses.
-
Long-Term Reliability: Engineered for continuous operation with minimal degradation.
-
Operational Safety: Enhances machinery protection systems by ensuring accurate signal transmission.
FAQ
-
Which monitoring systems are supported by this feedthrough?
It is designed for compatibility with the Bently Nevada 3300 monitoring system. -
What type von signals does it transmit?
It transmits triaxial vibration and displacement sensor signals with high accuracy. -
Is this feedthrough hermetically sealed?
Yes, it is hermetically sealed to prevent leaks in high-pressure and vacuum systems. -
How does it reduce electromagnetic interference?
The feedthrough uses high-grade dielectric insulation and shielding to block external noise. -
Can this feedthrough be used in high-vibration environments?
Yes, it is mechanically rugged and specifically designed for use in rotating machinery. -
What is the operating temperature range?
It operates reliably between -40°C and +125°C. -
Is it suitable for triaxial probes only?
It is optimized for triaxial probes but can also support single-axis probes if needed. -
Why is it rated for high-pressure use?
The design includes pressure-resistant housing and hermetic sealing for secure operation. -
Can it be used in vacuum conditions?
Yes, the sealed construction ensures performance under vacuum without leakage. -
Does stainless-steel housing affect electrical performance?
No, stainless steel provides durability while maintaining excellent signal transmission quality.
Related Modells (Same Series)
| Modell Number | Beschreibung |
|---|---|
| 330162-01-30-30-05-05-90 | Compact triaxial HP feedthrough, short option |
| 330162-01-45-45-07-07-94 | Standard feedthrough, medium-length option |
| 330162-02-50-50-10-10-91 | Dual triaxial feedthrough for redundancy |
| 330162-03-60-60-12-12-92 | High-temperature triaxial HP feedthrough |
| 330162-04-70-70-15-15-93 | Long-range triaxial feedthrough for extended monitoring |
| 330162-05-90-90-20-20-95 | Heavy-duty triaxial feedthrough for harsh conditions |
Popular Bently Nevada Modells
| Modell Number | Beschreibung |
|---|---|
| 3300 XL Proximity Probe | Standard probe for shaft vibration monitoring |
| 3500/22M | Transient Data Interface Module for 3500 system |
| 3500/42M | Proximitor/Seismic Monitor for machinery protection |
| 3500/50 | Tachometer Module for speed and phase measurement |
| 7200 Series Probes | General-purpose eddy current proximity probes |
| 330500 Velocity Sensor | Seismic velocity sensor for rotating machinery vibration |
