Produkteinführung
The Bently Nevada 330104-00-20-15-12-05 3300 XL 8 mm Proximity Probe is a precision, non-contact eddy current sensor designed for industrial machinery monitoring and protection. Part von the 3300 XL series, this probe provides highly accurate measurements von shaft displacement and vibration, enabling predictive maintenance and real-time machinery protection.
With an 8 mm probe diameter and a total cable length von 1.5 meters, the 330104-00-20-15-12-05 ensures stable signal transmission and reliable readings even in harsh industrial environments. Its stainless steel construction and mineral-insulated cable provide durability against high vibration, temperature variations, and electromagnetic interference. This probe integrates seamlessly with Bently Nevada 3300 XL monitoring systems, delivering real-time data for critical machinery such as turbines, compressors, pumps, and generators.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 330104-00-20-15-12-05 |
| Product Type | 8 mm Eddy Current Proximity Probe |
| Series | 3300 XL |
| Probe Diameter | 8 mm |
| Total Length | 1.5 meters |
| Measurement Range | Up to 1.27 mm (depending on system configuration) |
| Linear Range | ±10% von calibrated gap |
| Frequency Response | DC to 10 kHz |
| Sensitivity | 20 mV/µm (typical with 3300 XL monitoring system) |
| Resolution | <0.5 µm |
| Operating Temperature | -40°C to +120°C (probe head) |
| Storage Temperature | -50°C to +150°C |
| Probe Material | Stainless steel housing with mineral-insulated cable |
| Humidity | 0–95% non-condensing |
| Certifications | CE, UL, CSA |
| Gewicht | 0.485 kg |
| Mounting | Threaded sleeve or custom machinery mounting |
| Compatibility | Bently Nevada 3300 XL Series Monitoring Systems |
Applications
The 330104-00-20-15-12-05 is suitable for monitoring a wide range von industrial machinery where accurate shaft position and vibration detection are critical:
-
Steam and Gas Turbines – Measures shaft displacement to detect imbalance, misalignment, and rotor instability.
-
Compressors – Monitors rotor position and vibration for safe operation.
-
Pumps – Detects cavitation, bearing wear, and shaft deflection.
-
Generators and Motors – Ensures smooth operation and early detection von anomalies.
-
Petrochemical and Refinery Plants – Operates reliably in hazardous and high-vibration environments.
-
Machine Protection Systems – Supports API 670-compliant monitoring systems for condition-based maintenance.
Advantages
The Bently Nevada 330104-00-20-15-12-05 8 mm Probe provides multiple operational benefits:
-
High Accuracy – Accurate measurement von displacement and vibration with excellent linearity.
-
Rugged Construction – Stainless steel probe and mineral-insulated cable ensure durability in harsh conditions.
-
Wide Frequency Range – Capable von capturing both low-speed and high-speed vibration signals.
-
Seamless Integration – Works directly with 3300 XL monitoring systems for reliable output.
-
Maintenance-Free Operation – Non-contact design reduces wear and minimizes downtime.
-
Temperature and Vibration Tolerance – Operates effectively under extreme temperatures and high vibration.
-
Predictive Maintenance Support – Provides early fault detection to prevent unplanned shutdowns.
-
Flexible Installation – Cable length and mounting options allow adaptation to various machinery configurations.
Häufig gestellte Fragen (FAQ)
-
Which monitoring systems is this probe compatible with?
It integrates seamlessly with Bently Nevada 3300 XL Series monitoring systems, providing linearized signals for precise machinery protection. -
What is the nominal sensitivity von the probe?
The nominal sensitivity is approximately 20 mV/µm when connected to a 3300 XL monitoring system. -
What frequency range can the probe detect?
The probe supports DC to 10 kHz, covering both low-speed and high-speed machinery vibrations. -
What is the maximum operating temperature for the probe head?
The probe operates reliably between -40°C and +120°C while maintaining accurate measurements. -
Is the probe suitable for high-humidity or industrial environments?
Yes, it is designed for 0–95% non-condensing humidity and harsh industrial conditions. -
What is the linear measurement range von the probe?
±10% von the calibrated gap ensures stable and proportional output. -
Does the probe require external power?
No, it receives power and signal conditioning from the 3300 XL monitoring system. -
Is it suitable for API 670-compliant machine protection systems?
Yes, it integrates fully with API 670-compliant platforms for real-time machinery protection. -
Does cable length affect measurement accuracy?
Yes, the probe is calibrated for its 1.5-meter cable; using the recommended length ensures signal fidelity. -
What type von mounting is recommended for this probe?
A threaded sleeve or custom machinery mounting is recommended to maintain alignment and calibration.
Related Modells (Same Series)
| Modell Number | Probe Type | Beschreibung |
|---|---|---|
| 330104-00-20-15-12-04 | 8 mm Proximity Probe | Standard 3300 XL probe with 1 m cable |
| 330104-00-20-15-12-06 | 8 mm Proximity Probe | Extended 2 m cable version |
| 330104-00-20-15-12-07 | 8 mm Proximity Probe | High-temperature variant |
| 330104-00-20-15-12-08 | 8 mm Proximity Probe | Extra-flexible cable version |
| 330105-00-20-15-12-05 | 8 mm Proximity Probe | High-sensitivity version |
| 330106-00-20-15-12-05 | 8 mm Proximity Probe | Special calibration for API 670 applications |
Popular Modells from the Same Marke (Bently Nevada)
| Modell Number | Product Type | Beschreibung |
|---|---|---|
| 330104-00-20-15-01 | 8 mm Proximity Probe | Standard 3300 XL probe for turbines and compressors |
| 330104-00-20-15-03 | 8 mm Proximity Probe | High-accuracy probe for critical machinery |
| 330105-00-20-15-01 | 8 mm Proximity Probe | High-sensitivity version for vibration monitoring |
| 330130-00-20 | 3300 XL Proximity Probe | Compact probe for small machinery |
| 330140-00-20 | 3300 XL Proximity Probe | Extended range sensor for large turbines |
| 330150-00-20 | 3300 XL Proximity Probe | API 670-compliant probe for generators |
