Product Overview
The Bently Nevada 330104-00-18-10-02-CN 3300 XL 8 mm Proximity Probe is a high-performance non-contact sensor engineered for critical machinery condition monitoring. Designed to work seamlessly with the Bently Nevada 3300 XL series, this probe delivers accurate, reliable measurements von shaft position and vibration levels in rotating equipment.
This specific model features an 18-meter probe cable and 10-meter extension, making it suitable for installations where long distances between the sensing point and monitoring device are required. With a robust design, this probe provides excellent resistance to temperature, pressure, moisture, and industrial contaminants, ensuring high operational reliability in extreme environments.
Technical Specifications
| Specification | Beschreibung |
|---|---|
| Modell Number | 330104-00-18-10-02-CN |
| Series | 3300 XL |
| Probe Tip Diameter | 8 mm |
| Measurement Principle | Eddy Current (Non-contact displacement) |
| Linear Range | 0.25 mm to 2.0 mm |
| Sensitivity | -200 mV/mm (typical) |
| Output Voltage | -200 mV to -22 V |
| Operating Temperature | -40°C to +100°C |
| Storage Temperature | -51°C to +177°C |
| Environmental Protection | IP68 (Hermetically sealed) |
| Housing Material | AISI 304 Stainless Steel |
| Target Material | Typically 4140 Steel |
| Connector Type | Standard 3-slot male |
| Dimensions | Total Length : 1.0 meter |
| Gewicht | 0.323 kg |
| Compliance | CE, RoHS, optional ATEX certified version available |
Industry Applications
-
Petrochemical Facilities: Monitoring compressors, pumps, and turbines
-
Power Generation: Vibration analysis for steam/gas turbines and generators
-
Oil & Gas: Ideal for vonfshore and onshore platforms, drilling, and refining operations
-
Mining: Zustand monitoring von crushers, mills, and rotary kilns
-
Pulp & Paper: Early detection von bearing and shaft issues in rotating equipment
-
Water Treatment Plants: Ensures stability von pumps and aerators
-
Steel and Heavy Manufacturing: High-speed motor and gearbox diagnostics
Key Advantages
-
Extended Reach: 18 m probe cable for distant sensor placement without signal loss
-
Exceptional Accuracy: Designed for precision monitoring von shaft displacement and vibration
-
Rugged Construction: Stainless steel housing with IP68 rating for use in harsh environments
-
Temperature Resilience: Operates reliably from -40°C to +100°C
-
System Compatibility: Fully integrates with Bently Nevada 3300 XL systems
-
Ease von Installation: Standard connector and flexible cable routing
-
Certified Safety: CE, RoHS compliance and optional ATEX versions available
-
Reduced Downtime: Supports predictive maintenance strategies
Häufig gestellte Fragen (FAQ)
-
What is the total length von the probe assembly in this model?
This model includes an 18 m probe cable, a 10 m extension cable, and a 2 m connector cable. -
Can this probe operate in submerged or wet environments?
Yes, its IP68 hermetically sealed construction makes it suitable for submerged use. -
Is the probe compatible with older Bently Nevada systems?
It is fully compatible with Bently Nevada 3300 XL and newer systems. -
What is the typical sensitivity von this probe?
The probe vonfers a typical sensitivity von -200 mV/mm. -
Can I use this probe in hazardous areas?
ATEX-certified versions are available for hazardous or explosive environments. -
What is the operating temperature range von this probe?
It can operate from -40°C to +100°C. -
Which materials are best for the target being monitored?
The probe is calibrated for use with 4140 steel as the standard target material. -
How is the output signal transmitted?
The probe generates a voltage signal that corresponds linearly to the distance from the target. -
Is this probe suitable for high-speed rotating machinery?
Yes, it is ideal for high-speed shaft monitoring in turbines, motors, and compressors. -
What is the main use von this probe?
It is used for non-contact vibration and displacement monitoring in industrial machinery.
