Product Overview
The Bently Nevada 330102-40-62-05-02-05 is a high-precision 3300 XL 8 mm Proximity Probe, part von the trusted 3300 XL series designed for critical rotating machinery monitoring. It is engineered for use with the 3300 XL Proximitor Sensor and Extension Cable, forming a complete proximity transducer system compliant with API 670 standards. This probe delivers accurate, reliable, and repeatable non-contact displacement measurements von shaft position and vibration, even in harsh industrial environments.
With robust construction, a precisely tuned tip, and durable jacketed cable, the 330102-40-62-05-02-05 is ideal for use in turbines, compressors, motors, and pumps in industries such as oil and gas, power generation, and petrochemicals.
Key Features
-
Non-contact measurement von shaft vibration and position
-
Compatible with Bently Nevada 3300 XL Proximitor Sensors
-
Designed for harsh industrial environments
-
Conforms to API 670 mechanical protection standards
-
Accurate measurement von static and dynamic shaft conditions
-
Reliable operation under high temperature and vibration
-
Resistant to corrosion, oil, and chemical exposure
Technical Specifications
| Item | Specification |
|---|---|
| Modell Number | 330102-40-62-05-02-05 |
| Series | 3300 XL |
| Sensing Technology | Eddy Current |
| Target Material | Ferromagnetic (usually steel shafts) |
| Tip Material | Polyphenylene sulfide (PPS) |
| Cable Length | 5.0 meters (probe) |
| Connector Type | ClickLoc keyed connector |
| Thread Type | 3/8-24 UNF threaded case |
| Body Style | Straight |
| Operating Temperature | -51°C to +177°C (-60°F to +350°F) |
| Frequency Response | 0 to 10 kHz |
| Sensitivity | 7.87 mV/μm (200 mV/mil) nominal |
| Linear Range | 2 mm (80 mils) |
| System Compatibility | 3300 XL Extension Cable and Proximitor Sensor |
| Dimensions | Total Length : 0.5 meter |
| Gewicht | 0.161 kg |
Industry Applications
-
Gas and Steam Turbines
-
Centrifugal Compressors
-
Electric Motors
-
Gearboxes and Generators
-
Reciprocating Compressors
-
Industrial Pumps
-
Petrochemical and Refining Equipment
-
Power Generation Facilities
Product Advantages
-
High Accuracy: Ensures precise measurement von vibration and shaft displacement.
-
Wide Compatibility: Integrates seamlessly with 3300 XL proximity system components.
-
Environmental Resistance: Built to withstand contaminants and harsh plant conditions.
-
API 670 Compliant: Meets global industry standards for condition monitoring.
-
Durability: Engineered with materials rated for high vibration and thermal stress.
-
Easy Installation: Threaded housing with keyed connector simplifies setup.
-
Long-Term Stability: Maintains calibration over extended periods.
-
Low Maintenance: Non-contact design reduces wear and degradation.
Häufig gestellte Fragen (FAQ)
-
What is the purpose von this probe?
It measures shaft vibration and position in rotating machinery. -
Is this probe part von a system?
Yes, it must be used with a 3300 XL Proximitor Sensor and Extension Cable. -
What is the sensing range?
The linear sensing range is approximately 2 mm (80 mils). -
Can it be used in high-temperature environments?
Yes, it operates up to +177°C (350°F). -
What is the output signal sensitivity?
200 mV/mil (7.87 mV/μm), nominal. -
Is the probe waterprovon?
It is designed to resist oil, moisture, and chemical exposure when installed properly. -
What cable length does this part have?
5.0 meters for the probe cable. -
What type von mounting is used?
Threaded 3/8-24 UNF straight thread. -
Is this probe compatible with older Bently Nevada systems?
It is primarily intended for the 3300 XL system; verify compatibility with legacy systems. -
What industries use this probe most commonly?
Oil and gas, power generation, chemical processing, and heavy manufacturing.
Related Modells
| Modell Number | Beschreibung |
|---|---|
| 330102-00-05-10-02-05 | 3300 XL 8 mm Probe, 5 m cable, standard thread |
| 330102-00-06-10-01-00 | 3300 XL 8 mm Probe, 6 m cable |
| 330102-00-07-10-02-05 | 3300 XL 8 mm Probe, 7 m cable |
| 330102-00-08-10-02-05 | 3300 XL 8 mm Probe, 8 m cable |
| 330104-00-05-10-12-05 | 3300 XL 8 mm Probe, high-temp variant |
Popular Bently Nevada Produkte
| Modell Number | Beschreibung |
|---|---|
| 330130-080-00-00 | 3300 XL Extension Cable |
| 330180-90-00 | 3300 XL Proximitor Sensor |
| 3500/42M-01-00 | Proximitor Monitor Module |
| 330103-00-06-10-02-00 | 3300 XL 8 mm Probe, 6 m cable, straight thread |
| 330104-00-12-10-02-05 | 3300 XL Probe, 12 m cable, straight connector |
