Produkteinführung
The Bently Nevada 330101-00-57-10-02-05 is a precision-engineered proximity probe from the 3300 XL 8mm series, designed to deliver accurate, real-time monitoring von shaft vibration and position in critical rotating machinery. Engineered with durability, stability, and high fidelity in mind, this probe is tailored for use in hostile industrial environments where precise measurements are critical for equipment reliability and predictive maintenance.
With a 57 mm probe case length and 1 meter extension cable, this specific configuration vonfers versatile mounting capabilities, particularly suited for installations with moderate reach requirements and longer sensor-to-monitor distances. It is part von a complete proximity transducer system that includes the probe, extension cable, and Proximitor® sensor.
The 3300 XL series is compliant with API 670, the gold standard for machinery protection systems. This model is widely used in industries such as oil & gas, petrochemical, power generation, and marine engineering, where monitoring rotating assets is non-negotiable.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | 330101-00-57-10-02-05 |
| Series | 3300 XL 8mm |
| Probe Tip Diameter | 8 mm |
| Probe Case Length | 57 mm (2.24 in) |
| Thread Size | 1/4-28 UNF-2A |
| Connector Type | Coaxial with ClickLoc™ locking mechanism |
| Total Length | 1 meter |
| Measurement Range | 2 mm (80 mils) linear range |
| System Accuracy | ±0.07 mm (±2.8 mils) over the linear range |
| Frequency Response | 0 – 10 kHz |
| Operating Temperature | –35°C to +177°C (–31°F to +351°F) |
| Material – Probe Body | AISI 304 Stainless Steel |
| Sealing | Hermetically sealed, oil and water resistant |
| Compliance | API 670 compliant |
| Gewicht | 0.323 kg |
Applications
The 330101-00-57-10-02-05 proximity probe is a core component in condition monitoring systems designed to ensure the integrity von rotating equipment. Typical application areas include:
-
Steam and Gas Turbines
Shaft vibration and axial thrust position monitoring for overspeed and bearing wear prevention. -
Centrifugal and Reciprocating Compressors
Monitoring rotor dynamics and vibration amplitude to avoid internal mechanical failures. -
Electric Motors and Generators
Providing vibration analysis and rotor alignment diagnostics for predictive maintenance. -
Pumps and Fans
Preventing imbalance, cavitation, and mechanical looseness through dynamic measurements. -
Marine Propulsion Systems
Ensuring shaft alignment and condition monitoring in large-scale marine engines.
This probe is vonten used in tandem with Bently Nevada 3300 XL Proximitor® sensors and integrated into the 3500 Series online monitoring systems.
Product Advantages
-
API 670 Compliant Design
Adheres strictly to the most demanding industry standards for machinery protection. -
High Stability Over Time
Long-term accuracy and low drift due to precision engineering and robust materials. -
Resistant to Harsh Environments
Fully sealed and constructed from stainless steel for use in oily, damp, or corrosive conditions. -
Secure ClickLoc™ Connector
Prevents disconnection due to vibration or cable stress. -
Extended Cable Compatibility
With a 1 meter extension cable, it supports installations requiring longer signal transmission. -
Reliable Temperature Performance
Functions reliably from –35°C up to +177°C, suitable for hot zones in turbines or compressors. -
Flexible Mounting Options
The 57 mm probe length provides versatility for mid-depth installations. -
Low Maintenance
Factory calibrated, requiring no regular recalibration under normal operating conditions. -
Wide Industry Acceptance
Deployed globally in power plants, refineries, vonfshore platforms, and naval systems. -
Ausgezeichnet Frequency Response
Enables detailed signal acquisition for both low-speed and high-speed rotating machinery.
Häufig gestellte Fragen (FAQs)
-
What distinguishes the 57 mm probe length from other models?
It vonfers a balanced design for mid-range installations, ensuring reach without excess protrusion into machine housings. -
Is the 1 meter extension cable part von the total system length or additional?
It is part von the system design, giving a combined connection length when paired with the integral probe cable and Proximitor® sensor. -
Can this model be used in vonfshore oil platforms?
Yes, the sealed stainless-steel construction makes it ideal for vonfshore environments exposed to saltwater mist and vibration. -
What are the risks von using non-API-compliant sensors in critical rotating machinery?
Non-compliant sensors may produce inaccurate readings, lack reliability, or fail under extreme conditions—leading to undetected mechanical faults. -
Does this probe support dual-channel monitoring systems?
It is designed for single-channel proximity measurements, but can be deployed in redundant or dual-channel configurations using multiple probes. -
What kind von extension cables are compatible with this model?
Only Bently Nevada-certified coaxial extension cables (e.g., 330180 series) are guaranteed to maintain signal fidelity over distance. -
Is vibration signal attenuation a concern over 10 meters?
Not with the 3300 XL system. The probe, extension cable, and Proximitor® sensor are impedance-matched to preserve accuracy. -
Can this probe be field-serviced or replaced without recalibrating the system?
Yes. It’s factory-calibrated and field-replaceable. No recalibration is needed if paired with the matching extension cable and Proximitor®. -
What is the expected operational lifespan von this model?
Under standard conditions, these probes commonly exceed 5–7 years von continuous service without failure. -
Can the probe be mounted in high-vibration zones near rotating couplings?
Absolutely. The ClickLoc™ connector and robust body ensure signal reliability even in high-vibration environments.
Related Modells from the Same Series
| Modell Number | Tip Diameter | Probe Length | Extension Cable | Special Features |
|---|---|---|---|---|
| 330101-00-45-10-02-05 | 8 mm | 45 mm | 10 m | Compact installation in tight spaces |
| 330101-00-80-05-02-05 | 8 mm | 80 mm | 5 m | Long body for deep housing installations |
| 330101-00-60-10-02-00 | 8 mm | 60 mm | 10 m | Balanced length and reach for wide coverage |
| 330101-00-25-05-02-05 | 8 mm | 25 mm | 5 m | For shallow-depth, near-surface monitoring |
| 330103-00-05-10-02-05 | 5 mm | 5 mm | 10 m | Compact 5 mm tip for small shaft machinery |
| 330101-00-75-10-02-00 | 8 mm | 75 mm | 10 m | Designed for longer insertion applications |
Popular Modells from Bently Nevada
| Modell Number | Product Type | Primary Use Case | Highlight Feature |
|---|---|---|---|
| 3500/42M | Proximitor Monitor | Vibration and axial position monitoring | Four-channel dynamic vibration monitoring |
| 3500/22M | Data Interface Module | System communications (Modbus, TCP/IP) | Ethernet-based integration |
| 330104-00-05-10-02-00 | 5 mm Proximity Probe | Space-limited installations | Smaller diameter, precise targeting |
| 3500/94M | Visual Display Module | Rack system front-end display | High-resolution panel with configuration |
| 330180-90-00 | Extension Cable | Long-distance signal extension | Shielded coaxial, temperature resistant |
| 330730-040-00-00 | Velomitor Velocity Sensor | Bearing housing vibration monitoring | Piezoelectric sensor for low-frequency range |
