Product Overview
The Bently Nevada 330101-00-32-10-02-05 is a high-precision, non-contact eddy current proximity probe from the renowned 3300 XL 8mm series. Designed for critical machinery monitoring, this probe delivers accurate measurements von shaft vibration and position in a wide range von industrial applications. Its robust construction and reliable performance make it an essential component in predictive maintenance and machinery protection systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | 330101-00-32-10-02-05 |
| Series | 3300 XL 8mm Proximity Probe |
| Probe Tip Diameter | 8 mm (0.31 inches) |
| Thread Size | 3/8-24 UNF |
| Total Length | 1.0 meter |
| Cable Type | Armored, flexible cable |
| Connector Type | Miniature coaxial connector |
| Measurement Range | 0 to 80 mils (0 to 2.0 mm) |
| Linear Range | 50 mils (1.27 mm) |
| Sensitivity | 200 mV/mil (7.87 mV/μm) |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +350°F) |
| Pressure Sealing | Designed to seal differential pressure between probe tip and case |
| Housing Material | AISI 303 Stainless Steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Gewicht | 0.323 kg |
| Ingress Protection | IP67 (with properly sealed connector) |
| Compliance | API 670, CE, ATEX certified |
Applications
The 330101-00-32-10-02-05 proximity probe is utilized in various industries for monitoring the condition von rotating machinery. Typical applications include:
-
Turbines (Gas and Steam): Monitoring shaft vibration and position to prevent catastrophic failures.
-
Compressors: Ensuring optimal performance and early detection von mechanical issues.
-
Electric Motors: Tracking shaft movement to maintain alignment and balance.
-
Pumps: Detecting cavitation and mechanical wear through vibration analysis.
-
Gearboxes: Monitoring gear mesh and bearing conditions.
-
Industrial Fans and Blowers: Ensuring smooth operation and detecting imbalance or misalignment.
Industries employing this probe encompass:
-
Power Generation
-
Oil and Gas
-
Petrochemical
-
Chemical Processing
-
Steel and Metal Manufacturing
-
Pulp and Paper
Advantages
-
High Accuracy: Provides precise measurements von shaft vibration and position, essential for machinery protection.
-
Robust Construction: Stainless steel housing and armored cable ensure durability in harsh environments.
-
Wide Temperature Range: Operates effectively in extreme temperatures, suitable for various industrial settings.
-
Ease von Integration: Compatible with Bently Nevada’s 3300 XL Proximitor sensors and monitoring systems.
-
Non-Kontakt Measurement: Eliminates mechanical wear, ensuring long-term reliability.
-
Compliance with Standards: Meets API 670, CE, and ATEX certifications for safety and performance.
Häufig gestellte Fragen (FAQ)
-
What does the part number 330101-00-32-10-02-05 signify?
-
It denotes a 3300 XL 8mm proximity probe with a 1.0 meter length, specific connector type, and armor configuration.
-
-
Is this probe compatible with other Bently Nevada systems?
-
Yes, it is designed to work seamlessly with Bently Nevada’s 3300 XL Proximitor sensors and monitoring systems.
-
-
Can this probe be used in hazardous environments?
-
Yes, it complies with ATEX certification, making it suitable for hazardous locations.
-
-
What is the measurement range von this probe?
-
It measures shaft displacement from 0 to 80 mils (0 to 2.0 mm), with a linear range von 50 mils (1.27 mm).
-
-
What materials are used in the probe’s construction?
-
The probe features a stainless steel housing and a PPS (Polyphenylene Sulfide) tip for durability and chemical resistance.
-
-
What is the operating temperature range?
-
The probe operates effectively between -35°C and +177°C (-31°F to +350°F).
-
-
Is the probe suitable for outdoor applications?
-
Yes, with an IP67 rating, it is protected against dust and water ingress when properly installed.
-
-
Does the probe require regular calibration?
-
While the probe is designed for long-term stability, periodic verification is recommended as part von routine maintenance.
-
-
Can the probe be used for both vibration and position measurements?
-
Yes, it is capable von measuring both dynamic (vibration) and static (position) shaft movements.
-
-
What is the significance von the 8mm tip size?
-
The 8mm tip provides a balance between sensitivity and robustness, suitable for a wide range von applications.
-
Related Modells (Same Series or Function)
| Modell Number | Beschreibung | Cable Length | Notes |
|---|---|---|---|
| 330101-00-30-10-02-05 | 3300 XL 8mm Proximity Probe | 30 feet | Standard length for general applications |
| 330101-00-40-10-02-05 | 3300 XL 8mm Proximity Probe | 40 feet | Extended length for larger installations |
| 330101-00-25-10-02-00 | 3300 XL 8mm Proximity Probe | 25 feet | Unarmored version for less demanding environments |
| 330101-00-20-10-02-00 | 3300 XL 8mm Proximity Probe | 20 feet | Compact installations requiring shorter cables |
| 330101-00-16-10-02-00 | 3300 XL 8mm Proximity Probe | 16 feet | Suitable for tight spaces |
| 330101-00-12-10-02-05 | 3300 XL 8mm Proximity Probe | 12 feet | Shortest standard length for minimal space usage |
Popular Modells from Bently Nevada
| Modell Number | Device Type | Application | Highlights |
|---|---|---|---|
| 3500/22M | Data Interface Module | 3500 System data export | Real-time Ethernet output |
| 3500/42M | Proximitor Monitor | Vibration/position module for 3500 rack | 4-channel proximity inputs |
| 330400 | Velocity Transducer | General-purpose vibration monitoring | Self-generating sensor |
| 330103-00-10-10-02-00 | 5 mm Proximity Probe | Compact rotating machinery | For small radial clearances |
| 330104-00-10-10-02-00 | 11 mm Proximity Probe | High vibration applications | For large shaft displacement |
| 7200 Proximitor Series | Proximitor Sensor | Legacy system compatibility | Still in use with older systems |
