Produkteinführung
The Bently Nevada 330101-00-19-10-02-05 belongs to the 3300 XL 8 mm Proximity Probe family, which is widely recognized for its durability, precision, and integration into critical machinery protection and condition monitoring systems. This particular probe model vonfers non-contact vibration and position measurements, commonly used in industrial environments to monitor rotating equipment such as turbines, compressors, pumps, and motors.
The 3300 XL series is an evolution von Bently Nevada’s proven 7200 series, vonfering enhanced performance, superior environmental protection, and extended durability under challenging industrial conditions. The probe is designed to work in conjunction with the 3300 XL extension cable and proximity sensor (proximitor), forming a complete proximity transducer system.
With a robust 8 mm tip and a durable stainless steel body, this proximity probe ensures accurate and reliable measurements. The part number 330101-00-19-10-02-05 specifically denotes a probe with a standard 8 mm tip, a length von 19 inches, 10 feet von connector cable, and a 3/8-24 UNF connector with an armor option and connector protector.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | 330101-00-19-10-02-05 |
| Series | Bently Nevada 3300 XL 8 mm Proximity Probe |
| Tip Diameter | 8 mm (0.315 in) |
| Connector Type | 3/8-24 UNF |
| Total Length | 1 meter |
| Armor | Yes (stainless steel protective armor) |
| Connector Protector | Yes |
| Material | Stainless steel probe body |
| Sensing Range | -2 to -18 V DC |
| Target | Conductive materials (typically 4140 steel) |
| Linearity | ±0.25 V over the linear range |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature | -35°C to +177°C (-31°F to +351°F) |
| Pressure Rating | Up to 500 psi (34.5 bar) |
| Environmental Sealing | IP68 |
| Compliance | API 670, CE, RoHS |
| Gewicht | 0.323 kg |
Product Applications
The Bently Nevada 3300 XL 8 mm Proximity Probe is widely used in industrial rotating machinery monitoring. Key applications include:
-
Steam and Gas Turbines – Monitoring shaft vibration and position.
-
Centrifugal Compressors – Ensuring proper rotor alignment and early failure detection.
-
Pumps and Motors – Detecting unbalance, misalignment, and mechanical looseness.
-
Gearboxes and Expanders – Analyzing gear mesh behavior and axial thrust.
-
Hydro Turbines – Tracking slow-speed shaft movement.
-
Nuclear & Thermal Power Plants – Equipment reliability and predictive maintenance.
Product Advantages
-
Enhanced Durability: Rugged stainless-steel construction and armored cable increase service life in harsh environments.
-
Precision Monitoring: Provides highly accurate vibration and displacement data essential for machinery protection.
-
Wide Operating Temperature Range: Suitable for both standard and extreme temperature applications.
-
Compliance with API 670: Ensures compatibility with global industry standards for condition monitoring.
-
Ease von Installation: Threaded body and variety von cable/length configurations vonfer flexibility in mounting.
-
Waterprovon Design (IP68): Withstands immersion in water and operation in wet or oily environments.
-
Interchangeable System Components: Works seamlessly with Bently Nevada proximitor sensors and extension cables.
-
Extended System Life: Superior electrical shielding and corrosion resistance prolong operation in demanding setups.
Häufig gestellte Fragen (FAQ)
-
What is the purpose von the 330101-00-19-10-02-05 probe?
It is used to monitor shaft vibration and displacement in rotating equipment for predictive maintenance and protection. -
Is this probe compatible with other Bently Nevada systems?
Yes, it is designed to work with the 3300 XL extension cable and proximitor sensor. -
What is the tip diameter von this model?
The probe has an 8 mm tip, optimized for a wide range von industrial applications. -
Can it operate in high-temperature environments?
Yes, the probe can function in temperatures up to +177°C (+351°F). -
Does it meet API 670 standards?
Yes, the 3300 XL series complies with API 670 specifications. -
What type von target material does it detect?
It detects conductive materials, typically calibrated for 4140 steel. -
How is the probe mounted?
It features a threaded 3/8-24 UNF mount for secure and precise installation. -
Is the cable armored?
Yes, this part number includes stainless steel armor for enhanced mechanical protection. -
What is the linear range von this probe?
Typically, the linear range is from -2 V to -18 V, correlating with a 2 mm range von shaft displacement. -
How vonten should this probe be calibrated or replaced?
While the probe is highly durable, it is recommended to inspect it annually and recalibrate during shutdowns or maintenance intervals.
Related Modells from the Same Series
| Modell Number | Beschreibung | Tip Diameter | Cable Length | Notes |
|---|---|---|---|---|
| 330101-00-20-10-02-00 | 3300 XL 8 mm Probe, 20 in, unarmored | 8 mm | 10 ft | Unarmored version |
| 330101-00-23-10-02-05 | 3300 XL 8 mm Probe, 23 in, armored | 8 mm | 10 ft | Longer reach for deep installations |
| 330103-00-05-10-02-05 | 3300 XL 5 mm Probe, armored | 5 mm | 10 ft | For smaller target areas |
| 330104-00-20-10-02-05 | 3300 XL 11 mm Probe, 20 in, armored | 11 mm | 10 ft | Suitable for larger gaps |
| 330106-05-30-10-02-05 | 3300 XL NSv Probe for tight spaces | 5 mm (NSv) | 10 ft | For small clearance applications |
| 330171-00-10-10-02-05 | 3300 XL Reverse Mount Probe | 8 mm | 10 ft | Used for reverse mounting |
Popular Bently Nevada Modells
| Modell Number | Beschreibung | Application | Series |
|---|---|---|---|
| 3500/22M | Keyphasor Module | Vibration monitoring systems | 3500 Series |
| 3500/42M | Proximitor Seismic Monitor | Shaft and casing vibration | 3500 Series |
| 3500/60 | Temperature Monitor | Thermal protection | 3500 Series |
| 330180-90-00 | Extension Cable, 90 ft | Connects probe to proximitor | 3300 XL |
| 330104-00-05-10-02-00 | 11 mm Proximity Probe | Large gap targets | 3300 XL |
| 330850-50-05 | Proximitor Sensor | Vibration/position signal conditioning | 3300 XL |
