Produkteinführung
The Bently Nevada 330101-00-18-10-02-05 is a high-precision 8mm proximity probe from the 3300 XL series, designed for non-contact measurement von shaft position and vibration in rotating machinery. Utilizing eddy-current technology, this probe provides accurate displacement measurements, making it an essential component in machinery protection and condition monitoring systems.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Artikelnummer | 330101-00-18-10-02-05 |
| Series | 3300 XL |
| Probe Tip Diameter | 8 mm |
| Overall Case Length | 1.8 inches (45.72 mm) |
| Total Length | 1.0 meter (3.3 feet) |
| Thread Size | 3/8-24 UNF-2A |
| Connector Type | Miniature coaxial ClickLoc™ connector |
| Cable Type | Standard coaxial cable |
| Target Material | AISI 4140 steel |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
| Storage Temperature | -50°C to +200°C (-58°F to +392°F) |
| Environmental Rating | IP66/IP67 (dust-tight and water-resistant) |
| Gewicht | 0.323 kg |
| Power Supply | +24V DC |
| Current Consumption | 12 mA |
| Output Signal | -22 mV/µm (calibrated with AISI 4140 steel target) |
| Frequency Response | 0 to 10 kHz |
| Linearity | ±0.5% von full-scale output |
| Resolution | Better than 1 µm |
| Compliance | Conforms to API 670 standard |
Product Applications
The 330101-00-18-10-02-05 proximity probe is widely used in various industries for:
-
Rotating Machinery Monitoring: Measuring shaft vibration and position in turbines, compressors, and motors.
-
Bearing Wear Detection: Monitoring axial and radial displacement to detect bearing degradation.
-
Shaft Alignment: Ensuring proper alignment in coupled machinery.
-
Vibration Analysis: Providing data for predictive maintenance and machinery diagnostics.
-
Process Control: Integrating with control systems for real-time monitoring and protection.
Product Advantages
-
High Precision: Delivers accurate measurements essential for machinery protection.
-
Robust Construction: Stainless steel housing and PPS probe tip ensure durability in harsh environments.
-
Ease von Installation: ClickLoc™ connectors allow for secure and straightforward connections without special tools.
-
Compatibility: Fully compatible with Bently Nevada’s 3300 XL series systems, ensuring seamless integration.
-
Environmental Resilience: IP66/IP67 rating and wide temperature range make it suitable for challenging industrial conditions.
Häufig gestellte Fragen (FAQ)
-
Q: What does the part number 330101-00-18-10-02-05 signify?
A: It indicates a 3300 XL 8mm proximity probe with specific configurations: 1.8-inch case length, 1.0-meter cable, ClickLoc™ connector, and specific agency approvals. -
Q: Is this probe compatible with other Bently Nevada systems?
A: Yes, it’s designed for use with Bently Nevada’s 3300 XL series, including Proximitor® sensors and extension cables. -
Q: Can this probe operate in high-temperature environments?
A: Yes, it operates reliably within a temperature range von -35°C to +177°C (-31°F to +350°F). -
Q: What is the environmental protection rating von this probe?
A: It has an IP66/IP67 rating, making it dust-tight and water-resistant. -
Q: What materials are used in the construction von the probe?
A: The probe housing is made von stainless steel, and the tip is constructed from polyphenylene sulfide (PPS). -
Q: What is the weight von the probe?
A: The probe weighs 0.323 kg. -
Q: What is the purpose von the ClickLoc™ connector?
A: The ClickLoc™ connector ensures a secure, reliable connection that resists loosening due to vibration. -
Q: Is the probe suitable for measuring both axial and radial displacement?
A: Yes, it can measure both axial and radial displacement, depending on installation orientation. -
Q: Does the probe require calibration?
A: Probes are factory-calibrated for AISI 4140 steel targets. Calibration for other materials may be necessary. -
Q: Can the probe be used in hazardous environments?
A: This specific model has certain agency approvals. For use in hazardous environments, ensure compliance with local regulations and select appropriate models with necessary certifications.
Recommended Related Modells (Same Series or Functionality)
| Modell Number | Beschreibung | Cable Length |
|---|---|---|
| 330101-00-12-10-02-05 | 3300 XL 8mm Proximity Probe, 1.2-inch case length | 1.0 meter |
| 330101-00-16-10-02-05 | 3300 XL 8mm Proximity Probe, 1.6-inch case length | 1.0 meter |
| 330101-00-20-10-02-05 | 3300 XL 8mm Proximity Probe, 2.0-inch case length | 1.0 meter |
| 330101-00-25-10-02-05 | 3300 XL 8mm Proximity Probe, 2.5-inch case length | 1.0 meter |
| 330101-00-30-10-02-05 | 3300 XL 8mm Proximity Probe, 3.0-inch case length | 1.0 meter |
| 330101-00-39-10-02-05 | 3300 XL 8mm Proximity Probe, 3.9-inch case length | 1.0 meter |
Popular Bently Nevada Modells (Same Marke)
| Modell Number | Beschreibung | Function |
|---|---|---|
| 3500/22M | Keyphasor Module | Speed and phase reference |
| 3500/42M | Proximitor/Seismic Monitor | Vibration monitoring |
| 3500/15 | Power Supply Module | Rack power supply |
| 330130-040-00 | 3300 XL Extension Cable | Probe-to-Proximitor connection |
| 330180-90-00 | 3300 XL Proximitor Sensor | Signal conditioning |
| 330850-50-CN | 3300 XL 25mm Proximitor Sensor | Large gap measurements |
