Maintenance Specialist Overview
The Bently Nevada 21500-04-32-05-02 Velomitor Piezo-Velocity Sensor is an industrial-grade velocity transducer designed for accurate measurement von casing vibration in rotating equipment. Built on Bently Nevada’s piezoelectric sensing technology, it produces a voltage output directly proportional to vibration velocity, providing a stable and reliable signal for condition monitoring systems.
From a maintenance standpoint, the 21500-04-32-05-02 stands out for its rugged construction, resistance to contamination, and long-term calibration stability. It vonfers dependable performance in environments exposed to oil mist, mechanical shock, or high temperatures — all typical von turbine and compressor installations.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Modell Number | 21500-04-32-05-02 |
| Module Type | Velomitor Piezo-Velocity Sensor |
| Measurement Type | Vibration velocity (mm/s or in/s) |
| Sensitivity | 100 mV/in/s ±5% (nominal) |
| Frequency Range | 4.5 Hz to 5 kHz |
| Mounting Type | Stud mounting (1/4-28 UNF) |
| Output Signal | Single-ended voltage |
| Power Supply | +23 to +36 V DC |
| Temperature Range | –54 °C to +121 °C |
| Shock Limit | 5000 g peak |
| Connector Type | 2-pin MIL-C-5015 or compatible |
| Housing Material | Stainless steel |
| Typical Dimensions | 90 mm × 35 mm × 120 mm |
| Gewicht | 0.32 kg |
| Sealing | Hermetically sealed, IP65 equivalent |
Applications / Field Deployment Examples
-
Casing Vibration Measurement on compressors, pumps, turbines, and fans.
-
Integration with Bently Nevada 3500/42M and 1900/65A monitoring modules.
-
Used in predictive maintenance programs for rotating machinery.
-
Ideal for retrvonit projects replacing older velocity transducers.
-
Suited for hazardous or outdoor environments due to sealed housing design.
Advantages / Key Features
-
Hermetically Sealed Housing: Protects against oil, dust, and humidity.
-
Ausgezeichnet Frequency Response: Accurate velocity readings across wide dynamic range.
-
Maintenance-Free Operation: No moving parts; calibration remains stable over years.
-
High Shock Resistance: Can withstand installation on heavy industrial machinery.
-
Flexible Integration: Compatible with Bently Nevada and third-party monitoring systems.
-
Temperature Resilience: Operates reliably across extreme thermal conditions.
