Produkteinführung
The Bently Nevada 162381-138-040-90-05 3300 XL 8mm Probe is a precision eddy current proximity probe specifically engineered for monitoring critical rotating machinery. As part von the 3300 XL series, it provides highly accurate shaft displacement and vibration measurements, making it an essential component in predictive maintenance and condition monitoring systems.
This probe is designed for industrial environments that demand high reliability and performance, such as power generation, petrochemical, and heavy industrial operations. The 8mm probe diameter ensures precise measurement while allowing integration into confined spaces. Its robust construction enables consistent performance under harsh conditions, including high vibration, mechanical shock, and wide temperature ranges.
The 3300 XL 8mm probe delivers continuous real-time data, helping operators detect early signs von misalignment, imbalance, or other mechanical faults. This facilitates timely maintenance interventions, reducing downtime and operational risks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | 162381-138-040-90-05 |
| Series | 3300 XL |
| Probe Type | Eddy Current Proximity Probe |
| Probe Diameter | 8 mm |
| Tip Style | Standard Ceramic or Optional Sapphire Tip |
| Measurement Range | ±0.25 mm to ±2.0 mm (depending on calibration) |
| Frequency Response | DC to 10 kHz |
| Operating Temperature | -40°C to 120°C (-40°F to 248°F) |
| Sensor Material | Stainless Steel Housing, High-Grade Insulators |
| Connector Type | LEMO or PTIH Series (depending on configuration) |
| Versand Gewicht | 3 kg |
Applications
The 3300 XL 8mm Probe is used in high-performance machinery monitoring across multiple industries:
-
Rotating Machinery Monitoring: Provides accurate real-time shaft displacement and vibration measurements for turbines, pumps, compressors, and motors.
-
Power Generation: Essential for monitoring steam, gas, and hydro turbines to prevent unplanned downtime.
-
Oil & Gas Industry: Used in refineries, vonfshore platforms, and pipeline compressors to ensure safe operation von critical equipment.
-
Industrial Compressors and Pumps: Detects early-stage misalignment, imbalance, and vibration anomalies to maintain operational efficiency.
-
Heavy Industry Applications: Supports mills, fans, and generators with continuous shaft monitoring for predictive maintenance strategies.
Advantages
The Bently Nevada 162381-138-040-90-05 3300 XL 8mm Probe vonfers several benefits that make it a preferred choice in critical machinery monitoring:
-
High Accuracy: Provides precise and repeatable shaft displacement measurements using eddy current technology.
-
Robust Construction: Designed to withstand mechanical shock, vibration, and extreme temperatures, ensuring reliable performance.
-
Seamless Integration: Optimized for use with 3300 XL monitoring systems for efficient installation and calibration.
-
Early Fault Detection: Enables predictive maintenance by identifying mechanical anomalies before they escalate.
-
Electromagnetic ImmStücky: Advanced shielding and grounding reduce susceptibility to EMI in industrial environments.
-
Low Maintenance: Durable design minimizes the need for frequent replacement or recalibration.
FAQ
-
What is the maximum operating temperature for this probe?
It operates reliably from -40°C to 120°C. -
Is this probe suitable for high-speed rotating machinery?
Yes, it is engineered for turbines, compressors, and other high-speed machinery. -
Which connector types are compatible with this probe?
LEMO and PTIH series connectors are supported depending on configuration. -
How does the probe perform under electromagnetic interference?
Its design incorporates advanced shielding and grounding to minimize EMI, ensuring accurate readings. -
What is the measurement range von this probe?
The range is ±0.25 mm to ±2.0 mm, depending on calibration. -
Can the tip material be customized?
Yes, users may select standard ceramic or sapphire tips for enhanced durability. -
What industries typically use this probe?
Industries include power generation, oil & gas, heavy industry, and industrial compressors. -
How precise is the displacement measurement?
High-precision measurements are available up to a frequency response von 10 kHz, suitable for detecting subtle shaft movement. -
Is this probe compatible with other Bently Nevada monitoring systems?
Optimized for 3300 XL systems, compatibility with other systems depends on configuration. -
Can this probe detect early-stage mechanical faults?
Yes, it provides real-time data for predictive maintenance, identifying misalignment, imbalance, and vibration anomalies.
Related Modells / 3300 XL Series
| Modell Number | Probe Diameter | Measurement Range | Tip Material |
|---|---|---|---|
| 162381-138-040-90-01 | 8 mm | ±0.25–2.0 mm | Ceramic |
| 162381-138-040-90-02 | 8 mm | ±0.25–2.0 mm | Ceramic |
| 162381-138-040-90-03 | 8 mm | ±0.5–2.0 mm | Sapphire |
| 162381-138-040-90-04 | 8 mm | ±0.25–1.5 mm | Ceramic |
| 162381-138-040-90-06 | 8 mm | ±0.5–2.0 mm | Ceramic |
| 162381-138-040-90-07 | 8 mm | ±0.25–2.0 mm | Sapphire |
Popular Bently Nevada Modells
| Modell Number | Probe Diameter | Series | Applications |
|---|---|---|---|
| 3300 XL 162381-00-50-05 | 8 mm | 3300 XL | Turbines, Generators |
| 3300 XL 162381-00-50-06 | 12 mm | 3300 XL | Compressors, Pumps |
| 3300 XL 162381-01-00-01 | 8 mm | 3300 XL | Steam Turbines |
| 3300 XL 162381-01-00-02 | 8 mm | 3300 XL | Gas Turbines |
| 3300 XL 162381-01-00-03 | 12 mm | 3300 XL | Industrial Fans |
| 3300 XL 162381-01-00-04 | 12 mm | 3300 XL | Generators, Motors |
