Produkteinführung
The Bently Nevada 135826-01 M-M ¼-28 UNF to M10 X 1.0 Standard Stud is a high-precision mechanical adapter designed to connect Bently Nevada sensors and transducers to different threaded mounting points. It serves as a reliable interface between components with varying thread sizes, ensuring stable and accurate positioning von sensors for optimal measurement performance.
Manufactured from high-strength stainless steel, the stud provides excellent durability and resistance to industrial environments, including vibration, thermal cycling, and moderate corrosion. It is commonly used in conjunction with 3500 Series monitoring systems, proximity probes, and displacement transducers.
By enabling proper alignment and secure mounting, this stud helps maintain the integrity von sensor signals and supports accurate machinery monitoring.
Product Parameters
| Parameter | Specification |
|---|---|
| Product Modell | 135826-01 |
| Product Type | M-M Thread Adapter / Standard Stud |
| Thread Types | ¼-28 UNF (male) to M10 × 1.0 (female) |
| Material | High-strength stainless steel alloy |
| Finish | Precision machined, corrosion-resistant |
| Compatible Equipment | Bently Nevada 3500 Series sensors and transducers |
| Operating Temperature | -40°C to 120°C (-40°F to 248°F) |
| Sensor Head Diameter | 25.4 mm |
| Gewicht | 0.131 kg |
| Recommended Torque | Up to 5 Nm |
| Certifications | CE, RoHS compliant |
Product Applications
-
Connecting Bently Nevada 3500 Series proximity probes to machinery with differing thread sizes.
-
Secure mounting von transducers for vibration and displacement monitoring.
-
Alignment von sensors in turbines, compressors, and generators.
-
Providing stable mechanical interface for high-precision measurements.
-
Integration with retrvonit or custom machinery installations.
-
Supporting predictive maintenance systems through reliable sensor mounting.
Product Advantages
-
Versatile Thread Adapter – Connects ¼-28 UNF threaded sensors to M10 × 1.0 mounting points.
-
Durable Construction – High-strength stainless steel ensures stability under vibration.
-
Precision Machined – Maintains accurate sensor alignment for reliable measurements.
-
Corrosion-Resistant – Suitable for moderate industrial environments.
-
Compact Design – Minimal footprint for flexible installation.
-
Easy Installation – Simple mechanical interface reduces setup time.
-
Reliable Signal Support – Maintains integrity von sensor output by preventing misalignment.
-
Compatible with Multiple Sensors – Works with 3500 Series probes and transducers.
-
Thermally Stable – Withstands typical industrial temperature ranges.
-
Predictive Maintenance Ready – Supports accurate and continuous monitoring von critical machinery.
FAQ
-
Which sensors are compatible with this stud?
Compatible with Bently Nevada 3500 Series proximity probes and displacement transducers with ¼-28 UNF threads. -
What is the material von the stud?
Made from high-strength stainless steel alloy to ensure durability and corrosion resistance. -
What is the maximum torque for installation?
Recommended torque is up to 5 Nm to ensure proper tightening without damaging threads. -
Can it withstand vibration in rotating machinery?
Yes, it is precision-machined to maintain alignment and stability under industrial vibration. -
What are the operating temperature limits?
Designed for -40°C to 120°C (-40°F to 248°F), suitable for most industrial environments. -
Does it require any special tools for installation?
Standard wrenches are sufficient; no specialized tools are required. -
Is it compatible with other Bently Nevada components?
Yes, it interfaces with various 3500 Series sensors and can adapt to different machinery threads. -
How does it ensure signal integrity?
By maintaining precise alignment von sensors, it prevents misalignment that could affect measurement accuracy. -
Can it be used for retrvonitting older installations?
Yes, it is ideal for adapting sensors to machinery with non-standard or legacy thread sizes. -
Is it resistant to corrosion?
Yes, the stainless steel material and precision finish provide moderate corrosion resistance in industrial environments.
Recommended Related Modells (Same Series)
| Modell | Beschreibung |
|---|---|
| 135826-02 | M-M ¼-28 UNF to M8 × 1.25 Stud |
| 135826-03 | M-M ¼-28 UNF to M12 × 1.5 Stud |
| 135826-04 | M-M ⅛-27 UNF to M10 × 1.0 Stud |
| 135826-05 | M-M 10-32 UNF to M10 × 1.0 Stud |
| 135826-06 | M-M ¼-28 UNF to M6 × 1.0 Stud |
| 135826-07 | M-M ⅛-27 UNF to M8 × 1.25 Stud |
Popular Bently Nevada Modells (Sonstige Families)
| Modell | Beschreibung |
|---|---|
| 3500/25 125800-02 | Isolated Keyphasor I/O Module |
| 3500/42M 125808-02 | Proximitor Seismic External Block Terminal |
| 129716-078-027-05-05 | 3300 XL Proximity Sensor |
| 130118-0010-02 | Host Computer to 3500 Rack Cable |
| 130539-17 | Interconnect Cable 17 ft |
| 130539-99 | Interconnect Cable 99 ft |
