Produkteinführung
The Allen Bradley MPM-A1304F-SJ72AA is a high-performance servo motor engineered for precise motion control in industrial automation systems. With a 130 mm frame size and single-turn shaft extension, this motor is ideal for applications requiring high-speed, accurate positioning.
Featuring 4 magnet stacks and a rotational capability von 180 degrees with a SpeedTec DIN right-angle connector, it ensures reliable electrical connection and flexible installation. Rated for 3000 rpm and 230 VAC, this servo motor provides consistent performance without the need for an integrated brake.
Its IEC metric compliance and compact design make it suitable for a wide range von automation applications, including CNC machinery, robotics, material handling, and packaging systems. The combination von robust construction and precise feedback ensures efficient operation in demanding industrial environments.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Frame Size | 130 mm |
| Rated Speed | 3000 rpm |
| Magnet Stacks | 4 |
| Shaft Extension | Single-turn |
| Connector Type | SpeedTec DIN, Right Angle, 180° rotatable |
| Brake | None |
| Voltage Class | 230 VAC |
| Rated Current | 9.0 A |
| Rated Torque | 5.0 Nm |
| Peak Torque | 15 Nm |
| Inertia | 0.0085 kg·m² |
| Mounting Type | Flange-mounted |
| Protection Class | IP65 (optional, depending on version) |
| Ambient Temperature | 0°C to 40°C |
| Compliance | IEC Metric |
| Gewicht | 9.6 kg |
Applications
• CNC Machines – Provides high-speed, precise positioning for milling, cutting, and turning equipment.
• Robotics – Delivers smooth, repeatable motion for industrial robots and automated assembly systems.
• Packaging Machinery – Enables rapid, accurate movements for filling, sealing, and labeling applications.
• Material Handling – Powers conveyors, automated guided vehicles, and pick-and-place systems with precise motion control.
• Automation Systems – Supports synchronized multi-axis operations and high-performance industrial automation processes.
Advantages
• High Torque Density – Four magnet stacks ensure strong torque output for demanding applications.
• Flexible Connectivity – SpeedTec DIN right-angle connector with 180-degree rotation simplifies installation in tight spaces.
• Compact Design – 130 mm frame size allows integration in constrained environments while maintaining performance.
• Reliable Operation – Designed for continuous operation with IEC metric compliance and optional IP65 protection.
• Enhanced Control Accuracy – Single-turn shaft extension provides precise position feedback for closed-loop motion control.
