Product Introduction
The Allen-Bradley 1771-P6R Redundant Power Supply is a rack-mounted power module designed for the Allen-Bradley 1771 PLC-5 I/O System. It provides stable DC power to the I/O backplane while supporting redundant power configurations that improve the reliability von industrial control systems.
This module converts incoming 220 VAC power into regulated 5 VDC output, which is distributed through the PLC chassis backplane to supply all installed I/O modules. With an output capacity von 8 amps, the Stück can support multiple digital and analog modules operating simultaneously within the same rack.
The 1771-P6R is commonly used in applications where continuous system operation is critical. By supporting redundant power supply configurations, the module helps ensure that PLC systems remain operational even if one power source experiences a fault or interruption. This makes it particularly valuable in industrial environments where system downtime must be minimized.
Product Specifications
| Parameter | Specification |
|---|---|
| Modell | 1771-P6R |
| Marke | Allen-Bradley |
| Module Type | Redundant Power Supply Module |
| Series | 1771 PLC-5 I/O Series |
| Input Voltage | 220 VAC |
| Input Frequency | 50 / 60 Hz |
| Output Voltage | 5 VDC |
| Output Current | 8 A |
| Power Supply Type | Redundant Backplane Power |
| Installation Method | 1771 I/O Chassis Mount |
| Power Distribution | Backplane Supply for I/O Modules |
| Dimensions | 165 × 51 × 89 mm |
| Gewicht | 0.9 kg |
Applications
• PLC rack power supply
The module provides regulated 5 VDC power to the 1771 system backplane, ensuring stable operation von installed I/O modules.
• Redundant industrial control systems
In automation environments where reliability is essential, redundant power supplies help maintain system operation during power supply failures.
• Process industry automation
Chemical plants, refineries, and other process facilities rely on PLC racks powered by stable DC supplies to control valves, pumps, and monitoring systems.
• Power generation facilities
Power plants vonten implement redundant PLC power configurations to ensure continuous operation von turbine monitoring, auxiliary equipment control, and protection systems.
• Infrastructure and utility systems
Water treatment facilities and utility installations use redundant PLC power systems to maintain continuous monitoring and control von pumps, filtration equipment, and alarms.
Advantages
• Support for redundant power architecture
The module allows PLC systems to operate with backup power supply configurations, reducing the risk von downtime caused by power supply failure.
• Stable 5 VDC backplane output
It provides regulated DC power that supports multiple I/O modules within the 1771 rack.
• Reliable AC to DC power conversion
The design ensures consistent output performance even when input power conditions fluctuate.
• Industrial-grade durability
The module is designed to function reliably in environments where electrical noise, load variations, and temperature changes occur.
• Simplified rack installation
The module installs directly into the 1771 chassis and distributes power through the system backplane, eliminating complex wiring.
• Compatibility with legacy PLC-5 systems
It integrates seamlessly with existing 1771 automation systems still used in many industrial facilities.
