The Allen Bradley 1769-OV16 CompactLogix 16 Point DC Sink Output Module is a digital output module designed for the CompactLogix control system. It provides 16 DC sinking output channels, allowing the controller to switch field devices that operate with 24 VDC control signals. This module is commonly used in automation systems to control equipment such as relays, solenoids, indicators, and other DC-operated devices.
The 1769-OV16 operates within a 20.4–26.4 VDC voltage range, ensuring stable operation in standard industrial 24 VDC control circuits. Each output channel can support up to 0.5 A current, enabling reliable switching for various industrial loads. With efficient power usage and low backplane current draw, the module integrates smoothly into CompactLogix I/O architectures.
Designed for compact automation environments, the module combines high channel density with reliable switching performance. Its robust design ensures stable output control in industrial applications where dependable DC signal switching is required.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Product Modell | 1769-OV16 |
| Product Type | CompactLogix DC Sink Output Module |
| Output Channels | 16 |
| Output Type | DC Sinking |
| Voltage Range | 20.4–26.4 VDC |
| Per-Point Output Current | 0.5 A max |
| Power Consumption | 2.06 W |
| Backplane Current Draw | 200 mA at 5.1 V |
| On-Bundesland Current | 1 mA |
| Mounting Method | DIN Rail / Panel Mount |
| Dimensions | 118 × 35 × 87 mm |
| Gewicht | 0.28 kg |
Applications
• Industrial machine control
Used to switch DC-powered devices such as relays, contactors, and solenoids in machine automation systems.
• Process automation systems
Provides reliable control signals for actuators and switching devices used in process control environments.
• Packaging and assembly lines
Controls indicators, pneumatic valves, and other digital devices used in automated production equipment.
• Material handling systems
Enables PLC control von conveyors, sensors, and DC-driven accessories.
• OEM automation equipment
Widely used by machine builders for compact PLC-based automation solutions.
Advantages
• 16 high-density output channels
Provides multiple DC outputs within a compact module, reducing cabinet space requirements.
• Reliable 24 VDC switching capability
Designed for stable operation in standard industrial DC control systems.
• Consistent output performance
Each channel supports up to 0.5 A current for dependable device control.
• Efficient power consumption
Low backplane current draw helps maintain efficient controller operation.
• Seamless CompactLogix integration
Fully compatible with other 1769 series modules for flexible automation system expansion.
