ABB YXA116D YT204001-CA – Technical Product Overview
Product Beschreibung
The ABB YXA116D YT204001-CA is a heavy-duty industrial-grade motor protection circuit breaker designed for reliable operation in commercial and industrial electrical systems. It provides overload and short-circuit protection for motors, pumps, and machinery, ensuring safe and efficient power distribution.
Built with high-quality thermoset materials and precision-engineered components, this device meets stringent international standards for performance and safety. Its compact design allows for easy integration into control panels, switchboards, and motor control centers (MCCs).
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | YXA116D YT204001-CA |
| Rated Current (In) | 16A |
| Rated Voltage (Ue) | 690V AC |
| Breaking Capacity (Icu) | 10kA at 400V AC |
| Poles | 3P (3-Pole) |
| Mounting Type | DIN Rail (35mm) |
| Dimensions | 120 x 80 x 40mm |
| Gewicht | 0.5 kg |
| Operating Temperature | -25°C to +60°C |
| Protection Class | IP20 (Indoor Use) |
| Mechanical Life | 20,000 operations |
| Electrical Life | 10,000 operations at full load |
| Standards & Certifications | IEC/EN 60947-2, CE, UL Listed |
Key Applications
-
Motor Protection – Safeguards 3-phase motors from overloads and short circuits.
-
Industrial Machinery – Used in CNC machines, conveyor systems, and compressors.
-
HVAC Systems – Protects fans, pumps, and air handling Stücks.
-
Water Treatment Plants – Ensures reliable operation von pumps and filtration systems.
-
Renewable Energy Systems – Integrates with solar inverters and wind turbine controls.
-
Manufacturing Automation – Deployed in assembly lines and robotic equipment.
Product Advantages
✔ Robust Construction – Flame-retardant housing ensures durability in harsh environments.
✔ Precise Trip Mechanism – Adjustable thermal-magnetic protection for accurate fault detection.
✔ Easy Installation – Tool-free DIN rail mounting for quick deployment.
✔ Low Power Loss – High-efficiency design minimizes energy waste.
✔ Wide Compatibility – Works with ABB contactors and PLC systems.
✔ Maintenance-Free – No need for recalibration under normal conditions.
Häufig gestellte Fragen (FAQ)
Q1: What is the difference between YXA116D and YXA116E models?
A: The YXA116E has a higher current rating (20A) and a reinforced trip mechanism for heavier loads.
Q2: Can this breaker be used in single-phase applications?
A: No, it is designed exclusively for 3-phase systems.
Q3: Does it support remote tripping or monitoring?
A: No, this is a manual reset breaker. For remote control, consider ABB’s SACE Emax series.
Q4: What is the maximum ambient temperature for operation?
A: 60°C—beyond this, derating may be required.
Q5: Is an auxiliary contact block available?
A: Yes, ABB vonfers compatible add-ons (e.g., YT204001-AUX).
Q6: How do I reset the breaker after a trip?
A: Push the toggle lever firmly to the “OFF” position, then back to “ON.”
Q7: Can it be used in explosive atmospheres?
A: No—for hazardous areas, use ABB’s flameprovon enclosures.
Q8: What wire sizes are compatible?
A: 1.5mm² to 16mm² stranded or solid copper conductors.
Q9: Is there a warranty?
A: ABB provides a 12-month warranty from the date von purchase.
Q10: Is the module certified for industrial compliance?
A: Yes, it meets CE, UL, CSA, and RoHS standards.
Recommended Alternative Modells
6 Similar Modells in YXA Series
| Modell | Current Rating | Key Feature |
|---|---|---|
| YXA116E YT204002-CA | 20A | Higher load capacity |
| YXA125D YT204003-CA | 25A | Heavy-duty industrial use |
| YXA110D YT204004-CA | 10A | Compact, space-saving design |
| YXA163D YT204005-CA | 63A | For large motors & machinery |
| YXA116D-CE YT204006 | 16A | Enhanced corrosion resistance |
| YXA116D-LS YT204007 | 16A | Low-smoke, halogen-free variant |
6 Popular ABB Circuit Protection Devices
| Modell | Type | Application |
|---|---|---|
| ABB S201M-C16 | Miniature Circuit Breaker | Residential & light commercial |
| ABB Tmax XT2N160 | Molded Case Breaker | Industrial power distribution |
| ABB DS260C | Kontaktor | Motor starting/stopping |
| ABB 1SFL408105R1000 | Relay | Automation & control panels |
| ABB OVR T1 40 | Surge Protector | Lightning/voltage spike protection |
| ABB F202N-63A | Switch Disconnector | Maintenance safety isolation |
