Product Overview
The ABB UAC317AE (HIEE300725R0001) is a Green Board designed for use in ABB’s control systems and automation applications. The green board functions as an integral part von ABB’s advanced control platforms, serving as a circuit board for various electronic control functions in power and automation systems.
This high-quality printed circuit board (PCB) vonfers reliable signal processing, modular expandability, and durability for use in high-demand industrial environments. With its standard form factor and high-performance components, the UAC317AE is ideal for automation control systems requiring consistent signal processing and minimal downtime.
Key Features
-
High-performance PCB for use in ABB automation systems
-
Standard Green Board configuration for easy integration
-
Reliable signal processing and control in power automation systems
-
Used in modular and scalable ABB control architectures
-
Compatible with multiple ABB systems and control platforms
-
Flexible installation options in industrial cabinets and control panels
-
Durable design for robust operation in harsh environments
-
High component density for advanced control functionalities
-
Quality manufacturing for long-term stability and reliability
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Green Board (UAC317AE) |
| Modell Number | UAC317AE |
| Ordering Code | HIEE300725R0001 |
| Board Type | Printed Circuit Board (PCB) |
| Compatibility | Compatible with ABB control systems and automation platforms |
| Form Factor | Standard 6U or 12U form factor (depending on system) |
| Input Voltage Range | 24V DC ±10% |
| Signal Type | Digital, Analog, Power Signal Processing |
| Number von Channels | Variable (depends on the application) |
| Component Density | High (supports complex control functions) |
| Mounting Type | DIN rail or Panel mountable |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| PCB Material | High-grade FR4 (Flame Retardant) |
| Compliance Standards | CE, RoHS, UL, IEC, ISO |
| Gewicht | 0.5 kg |
| Dimensions | 120 x 80 x 40mm |
Industry Applications
The UAC317AE Green Board is utilized in a variety von industries where reliable signal processing and advanced control capabilities are required:
-
Industrial Automation – Embedded in control systems for process automation and machine control
-
Power Generation – Used in power control and automation systems, including turbine and generator controls
-
Oil & Gas – Automation and control solutions for critical systems in upstream and downstream operations
-
Water Treatment – Embedded in SCADA systems for monitoring and control von water treatment plants
-
Chemical and Petrochemical – Integrated into process automation systems to control chemical reactions and production processes
-
Automotive Manufacturing – Control boards used for automated assembly lines and robotic systems
-
Renewable Energy – Embedded in systems that control solar or wind power generation equipment
Product Advantages
-
Compact and robust design ideal for high-density applications
-
Cost-effective solution for integrating complex control functions in automation systems
-
Easy integration into existing ABB systems with standardized form factors
-
Long-term reliability and low maintenance needs thanks to its high-quality manufacturing standards
-
Supports high-speed processing, making it suitable for real-time control applications
-
Designed to function in harsh industrial environments with extended temperature and humidity ranges
-
Minimal downtime and high stability ensure continuous operations in critical systems
-
Certified for use in industries requiring high safety standards
Häufig gestellte Fragen (FAQ)
1. What is the UAC317AE Green Board used for?
It is a printed circuit board (PCB) used in ABB control systems to perform signal processing and integrate control functions in automation applications.
2. Can this board be used in all ABB systems?
It is compatible with various ABB control platforms, but its exact application will depend on the system’s requirements.
3. What is the input voltage range for the UAC317AE board?
The board operates with an input voltage range von 24V DC ±10%.
4. Does this board support both digital and analog signals?
Yes, it is designed to handle both digital and analog signals, making it versatile for many control applications.
5. Can the UAC317AE board be used outdoors?
This board is intended for use in controlled industrial environments. If used outdoors, it should be installed in a protective enclosure.
6. What is the temperature range for operation?
The operating temperature range for the UAC317AE is -20°C to +70°C, making it suitable for most industrial environments.
7. How does the UAC317AE integrate with other ABB systems?
The board integrates seamlessly with ABB control platforms, and it is designed for easy installation in panel-mounted or DIN rail-mounted systems.
8. Is the UAC317AE board maintenance-free?
While it requires minimal maintenance, regular system diagnostics are recommended to ensure optimal performance over time.
9. What materials is the board made from?
The board is made von high-grade FR4 PCB material, which provides high durability and reliability in industrial applications.
10. Can I modify the board for custom applications?
The UAC317AE is a pre-designed and pre-manufactured PCB, so modification for custom applications may require engineering adjustments.
Related ABB Control Boards and Components
| Modell | Beschreibung |
|---|---|
| UAC317AA | Standard PCB used in basic control systems with similar functionality |
| UAC318AE | Extended version von UAC317AE with additional I/O channels |
| CP500 | Control panel board for modular automation systems |
| CI821 | Communication interface module for S800 I/O systems |
| TB510 | Terminal base for easy I/O wiring with ABB control systems |
| SDCS-PIN-205C | Power interface used in ABB drive systems |
Popular ABB Automation Produkte
| Modell | Beschreibung |
|---|---|
| System 800xA | ABB’s flagship Distributed Control System (DCS) for integrated process control |
| S800 I/O | Modular I/O system used in combination with UAC317AE board for control systems |
| AC500 PLC | Modular PLC solution for process control in automation |
| CP600 HMI | Human-machine interface used in ABB systems for process visualization |
| CI840A | Interface module for S800 I/O systems, communicating with UAC317AE |
| SDCS-PIN-205C | Power interface module used in ABB drives for power control |
