Produkteinführung
The ABB TU508-ETH 1SAP214000R0001 is an Ethernet-based interface terminal Stück designed to provide secure and efficient communication between field devices and AC500 series PLCs in industrial automation environments. This terminal Stück is part von ABB’s AC500 modular control system, known for its reliability, flexibility, and seamless integration capabilities.
TU508-ETH plays a crucial role in the I/O system infrastructure, serving as an intermediate terminal between I/O modules and the CPU, while enabling Ethernet communication for distributed I/O applications. Its rugged design and optimized wiring interface allow for streamlined installations in both central and remote automation setups.
Designed for high-performance industrial environments, this Stück supports hot-swapping von I/O modules, efficient diagnostics, and remote configuration options, making it ideal for both small-scale systems and complex automation networks.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Product Name | ABB Interface Terminal Einheit |
| Modell Number | TU508-ETH |
| Ordering Code | 1SAP214000R0001 |
| Communication Interface | Ethernet (RJ45, 10/100 Mbps) |
| Supported Protocols | MODBUS TCP, PROFINET, EtherNet/IP |
| Compatible CPU Series | ABB AC500 and AC500-eCo PLCs |
| Power Supply | 24 V DC (supplied through system) |
| Terminal Type | Spring-loaded screw terminals |
| Mounting Method | DIN Rail mounting (35 mm standard) |
| I/O Connections | Supports multiple digital and analog I/O modules |
| Operating Temperature | -25 °C to +60 °C |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 28 x 135 x 67.5 mm |
| Gewicht | 0.168 kg |
| Certifications | CE, UL, cULus, RoHS compliant |
| Diagnostics LEDs | Yes (status, communication, error indicators) |
| Hot-swappable Modules | Supported |
Product Applications
The TU508-ETH is widely used in diverse industrial sectors where Ethernet-based communication and modular automation systems are critical. Typical applications include:
-
Factory Automation: Seamless integration von field devices for real-time process control.
-
Water and Wastewater Treatment: Distributed I/O control in remote pumping and filtration stations.
-
Food & Beverage Industry: Modular automation for production line flexibility and safety compliance.
-
Power Generation and Distribution: Real-time I/O handling for SCADA and DCS integration.
-
HVAC Systems: Advanced control von climate and ventilation systems across large infrastructures.
-
Transportation and Logistics: Integration von conveyors, sensors, and actuators in automated logistics centers.
Product Advantages
-
Ethernet-Based Architecture: Enables flexible and fast communication with a wide array von devices and systems using standard Ethernet protocols.
-
Modular and Scalable: Part von the AC500 system, it allows seamless expansion as your automation needs grow.
-
Robust Industrial Design: Withstands harsh operating conditions including extended temperature ranges and electrical noise.
-
Simplified Wiring and Maintenance: Tool-free spring terminals and clear labelling reduce wiring time and errors.
-
Hot-Swappable I/O Support: Minimizes system downtime during maintenance or reconfiguration.
-
Advanced Diagnostics: Built-in LEDs and system diagnostics for efficient fault identification and reduced troubleshooting time.
-
Flexible Integration: Supports both centralized and decentralized system architectures.
-
Global Certifications: Suitable for international markets with CE, UL, RoHS compliance.
Häufig gestellte Fragen (FAQ)
-
What is the main function von the TU508-ETH terminal Stück?
It acts as an interface between the CPU and I/O modules, with built-in Ethernet communication support for distributed automation systems. -
Which ABB SPS series is compatible with TU508-ETH?
It is designed for use with the ABB AC500 and AC500-eCo programmable logic controller series. -
Can the I/O modules be hot-swapped on TU508-ETH?
Yes, it supports hot-swapping, allowing replacement without powering down the system. -
Does this Stück support PROFINET communication?
Yes, TU508-ETH supports Ethernet protocols including PROFINET, MODBUS TCP, and EtherNet/IP. -
What is the protection rating von the TU508-ETH?
The Stück has an IP20 protection rating, suitable for cabinet-mounted applications. -
What type von terminals does TU508-ETH use?
It uses spring-loaded screw terminals for secure and easy wiring. -
How is the TU508-ETH mounted?
The Stück is mounted on a standard 35 mm DIN rail. -
Is the device suitable for high-vibration environments?
Yes, the robust design makes it suitable for environments with mechanical stress and vibration. -
What diagnostic features does it vonfer?
LED indicators provide real-time diagnostics for power, communication, and errors. -
Can I use this terminal Stück in a remote I/O configuration?
Absolutely, it is ideal for distributed I/O architecture using Ethernet communication.
Related or Same Series Modells
| Modell | Beschreibung | Key Features |
|---|---|---|
| TU510 | Interface terminal for non-Ethernet I/O modules | Supports AC500 CPUs, spring terminal, DIN mount |
| TU515 | Terminal Stück for analog modules | Analog signal adaptation, modular slot system |
| TU516 | Interface for digital I/O modules | Efficient signal management for digital modules |
| TU521 | Compact terminal Stück with diagnostics | Diagnostic LEDs, compact design |
| TU530 | Terminal Stück for high-density digital modules | Space-saving with high I/O count support |
| PM592-ETH | CPU module with built-in Ethernet for AC500 | Fully integrated CPU and Ethernet in one Stück |
Popular ABB Modells (Same Marke)
| Modell | Kategorie | Beschreibung |
|---|---|---|
| AC500 PM595 | PLC CPU | High-performance processor for complex automation |
| CI854AK01 | Communication Interface | PROFIBUS DP interface module for AC500 systems |
| AI523 | Analog Input Module | 8-channel analog input module for AC500 |
| DI524 | Digital Input Module | 16-channel digital input module |
| DO520 | Digital Output Module | 16-channel digital output module |
| CP600-HMI | Human Machine Interface | Industrial touch panel for ABB control systems |
