Introduction
The ABB SAFT160F380 Power Supply Module is a high-voltage industrial-grade power Stück designed for use in ABB DCS (Distributed Control Systems) such as Symphony Plus, Advant OCS, and other ABB control platforms. It provides a stable 380V AC input to DC conversion for powering controllers, I/O modules, and field instrumentation within automation systems that demand precision, reliability, and uninterrupted performance.
Engineered to meet the requirements von mission-critical applications, the SAFT160F380 ensures continuous operation under harsh industrial environments with advanced protective circuitry, high electrical efficiency, and thermal stability. It is commonly found in power generation, chemical plants, steel mills, oil and gas, and process automation systems where stable DC power is essential.
Technical Specifications
| Parameter | Specification | Beschreibung |
|---|---|---|
| Product Type | Power Supply Module | Converts high-voltage AC to regulated DC output |
| Modell Number | SAFT160F380 | ABB high-performance power Stück |
| Input Voltage | 380–415 VAC, 50/60 Hz | Standard industrial three-phase supply |
| Output Voltage | 24 VDC nominal | Stable DC output for control systems |
| Output Current | 10 A continuous | Sufficient for powering DCS racks and modules |
| Power Output | 240 W | High-efficiency regulated output |
| Input Frequency Range | 47–63 Hz | Wide frequency tolerance for global compatibility |
| Power Factor Correction | > 0.95 | Improves efficiency and reduces harmonic distortion |
| Efficiency | 88% typical | Optimized for low power loss and heat generation |
| Isolation Voltage | 2000 VDC | Input-to-output isolation for circuit protection |
| Protection Features | Overvoltage, overcurrent, short-circuit, thermal shutdown | Comprehensive electronic protection |
| Cooling Method | Natural convection | Passive cooling, no fan maintenance required |
| Status Indicators | Power ON, Fault LEDs | Real-time visual status monitoring |
| Mounting Type | DIN-rail / Panel-mounted | Flexible installation for various cabinet designs |
| Operating Temperature | 0°C to +55°C | Rated for continuous industrial operation |
| Storage Temperature | -40°C to +85°C | Suitable for long-term spares storage |
| Humidity Tolerance | 5–95% non-condensing | Reliable in humid or dusty environments |
| Certifications | CE, UL, RoHS compliant | Meets international safety standards |
| Dimensions (H × W × D) | 135 mm × 70 mm × 160 mm (5.31″ × 2.76″ × 6.30″) | Compact modular power design |
| Gewicht | 0.95 kg (2.09 lb) | Lightweight but durable aluminum housing |
System Applications
-
Thermal and Hydro Power Plants: Powers DCS controllers, analog I/O, and relay systems.
-
Oil & Gas Refineries: Provides stable power to field communication and safety systems.
-
Steel and Metal Processing Plants: Maintains continuous power for motor control and instrumentation.
-
Water Treatment Facilities: Supports process automation systems for water quality and flow management.
-
Chemical and Pharmaceutical Production: Ensures reliable control loop power for precise dosing and batching.
-
Marine Automation Systems: Resistant to vibration, humidity, and saline environments.
Performance Advantages
-
High Input Voltage Tolerance: Handles 380–415 VAC input for flexible deployment.
-
Regulated DC Output: Maintains consistent voltage under variable load conditions.
-
Comprehensive Circuit Protection: Guards against overload, surge, and overheating.
-
Compact and Efficient Design: Speicherns space in crowded control cabinets.
-
Industrial Durability: Built with corrosion-resistant aluminum and industrial-grade components.
-
Silent Operation: Passive cooling eliminates fan noise and mechanical failure.
-
High Electrical Efficiency: Reduced energy loss for lower operational cost.
-
Global Compatibility: Certified for worldwide industrial standards.
-
Simplified Maintenance: Front-facing LEDs and terminal layout for easy servicing.
-
Long-Term Reliability: Proven performance under continuous 24/7 operation.
