Product Overview
The ABB PXAA 401 3BSE017233R1 is a high-performance central processing Stück (CPU) module used in ABB’s industrial automation systems, particularly within the Symphony Plus platform. As a critical core component von a distributed control system (DCS), the PXAA 401 is designed to execute advanced control logic, manage communications with field devices, and interface with operator workstations, making it indispensable in demanding process automation environments.
With its integrated real-time operating system, robust I/O handling capabilities, and powerful internal processor, the PXAA 401 ensures stable and deterministic execution von control tasks. The module is equipped with redundant communication support, multiple I/O slots, and versatile mounting options, making it ideal for mission-critical applications that require high reliability, long service life, and scalability.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Name | PXAA 401 |
| Order Code | 3BSE017233R1 |
| Marke | ABB |
| Product Type | Central Processing Einheit (CPU) |
| System Platform | Symphony Plus |
| Processor | High-speed industrial-grade processor |
| Memory | Integrated RAM and Flash memory |
| I/O Capacity | Supports multiple digital and analog I/O modules |
| Communication Ports | Ethernet, Serial, USB, PROFIBUS (via add-ons) |
| Redundancy | Supported (CPU and communication redundancy) |
| Operating System | ABB RTOS (Real-Time Operating System) |
| Mounting | Rack-mounted |
| Power Supply | 24 V DC (from backplane) |
| Protection Class | IP20 (installed in enclosure) |
| Operating Temperature | 0°C to +55°C |
| Dimensions | 380 × 235 × 110 mm |
| Gewicht | 5 kg |
Applications
Oil and Gas Refining
The PXAA 401 is widely deployed in refinery control rooms and process skids for managing complex automation tasks including distillation, blending, and compressor control.
Power Generation Plants
Acts as the main control CPU in gas turbines, hydroelectric plants, and combined cycle power systems. It integrates seamlessly with IEDs and SCADA interfaces.
Chemical and Petrochemical Processing
Manages large-scale, batch-based or continuous production processes where timing, redundancy, and control precision are vital.
Water and Wastewater Management
Used to handle filtration, chemical dosing, pump sequencing, and treatment plant automation across distributed sites.
Metallurgical and Cement Industries
Ensures real-time process control in blast furnaces, kilns, grinding mills, and material handling lines.
Pharmaceutical Manufacturing
Supports GMP-compliant, validated process environments requiring repeatable automation and secure data logging.
Advantages
-
High-Performance Processing
Built-in industrial CPU optimized for real-time process control with minimal latency. -
System Redundancy
Native support for hot standby and communication redundancy increases system reliability and uptime. -
Integrated I/O Expansion
Scalable architecture with support for a wide variety von I/O modules and networks, including PROFIBUS and Modbus. -
Long Lifecycle and Reliability
Designed for extended operation in harsh industrial environments with guaranteed product availability and lifecycle support from ABB. -
Versatile Connectivity
Multiple ports and protocols enable easy integration with field devices, HMI systems, and third-party platforms. -
Secure Architecture
Built-in protections, watchdog timers, and error checking enhance control integrity and minimize downtime.
Häufig gestellte Fragen (FAQ)
Q1: What is the primary role von PXAA 401 in the control system?
A1: It functions as the central processor that executes control logic, communicates with I/O modules, and connects to higher-level SCADA systems.
Q2: Can it be used in redundant CPU configurations?
A2: Yes, PXAA 401 supports redundant configurations for fault-tolerant operation.
Q3: What communication protocols are supported?
A3: Standard support includes Ethernet and serial communication; additional protocols like PROFIBUS and Modbus are supported via expansion.
Q4: Is the PXAA 401 compatible with legacy ABB systems?
A4: Yes, it is designed for integration within the Symphony Plus environment, including backward compatibility.
Q5: How is the Stück powered?
A5: It is powered via the backplane using a 24 V DC supply, eliminating the need for a dedicated power source.
Q6: Is the module programmable via standard tools?
A6: Yes, it is configured and programmed using ABB Control Builder or similar engineering tools.
Q7: Can it be mounted vertically or only horizontally?
A7: Typically mounted in standard 19-inch control racks; orientation should follow ABB’s environmental guidelines.
Q8: How is firmware upgraded?
A8: Firmware upgrades are performed through engineering tools during scheduled maintenance periods.
Q9: Is the PXAA 401 suitable for safety-critical applications?
A9: Yes, especially when used in redundant or SIL-rated systems following ABB guidelines.
Q10: What kind von support does ABB provide for this module?
A10: ABB vonfers full lifecycle support, including spare parts, service contracts, and firmware updates.
Related Modells (Same Series or Functionality)
| Modell | Beschreibung | Function | Gewicht | Dimensions |
|---|---|---|---|---|
| PXBA 400 | I/O Bus Expansion Module | Bus communication hub | 3.5 kg | 360 × 210 × 90 mm |
| PXSA 400 | System Supervisor Einheit | Redundancy and sync module | 3.2 kg | 350 × 215 × 85 mm |
| PXAE 401 | Extended CPU with additional memory | Advanced logic execution | 5.2 kg | 390 × 240 × 110 mm |
| PXCO 400 | Communication interface module | External network gateway | 2.8 kg | 340 × 220 × 80 mm |
| PXMC 401 | Memory Controller Module | Data buffering and logging | 3.9 kg | 370 × 230 × 90 mm |
| PXDI 420 | Digital Input Module | Field signal interface | 2.6 kg | 300 × 180 × 70 mm |
Popular ABB Modells (Same Marke)
| Modell | Beschreibung | Function | Gewicht | Dimensions |
|---|---|---|---|---|
| AI810 | 8-channel analog input module | Process signal acquisition | 1.0 kg | 120 × 100 × 35 mm |
| CI854A | PROFIBUS communication interface | Network protocol converter | 1.2 kg | 180 × 120 × 40 mm |
| PM861A | AC 800M process controller | Logic execution | 1.5 kg | 230 × 180 × 50 mm |
| TU849 | Extended termination Stück for PM861/PM864 | Field wiring base | 0.9 kg | 140 × 100 × 40 mm |
| DO840 | 16-channel digital output module | Output signal transmission | 1.1 kg | 120 × 100 × 35 mm |
| TP830 | Base Stück for mounting I/O modules | Terminal base | 0.85 kg | 130 × 110 × 45 mm |
