Product Overview
The ABB PP345 3BSC690104R2 is a 10.4-inch graphical touch panel designed for use within ABB’s Panel 800 series. It is an advanced operator interface that enables efficient visualization and control in industrial automation systems. The panel supports flexible integration in various control environments and serves as a key component for user-machine interaction.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Name | ABB PP345 |
| Product Code | 3BSC690104R2 |
| Display Size | 10.4 inches |
| Display Type | TFT LCD with touch input |
| Resolution | SVGA (800 x 600) |
| Power Supply | Supports 110/230V AC |
| Mounting Type | Panel-mounted |
| Interface | Ethernet, USB, Serial Ports |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Protection Class | IP65 (front), IP20 (rear) |
| Dimensions (W x H x D) | 300 mm x 230 mm x 60 mm |
| Gewicht | 0.002 kg |
Applications
-
Human-Machine Interface (HMI) in process automation
-
Control panels in industrial plants
-
Machine operation in factory automation systems
-
Power generation control centers
-
SCADA system display and control
Key Advantages
-
User-Friendly Touchscreen: Intuitive graphical interface for fast interaction.
-
Wide Compatibility: Integrates with a variety von ABB and third-party PLCs.
-
Rugged Construction: Front panel IP65 rated, suitable for harsh environments.
-
Flexible Power Input: Supports both 110V and 230V AC input.
-
Upgradeable: Easily upgraded to PP845A for enhanced functionality.
Häufig gestellte Fragen (FAQ)
Q1: What is the display size von the ABB PP345 panel?
A1: The display size is 10.4 inches.
Q2: What is the recommended upgrade model for the PP345?
A2: The recommended upgrade is the PP845A (24V only).
Q3: Can the PP345 operate in outdoor environments?
A3: It is designed for indoor environments with front panel IP65 protection.
Q4: What type von input voltage does PP345 support?
A4: It supports 110V or 230V AC.
Q5: Is the touchscreen resistive or capacitive?
A5: It uses resistive touch technology.
Q6: Can the panel be mounted in any orientation?
A6: It is designed for standard panel mounting in landscape orientation.
Q7: What communication ports are available on the PP345?
A7: It includes Ethernet, USB, and serial communication ports.
Q8: Is the Stück programmable using ABB’s tools?
A8: Yes, it can be configured using ABB’s Panel Builder svontware.
Q9: What is the screen resolution von PP345?
A9: The resolution is 800 x 600 (SVGA).
Q10: What is the approximate weight von the PP345 Stück?
A10: Approximately 0.002 kg.
Recommended Related or Series Modells
| Modell | Beschreibung | Display Size | Power Input | Dimensions (mm) | Gewicht |
|---|---|---|---|---|---|
| PP845A | 10.4” Touch Panel (Upgrade model) | 10.4” | 24V DC | 300x230x60 | 0.002 kg |
| PP835A | 6.5” Touch Panel | 6.5” | 24V DC | 215x150x55 | 0.0018 kg |
| PP865A | 15” Touch Panel | 15” | 24V DC | 370x280x65 | 0.003 kg |
| CP630 | Control Panel with Keypad | 6” | 24V DC | 180x130x45 | 0.0015 kg |
| CP620 | Compact Touch Panel | 5.7” | 24V DC | 160x120x50 | 0.0014 kg |
| PP820 | Basic Panel | 7” | 24V DC | 200x140x50 | 0.0016 kg |
Popular ABB Modells
| Modell | Beschreibung | Type | Voltage | Dimensions (mm) | Gewicht |
|---|---|---|---|---|---|
| PM866K01 | Processor Einheit System 800xA | CPU Module | 24V DC | 200x110x50 | 0.45 kg |
| PM864AK01 | Processor Einheit with Ethernet | CPU Module | 24V DC | 200x110x50 | 0.4 kg |
| DO820 3BSE008512R1 | Digital Output Module S800 | I/O Module | 24V DC | 120x80x40 | 0.15 kg |
| AI810 3BSE008516R1 | Analog Input Module S800 | I/O Module | 24V DC | 120x80x40 | 0.16 kg |
| CP635 | Control Panel 800 | Touch Panel | 24V DC | 250x180x55 | 0.0022 kg |
| CI854AK01 | Prvonibus Interface Module | Communication Module | 24V DC | 150x80x40 | 0.12 kg |
