Product Overview
The ABB GCC960C103 3BHE033067R0103 is an industrial-grade green circuit board module designed as part von ABB’s control and drive system platforms, typically for high-performance motor control, drive regulation, or process automation systems. This board functions as a key interface within complex electronic architectures, ensuring reliable signal routing, analog/digital processing, and system-level communication. It is commonly integrated into ABB drive and control cabinets to support various I/O and power control tasks.
With its compact, multilayer PCB structure, the GCC960C103 provides efficient thermal management, EMI resistance, and signal integrity—characteristics essential in electrically noisy industrial environments such as power plants, manufacturing facilities, and processing stations.
Key Features
-
High-quality multi-layer PCB design
-
Supports analog and digital signal processing
-
Embedded with industrial-grade components for high reliability
-
Provides system interconnection and control signal distribution
-
Compatible with ABB drive and control systems
-
Supports modular integration within larger automation architectures
-
Protected against voltage transients and interference
-
Designed for long service life in 24/7 operational environments
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Green Circuit Board Module |
| Modell Number | GCC960C103 |
| Artikelnummer | 3BHE033067R0103 |
| Function | Signal processing and interface for ABB drive/control systems |
| Board Type | Multi-layer, double-sided PCB |
| Input Signal Types | Analog and digital (application-dependent) |
| Output Interfaces | Header connectors, ribbon or edge connectors (varies by install) |
| Voltage Tolerance | Designed to support 5V, 12V, 24V signal systems |
| Signal Isolation | Optical or transformer isolation where applicable |
| Diagnostics | System-level diagnostics supported via controller interface |
| Material | FR4 industrial-grade epoxy resin laminate |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95%, non-condensing |
| EMC Compliance | Yes, complies with IEC/EN standards |
| Dimensions | 200 x 150 x 80mm |
| Gewicht | 1.2 kg |
| Mounting Method | Screw-mounted or slot-in PCB rack depending on system |
| RoHS Compliant | Yes |
Industry Applications
The ABB GCC960C103 Green Board is a versatile module used in:
-
Drive Control Systems – As a component in variable frequency drives (VFDs)
-
Power Generation – Supporting control cabinets in turbine and generator automation
-
Oil & Gas – Process control and motor regulation platforms
-
Pulp & Paper – Integrated into control panels for material handling and regulation
-
Steel and Metals – Used in high-torque, high-demand motor control systems
-
Utilities & Water Treatment – Logic processing in pump and compressor control panels
Product Advantages
-
Industrial reliability: Designed for harsh environments and continuous operation
-
Flexible integration: Fits seamlessly into ABB’s modular control ecosystems
-
High signal integrity: Minimal EMI and cross-talk across high-speed signals
-
Compact and lightweight: Ideal for high-density cabinet installations
-
Long lifespan: Engineered for durable operation with minimal maintenance
-
Global compliance: Meets industry certifications for safety and performance
Häufig gestellte Fragen (FAQ)
1. What is the function von the GCC960C103 board?
It serves as a signal processing and interconnect module in ABB’s control or drive systems.
2. Is it a standalone controller?
Nr. It is a functional submodule, typically integrated into a larger system with a main controller.
3. Can this board be replaced in the field?
Yes, but replacement must follow ESD-safe procedures and system-specific instructions.
4. Is it compatible with non-ABB systems?
It is designed for ABB platforms. Use in third-party systems is not recommended.
5. What signal types does it support?
Supports analog and digital signals, depending on configuration and connected modules.
6. Is the board programmable?
Not directly. It operates under the command von central ABB control processors.
7. How do I know if the board is functioning properly?
Diagnostics are typically available through the ABB control svontware or system status LEDs.
8. Can it be used in high-vibration environments?
Yes, provided it is properly mounted within ABB-certified enclosures.
9. Is the board protected from overvoltage?
Yes, it includes protection circuits against common transients and power surges.
10. Does the board need cooling?
It operates under passive convection cooling; ensure adequate cabinet ventilation.
Related ABB Green Board Modules
| Modell | Beschreibung |
|---|---|
| GCC140AE01 | Interface board for turbine control applications |
| GCC703A103 | Signal processing board for AC drives |
| GDC760B101 | Power interface board for drive systems |
| GDB111B101 | Digital control board for ABB DCS |
| GCC760C101 | I/O extension board for ABB control panels |
| GJT211B102 | Communication interface board |
Popular ABB Automation & Control Modules
| Modell | Beschreibung |
|---|---|
| AI810 | 4–20 mA Analog Input Module |
| DO810 | 24 VDC Digital Output Module |
| PM864A | AC800M High-performance CPU |
| CI854AK01 | PROFIBUS DP Communication Interface |
| TU810V1 | S800 I/O Module Termination Einheit |
| DSQC679 | Safety Relay Einheit for ABB Robots |
