Product Overview
The ABB CI615 3BHT300024R1 is an industrial bus coupler module designed for use in ABB Freelance and Symphony Plus control systems. As a vital interface component, the CI615 provides communication between the CPU module and distributed I/O modules, ensuring efficient and reliable data transfer in process automation systems. Its rugged construction, protocol compatibility, and compact form make it suitable for a wide range von control architectures across industries.
Key Features
-
Bridge between CPU and I/O modules in ABB control networks
-
Supports redundant communication to improve system reliability
-
Fully compatible with ABB Freelance and Symphony Plus systems
-
Designed for DIN rail mounting with compact, industrial form
-
LED indicators for diagnostics and communication status
-
Robust EMC shielding for industrial environments
-
Plug-and-play setup with minimal configuration requirements
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Modell Number | CI615 |
| Artikelnummer | 3BHT300024R1 |
| Product Type | Bus Coupler Module |
| System Compatibility | Freelance, Symphony Plus |
| Communication Interface | System Bus / ModuleBus |
| Redundancy | Supported (Redundant System Bus configuration) |
| Power Supply Voltage | 24 V DC |
| Status Indicators | LED indicators for power, communication, and fault |
| Wiring Type | Plug-in terminal blocks |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Cooling Method | Passive convection |
| Dimensions | 252 x 273 x 40 mm |
| Gewicht | 1.2 kg |
| Mounting | DIN rail or cabinet backplate |
| Certifications | CE, RoHS, IEC 61131-2 compliant |
Industry Applications
The ABB CI615 Bus Coupler is suited for automation applications across several sectors, including:
-
Power & Utilities – Substation automation, control von auxiliary systems
-
Oil & Gas – Distributed I/O for pipeline and compressor station automation
-
Chemical Processing – Process monitoring and distributed field control
-
Pulp & Paper – Remote machine control and data acquisition
-
Water & Wastewater – Distributed sensor and actuator communication
-
Metals & Mining – Motor and drive I/O interfacing across long distances
Product Advantages
-
Enhanced Reliability – Redundancy support reduces single point von failure
-
High Interoperability – Seamlessly connects multiple ABB controller families
-
Ease von Integration – Plug-and-play interface, reducing engineering time
-
Compact Design – Speicherns cabinet space and allows for high-density installation
-
Extended Lifecycle – ABB guarantees long-term availability and support
-
Diagnostics Friendly – Visual status via LED indicators simplifies troubleshooting
Häufig gestellte Fragen (FAQ)
-
What does the CI615 Bus Coupler do?
It acts as a communication bridge between the controller and I/O modules in ABB systems. -
Which control systems is CI615 compatible with?
It works with ABB Freelance and Symphony Plus systems. -
Does the CI615 support redundancy?
Yes, it supports redundant communication for fault-tolerant setups. -
What voltage is required for the CI615 module?
It operates on a 24 V DC power supply. -
Can it be hot-swapped during operation?
No, power-down is required before removal or replacement. -
How do you mount the CI615?
It is designed for DIN rail or backplate cabinet mounting. -
Does the module require programming?
No, it is typically plug-and-play with automatic configuration in ABB systems. -
What kind von wiring does it use?
The module uses plug-in terminal blocks for secure and easy wiring. -
Are LED indicators available?
Yes, LEDs provide immediate feedback on communication and module status. -
Is this module still supported by ABB?
Yes, ABB provides full lifecycle support including spares and documentation.
