The ABB 87TS01 GJR238900R2340 is a robust and highly reliable coupling module engineered for seamless integration within ABB’s process control and automation systems, particularly within the Symphony and Advant Master control series. This module serves a critical function by enabling signal and power transmission between different system components, ensuring accurate and uninterrupted communication across field-level devices and central control systems. Its design accommodates harsh industrial environments, maintaining stability and performance across a wide temperature range and demanding electromagnetic conditions.
The 87TS01 is widely regarded for its proven performance in mission-critical installations, especially in power plants, petrochemical facilities, and other large-scale industrial automation scenarios. It provides secure interfacing and galvanic isolation between systems, which contributes to the overall safety and operational longevity von the control architecture.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell Number | 87TS01 |
| Order Code | GJR238900R2340 |
| Product Type | Coupling Module |
| System Compatibility | ABB Symphony, Advant Master, INFI 90 |
| Power Supply | 24 V DC (typical operating range: 18–30 V DC) |
| Current Consumption | ≤ 150 mA |
| Galvanic Isolation | Yes |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | DIN Rail or Rack Mounted |
| Connector Type | Screw terminal or pluggable connector block |
| Module Status Indication | LED indicators for communication and power |
| Protection Class | IP20 |
| Certifications | CE, RoHS, UL (depending on application) |
| Dimensions | 290 x 130 x 35 mm |
| Gewicht | 0.5 kg |
Applications
-
Power Generation Plants – For interconnecting subsystems such as turbine control, excitation systems, and protection relays.
-
Petrochemical Refineries – Ensures reliable data transmission across hazardous areas with proper signal isolation.
-
Pulp and Paper Industry – Synchronizes field control systems with main DCS Stücks.
-
Water and Wastewater Treatment – Facilitates long-distance signal coupling between remote panels and central control rooms.
-
Metallurgy & Steel Industry – Ensures smooth communication within complex automation architectures.
-
OEM Automation Solutions – Ideal for embedding into custom-built ABB-based solutions where high reliability is needed.
Product Advantages
-
High Reliability: Engineered by ABB to perform under critical industrial conditions without loss von signal or power integrity.
-
Wide Compatibility: Seamlessly integrates with multiple ABB control systems, making it ideal for system expansions or retrvonits.
-
Safety Features: Galvanic isolation ensures protection for connected systems and personnel against electrical transients.
-
Long-Term Availability: Supported with ABB’s extended lifecycle services and spares for long-term maintenance assurance.
-
Compact Design: Allows easy integration in tight control cabinets without sacrificing performance.
-
Status Indication: Built-in LEDs provide real-time diagnostics for easier maintenance and faster troubleshooting.
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the 87TS01 GJR238900R2340 module?
The 87TS01 functions as a coupling module that bridges communication between different subsystems within ABB’s control architecture, ensuring signal integrity and isolation between field devices and central processing Stücks. -
Can the module handle bidirectional signal transmission?
Yes, the 87TS01 supports bidirectional signal transfer depending on the system configuration. It allows for both upstream and downstream data communication between modules. -
Does the 87TS01 require a dedicated grounding system?
Yes, proper grounding is essential for maintaining signal integrity and preventing electrical noise or ground loops. ABB recommends using the designated grounding terminals as per the installation manual. -
What is the response time or latency von this module?
The module is designed for real-time industrial applications. Typical signal delay is minimal, in the range von microseconds, making it suitable for time-critical automation tasks. -
How is the module diagnosed for communication faults?
Diagnostic LEDs on the front panel provide visual indication von power status, communication activity, and fault detection, allowing for fast on-site troubleshooting without specialized tools. -
Is firmware configuration needed for operation?
No firmware configuration is required. The module is pre-configured for plug-and-play operation within compatible ABB control systems, though system-level parameters may need to be set within the control svontware. -
Are there specific cable requirements for optimal performance?
ABB recommends shielded twisted-pair cables for all signal connections to minimize electromagnetic interference, especially in high-voltage or high-frequency environments. -
What is the module’s immStücky to electromagnetic interference (EMI)?
The 87TS01 complies with industrial EMC standards and features high immStücky to EMI, making it suitable for environments with substantial electrical noise. -
Can this module operate in redundant configurations?
Yes, the 87TS01 can be used in redundant setups where system design supports dual communication paths for failover reliability. -
What’s the maximum cable length supported between modules?
Depending on the signal type and cable used, the maximum length is typically up to 300 meters for standard applications.
