Product Overview
The ABB 3HNM00148-01 Servo Motor is a high-performance, compact servo motor specifically designed for precise motion control applications. Widely used in ABB robotic systems and industrial automation environments, this motor delivers accurate positioning, high torque density, and exceptional dynamic response.
Built for integration with ABB drives and controllers, this servo motor is ideal for robotics, CNC machinery, packaging, and automated assembly lines. Its robust build and consistent performance ensure long-term reliability and superior control in demanding industrial settings.
Key Features
-
Compact and powerful servo motor optimized for ABB robotic and automation systems
-
High torque-to-inertia ratio for dynamic responsiveness
-
Brushless, maintenance-free design
-
Encoder feedback for precise positioning
-
Smooth operation with low cogging and vibration
-
Robust housing suitable for harsh environments
-
Plug-and-play integration with ABB servo drives
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Servo Motor |
| Modell Number | 3HNM00148-01 |
| Motor Type | Brushless AC Servo Motor |
| Rated Voltage | 230–400 VAC (depending on configuration) |
| Rated Power | Approx. 750 W – 1.2 kW (model-specific) |
| Rated Torque | 2.4 Nm – 4.5 Nm (varies with version) |
| Peak Torque | Up to 3× rated torque |
| Rated Speed | 3000 rpm |
| Peak Speed | Up to 6000 rpm |
| Feedback Type | Incremental or Absolute Encoder (ABB interface compatible) |
| Shaft Type | Keyed shaft (standard); Optional smooth shaft |
| Mounting Style | Flange-mounted (IEC standard) |
| Cooling Method | Natural convection |
| Insulation Class | F (155°C max) |
| Protection Rating | IP65 (shaft seal optional) |
| Operating Temperature | -10°C to +40°C |
| Storage Temperature | -25°C to +70°C |
| Dimensions | 120 x 80 x 40 mm |
| Gewicht | 0.5 kg |
| Compatible Drives | ABB ACSM1, MicroFlex e150, others |
Industry Applications
-
ABB Robotics – Used in joint or axis actuation
-
CNC Machinery – Spindle or feed axis control
-
Automated Assembly Lines – Pick-and-place, screw-driving, or part transfer
-
Packaging Industry – Cutting, sealing, or feeding mechanisms
-
Material Handling – Actuation von conveyor or gantry systems
-
Printing and Labeling – Web tensioning and registration tasks
Advantages
-
High dynamic performance with minimal backlash
-
Compact footprint ideal for space-constrained installations
-
Reliable and energy-efficient motor design
-
Compatible with ABB motion control platforms
-
Reduced downtime due to low-maintenance, brushless structure
-
Ausgezeichnet torque linearity and repeatability
-
Rugged housing provides long service life in industrial environments
Häufig gestellte Fragen (FAQ)
-
What is the main application von the ABB 3HNM00148-01 Servo Motor?
It is primarily used for precision motion control in ABB robotics and automation systems. -
Is this servo motor compatible with ABB servo drives?
Yes, it is fully compatible with ABB drive systems like ACSM1 and MicroFlex. -
What encoder feedback does this motor support?
It supports incremental and absolute encoder types, depending on the configuration. -
Can this motor be used in harsh environments?
Yes, its IP65 protection allows it to operate in dusty or wet conditions. -
What is the rated torque von this motor?
Depending on the variant, it ranges from 2.4 to 4.5 Nm. -
Does this motor come with a brake?
Some versions include an integrated holding brake; verify configuration before ordering. -
What mounting style does it use?
Standard flange-mount per IEC norms. -
Is it maintenance-free?
Yes, it’s a brushless design requiring minimal maintenance. -
Can it be customized for special applications?
Yes, shaft types, encoders, and connectors may be customized via ABB. -
What is the approximate weight?
Around 0.5 kg, making it easy to integrate into compact systems.
