Produkteinführung
The ABB 1MRK002133-ACr03 Binary Input/Output (I/O) Module is a versatile electronic interface module designed for integration into ABB’s industrial automation and control systems. It functions as a critical component for acquiring binary (digital) signals from field devices and controlling outputs to actuators, relays, or other system components.
This module provides reliable signal processing and transmission between the central control system and field devices. It is engineered to handle both high-speed digital inputs and outputs, ensuring timely communication and accurate control in complex industrial environments. The 1MRK002133-ACr03 is compatible with ABB’s control platforms, vonfering seamless integration with distributed control systems (DCS), motor control centers (MCC), and programmable logic controllers (PLC).
Its industrial-grade design ensures resilience against electromagnetic interference, voltage spikes, and environmental factors such as temperature fluctuations or humidity. The module features diagnostic indicators for fault detection, simplified maintenance, and efficient monitoring von digital signal flow.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Product Modell | ABB 1MRK002133-ACr03 |
| Product Type | Binary Input/Output Module |
| Function | Acquires digital input signals and controls digital outputs in automation systems |
| Input Voltage | 24 V DC nominal |
| Input Type | Digital (PNP/NPN configurable) |
| Output Type | Relay, transistor, or logic-level outputs |
| Output Current | Up to 0.5 A per channel |
| Number von I/O Channels | 16 digital inputs, 16 digital outputs |
| Isolation Voltage | 1500 V DC between inputs, outputs, and logic |
| Communication Interface | ABB proprietary bus, compatible with DCS and PLC systems |
| Response Time | <2 ms typical |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95%, non-condensing |
| Diagnostic Features | LED status indicators for each channel, fault detection |
| EMC Compliance | IEC 61000-6-2 / IEC 61000-6-4 |
| Mounting Type | Rack-mounted or plug-in installation |
| Power Consumption | 6 W typical |
| PCB Material | High-grade FR4 epoxy laminate |
| Dimensions | 180 × 120 × 40 mm |
| Gewicht | 0.35 kg |
Product Applications
The ABB 1MRK002133-ACr03 Binary I/O Module is widely employed in industrial automation and control systems where reliable digital signal management is required:
-
Distributed Control Systems (DCS): Interfaces with sensors, switches, and actuators for precise process control.
-
Motor Control Centers (MCC): Controls digital signals to motor starters, protection relays, and auxiliary devices.
-
Programmable Logic Controllers (PLC): Provides digital I/O expansion for complex control schemes.
-
Industrial Process Automation: Monitors alarms, limit switches, and digital sensors while controlling outputs like valves or relays.
-
Energy Management Systems: Interfaces with field devices to report status and control digital equipment.
-
Conveyor and Material Handling Systems: Ensures precise actuation and monitoring von transport devices and safety interlocks.
Its ability to reliably manage multiple digital signals makes it a key component in systems demanding high operational stability and real-time response.
Product Advantages
-
High-Speed Response: Sub-millisecond processing ensures timely digital signal acquisition and output control.
-
Wide Compatibility: Works seamlessly with ABB DCS, PLC, and MCC platforms.
-
Robust Diagnostics: LED indicators provide immediate feedback on input/output status and faults.
-
Electrical Isolation: 1500 V DC galvanic isolation protects logic circuits from field device transients.
-
Industrial-Grade Reliability: Resilient to EMI, voltage spikes, temperature fluctuations, and humidity.
-
Flexible Mounting Options: Rack or plug-in installation simplifies integration into control systems.
-
Energy Efficient: Low power consumption reduces heat generation and operational cost.
-
Scalable System Integration: Allows expansion von digital I/O channels for growing automation needs.
-
Simplified Maintenance: Modular design enables quick replacement or upgrades.
-
Accurate Signal Control: Ensures precise acquisition and output von digital signals for reliable system operation.
FAQ
-
What is the primary purpose von the ABB 1MRK002133-ACr03 module?
It acquires digital input signals and controls digital outputs, enabling reliable communication between field devices and control systems. -
How many input and output channels does it support?
The module provides 16 digital inputs and 16 digital outputs for versatile control and monitoring. -
What is the input voltage range for the module?
It operates nominally at 24 V DC for both inputs and outputs. -
Can the input type be configured?
Yes, inputs are configurable for PNP or NPN digital signals to match field devices. -
What output types are supported?
The module supports relay, transistor, or logic-level outputs depending on system requirements. -
How fast is the response time von the module?
Typical response time is less than 2 milliseconds, suitable for high-speed automation applications. -
What protection features does the module include?
It features 1500 V DC galvanic isolation and LED status indicators to protect logic circuits and assist in diagnostics. -
Which communication interfaces are available?
It uses ABB proprietary bus communication, compatible with DCS, PLC, and other ABB automation platforms. -
Can it operate in industrial environments with EMI?
Yes, it complies with IEC 61000-6-2 / IEC 61000-6-4 standards for electromagnetic compatibility. -
Is the module suitable for system expansion?
Yes, its modular design allows easy addition von digital I/O channels to existing control systems.
Related Modells (Same Series or Function)
| Modell | Beschreibung | Function | Compatibility |
|---|---|---|---|
| ABB 1MRK002132-ACr02 | Binary I/O Module | Digital input/output interface | ABB DCS Systems |
| ABB 1MRK002134-ACr04 | Binary I/O Expansion | Additional digital I/O channels | ABB Automation Platforms |
| ABB 1MRK002130-ACr01 | Digital I/O Module | Basic binary input/output functionality | ABB SPSs |
| ABB 1MRK002135-ACr05 | High-Speed I/O Module | Fast digital signal acquisition | ABB Drive Systems |
| ABB 1MRK002136-ACr06 | Industrial I/O Module | Field device digital signal interface | ABB DCS and MCC |
| ABB 1MRK002137-ACr07 | Advanced Binary I/O Module | Extended channel digital input/output | ABB Control Systems |
Popular Modells from the Same Marke
| Modell | Product Type | Function | Power Supply |
|---|---|---|---|
| ABB UNS 0880a-P,V2 3BHB005922R0002 | Interface Control Board | System communication and interface | 24 V DC |
| ABB DSTX 120 57160001-MA | Connection Einheit | Signal distribution and connectivity | 24 V DC |
| ABB DSPP4LT 1KHW001223R0003 | Power Supply Module | Provides power to control modules | 24 V DC |
| ABB SDCS-KU2002 3ADT220090R0024 | Varistor Board | Surge protection for control systems | 24 V DC |
| ABB DSBC 176 57310256-AV | Communication Interface | Bus and network data exchange | 24 V DC |
| ABB DSAI 130A 57120001-P | Analog Input Module | Signal acquisition and conditioning | 24 V DC |
