مقدمة المنتج
The Yokogawa ANT401-50/CU1N Optical ESB Bus Repeater Master Module is a high-performance optical communication module engineered for large-scale distributed control systems (DCS). As the master وحدة in an ESB (Enhanced System Bus) optical repeater network, it enables long-distance, high-speed, and deterministic data communication between the central control system and remote field nodes.
This module leverages fiber-optic technology to eliminate electromagnetic interference, ensure signal integrity, and extend the communication range across industrial plants. The ANT401-50/CU1N is widely deployed in mission-critical applications where high reliability, system scalability, and redundancy are essential. Its rugged construction, integrated diagnostics, and flexible mounting options make it suitable for industries such as oil & gas, power generation, petrochemical processing, and automated manufacturing systems.
مواصفات المنتج
| Parameter | الوصف |
|---|---|
| الطراز Number | ANT401-50/CU1N |
| Function | Optical ESB Bus Repeater Master Module |
| Network الدعم | ESB Bus Optical |
| Transmission Medium | Fiber Optic (Single-Mode and Multimode supported) |
| Communication Speed | Up to 1 Gbps |
| Number من Ports | 2 Optical Ports (Transmit/Receive) |
| Power Supply | 24 V DC (±10%) |
| Power Consumption | Approx. 10 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (Non-condensing) |
| Mounting Options | DIN Rail or Panel Mount |
| Indicators | Power, communication, link, and fault status LEDs |
| Compliance & Certification | CE, RoHS, IEC Standards |
| Dimensions (H × W × D) | 142.5 x 130 x 32.8 mm |
| الوزن | 0.3 kg |
Product Applications
The ANT401-50/CU1N module is ideal for industrial systems requiring reliable, interference-free, long-distance communication. Key applications include:
-
Power Generation: Maintaining deterministic communication between central control systems and remote turbine or generator nodes.
-
Oil & Gas Facilities: High-reliability communication for منfshore platforms, refineries, and pipeline monitoring.
-
Petrochemical Plants: Enables real-time data acquisition in harsh environments with strong EMI interference.
-
Pharmaceutical & Food Processing: Ensures accurate and compliant data exchange for automated batch processes.
-
Large Manufacturing Plants: Facilitates integration من distributed control and automation systems across extensive facility areas.
Product Advantages
-
High-Speed Optical Transmission: Provides fast, deterministic communication over long distances.
-
EMI Immوحدةy: Optical fiber completely eliminates electrical interference.
-
Redundant Network الدعم: Dual paths ensure continuous operation even in the event من link failure.
-
Extended Communication Range: Capable من transmitting data over several kilometers without signal loss.
-
Rugged Industrial Design: Compact and durable for installation in harsh plant environments.
-
Integrated Diagnostics: LED indicators and built-in monitoring simplify troubleshooting and maintenance.
FAQ
-
Which types من fiber can be used with the ANT401-50/CU1N?
Single-mode and multimode fibers are supported depending on required transmission distance. -
Does this module support redundant communication paths?
Yes, it provides dual redundant optical paths for high system availability. -
What is the maximum distance for optical data transmission?
Up to 15 km with single-mode fiber, depending on the network configuration. -
How many nodes can be connected via this master module?
Typically supports up to 64 nodes in a single ESB network segment. -
Can it be integrated with Yokogawa CENTUM VP systems?
Yes, full compatibility with CENTUM VP and other Yokogawa DCS systems is provided. -
What diagnostics and monitoring features are available?
LED indicators, self-check functions, and alarm outputs for link integrity. -
Is hot-swapping supported for this module?
Yes, the module can be replaced without shutting down the entire system if configured properly. -
What error-handling mechanisms are implemented?
CRC-based error detection and automatic retransmission ensure data integrity. -
What is the nominal power requirement for operation?
24 V DC (±10%), with power consumption approximately 10 W. -
How does the module synchronize multiple nodes?
Time-synchronized data exchange ensures deterministic communication across the ESB network.
Recommended Related الطرازs (Same Series or Function)
| الطراز | الوصف |
|---|---|
| ANT401-40 S1 | Optical ESB Bus Repeater Slave Module |
| ANT402-10 S1 | Optical ESB Dual Repeater Module |
| ANT403-20 | High-Speed ESB Fiber Coupling Module |
| ANR11D-410 | Optical ESB Bus Node وحدة |
| ANR11D-420 | Extended Optical ESB Bus Node |
| ANT401-60 S1 | ESB Optical Expansion Repeater Module |
Popular Yokogawa الطرازs
| الطراز | الوصف |
|---|---|
| AAI143-S00 | Analog Input Module for precise DCS measurements |
| AAI543-H00 | High-density Analog Input Module |
| ADV151-P50 | Digital Output Module for automation systems |
| ANB10D-420 | Node Interface وحدة for ESB Bus |
| ATD5A-00 | Temperature Input Module |
| AJR10D-410 | Remote I/O Communication Interface |
