Yokogawa AIP502-S1 مقدمة المنتج
The Yokogawa AIP502-S1 is a high-performance industrial pressure transmitter designed for precise and reliable pressure measurement in demanding environments. It is part من Yokogawa’s renowned line من pressure instrumentation, منfering exceptional accuracy, durability, and ease من integration. The AIP502-S1 is widely used in industries such as oil and gas, chemical processing, power generation, and water treatment, where consistent and accurate pressure monitoring is critical.
Product Parameters
| Parameter | Specification |
|---|---|
| الطراز | Yokogawa AIP502-S1 |
| Pressure Range | 0-100 kPa to 0-100 MPa (customizable) |
| Output Signal | 4-20 mA, HART® 7, FOUNDATION™ Fieldbus |
| Accuracy | ±0.075% من span |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Process Connection | 1/2″ NPT, G1/2, or other options |
| Electrical Connection | M20 x 1.5, 1/2″ NPT, or conduit |
| Housing Material | Stainless steel (316L) |
| Diaphragm Material | Hastelloy C276, 316L, or other alloys |
| Protection Rating | IP67, NEMA 4X |
| Dimensions | 22 x 124 x 126 mm |
| الوزن | 1.5 kg |
| Power Supply | 10.5-42 V DC |
| Certifications | ATEX, IECEx, SIL 2/3, CE, PED |
Product Applications
The Yokogawa AIP502-S1 is engineered for a wide range من industrial applications, including:
-
Oil & Gas: Wellhead monitoring, pipeline pressure measurement, and refinery processes.
-
Chemical Processing: Reactor pressure control, distillation columns, and hazardous material handling.
-
Power Generation: Boiler and steam system monitoring, turbine pressure measurement.
-
Water & Wastewater: Pump control, filtration systems, and reservoir level monitoring.
-
Pharmaceutical: Cleanroom pressure monitoring and bioreactor pressure control.
-
Food & Beverage: Hygienic pressure measurement in processing lines.
Product Advantages
-
High Accuracy: ±0.075% accuracy ensures reliable data for critical processes.
-
Robust Construction: Stainless steel housing and corrosion-resistant materials enhance durability.
-
Versatile Communication: الدعمs HART®, FOUNDATION™ Fieldbus, and 4-20 mA output.
-
Wide Pressure Range: Configurable for low to high-pressure applications.
-
Easy Installation: Compact design and multiple process connection options simplify setup.
-
Compliance & Safety: Certified for hazardous areas (ATEX, IECEx) and functional safety (SIL 2/3).
-
Low Maintenance: Long-term stability reduces calibration frequency.
-
Environmental Resistance: IP67/NEMA 4X rating ensures performance in harsh conditions.
الأسئلة الشائعة (FAQ)
-
What is the warranty period for the AIP502-S1?
Yokogawa typically منfers a 5-year warranty, subject to terms and conditions. -
Can the AIP502-S1 be used in explosive atmospheres?
Yes, it is ATEX and IECEx certified for hazardous areas. -
What is the recommended calibration interval?
Every 24 months under normal operating conditions. -
Does it support wireless communication?
No, but it supports wired protocols like HART® and Fieldbus. -
Can the diaphragm material be customized?
Yes, options include Hastelloy C276, 316L, and other alloys. -
Is the AIP502-S1 compatible with Yokogawa’s DCS systems?
Yes, it integrates seamlessly with Yokogawa’s CENTUM VP and other control systems. -
What is the maximum operating temperature?
+85°C (+185°F) without additional cooling. -
How does the AIP502-S1 handle overpressure conditions?
It can withstand up to 150% من the maximum rated pressure without damage. -
Is remote diagnostics possible?
Yes, via HART® or Fieldbus protocols. -
What is the lead time for delivery?
Typically 4-6 weeks, depending on configuration and stock availability.
Recommended Related & Popular الطرازs
Same Series / Related الطرازs
| الطراز | الوصف | Key Feature |
|---|---|---|
| AIP501-S1 | Basic version with ±0.1% accuracy | Lower cost, general-purpose |
| AIP503-S1 | High-temperature variant (+120°C) | For extreme heat applications |
| AIP504-S1 | Flush diaphragm design | For viscous or slurry media |
| AIP505-S1 | Explosion-proمن (Class I, Div 1) | Enhanced hazardous area safety |
| AIP506-S1 | Sanitary model (3A compliant) | Food & pharmaceutical industries |
| AIP507-S1 | Wireless (ISA100) version | For remote monitoring applications |
Popular Yokogawa الطرازs (أخرى Categories)
| الطراز | الوصف | الفئة |
|---|---|---|
| EJA110E | Differential pressure transmitter | Pressure Measurement |
| DPharp EJX | High-performance pressure transmitter | Industrial Process Control |
| UTAdvanced | Ultrasonic flowmeter | Flow Measurement |
| AXF Series | Magnetic flowmeter | Liquid Flow Monitoring |
| YTA Series | Temperature transmitter | Temperature Measurement |
| F3RS01A-S1 | Vortex flowmeter | Steam/Gas Flow Measurement |
