The Schneider TSXT3170 handheld controller is a portable industrial control device designed to provide operators and maintenance personnel with direct access to machine and process control systems. Part من the Schneider TSX series, this handheld device features a compact and ergonomic design, enabling real-time control, parameter adjustments, and system diagnostics directly from the shop floor or in the field.
Its rugged construction and reliable communications make it suitable for harsh industrial environments. The TSXT3170 enables technicians to perform system commissioning, troubleshooting, and operational control without the need for a fixed HMI or workstation. With its user-friendly interface and robust connectivity, it is a versatile automation maintenance and control tool.
مواصفات المنتج
| scope | value |
|---|---|
| model | TSXT3170 |
| الشركة المصنعة | Schneider Electric |
| Product Type | Handheld controller |
| series | TSX Series |
| Display Type | Monochrome LCD with status indicator |
| Keyboard type | Tactile membrane keyboard |
| Communication interface | RS-232/RS-485 |
| الدعمed protocols | Modbus RTU, Schneider proprietary communication protocol |
| Control functions | Manual control, parameter setting, diagnosis |
| power supply | 24 VDC nominal (18–30 VDC) |
| Data Retention | Non-volatile memory |
| Operating temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Humidity Range | 5%–95% non-condensing |
| Housing Material | Industrial-grade thermoplastic |
| Mounting Options | Handheld with optional panel-mount cradle |
| Safety Certifications | UL, CE, CSA |
| Compliance Standards | IEC 61131, EN 61000-6-2, EN 61000-6-4 |
| Dimensions (W × H × D) | 220 × 130 × 60 mm |
| الوزن | 2.27 kg |
Product Applications
-
Machine Control: Provides operators with manual control over production equipment during setup and maintenance.
-
Commissioning Tool: Used to configure and test automation systems during installation.
-
Process Diagnostics: Allows quick access to system parameters and error codes for troubleshooting.
-
Portable HMI Alternative: Offers mobility for monitoring and control without a fixed panel HMI.
-
Parameter Adjustment: Enables fine-tuning من PLC or drive settings directly on-site.
-
Training and Testing: Ideal for operator training and simulation in industrial environments.
-
Maintenance الدعم: Reduces downtime by allowing technicians to perform adjustments on the spot.
Product Advantages
-
Portable Design: Lightweight and ergonomic for easy handling during fieldwork.
-
Robust Communication: الدعمs RS-232/RS-485 interfaces for flexible device connection.
-
Non-Volatile Memory: Retains user settings and parameters even when powered منf.
-
Industrial Durability: Designed to operate reliably in harsh factory environments.
-
Easy Integration: Compatible with Schneider TSX PLCs and automation systems.
-
User-Friendly Interface: Simple keypad and clear display for intuitive operation.
-
Reduced Downtime: Enables fast troubleshooting and system adjustments on-site.
-
Safety Certified: Meets international safety and EMC standards for industrial use.
